Installation Guide and Users Manual 168/198 Series Island Hood Suitable for: Standard Class “R” Class “E” Class IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Island Mount Range Hood Rev. 2016u.
Important Safety Notice Read all Instructions before Installing and operating this appliance • • • • • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction. DO NOT attempt to install this appliance yourself.
Important Safety Notice Read all Instructions before Installing and operating this appliance • • • Clean ventilating fan frequently. Always use appropriate cookware and utensils size. Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: • • • SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn OFF the burner. BECAREFUL TO PREVENT BURNS.
Table of Contents INSTALLATION Tools needed....................................................3 Parts supplied...................................................4 Venting requirements.......................................5 Mount heights & clearance...........................5-6 Calculating vent system length.......................6 Venting methods & ductless conversion..........7 Charcoal filters & electrical requirements.......8 Preparation......................................................
Parts supplied: Range Hood (vary with model) Flappers Remote Control Air diverter (Optional w/ “R” Class Control) (Optional re-circulating kit) Upper standard chimney Lower standard chimney Charcoal Filter (Optional re-circulating kit) Flexible Duct Tube (Optional) Stainless Steel Baffle or Aluminum Filter(s) Description Hexagonal Wood Screws Duct Set Inner Supporting Frame with Top Plate Outer Support Frame This Guide and Warranty Card 4mm x 16mm Round Phillips Head Screw 4mm x 16mm Phillips H
Venting Requirements • • • • • • • Vent system must terminate to the outside (roof or side wall). DO NOT terminate the vent system in an attic or other enclosed area. DO NOT use 4” (10.2 cm) laundry-type wall caps. Use metal/aluminum vent only. Rigid metal/ aluminum vent is recommended. DO NOT use plastic vent. Always keep the duct clean to ensure proper airflow. Calculate the following figures before installation: 1. Distance from the floor to the ceiling. 2.
IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. • Please use Duct Run Calculation below to compute the total available duct run when using elbows, transitions and caps.
Venting Methods • • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installations, see Recirculating (Non-Vented) Kit on Page 11. Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • • • • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. Use metal/aluminum duct work only.
Charcoal Filter Installation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. 1. Remove aluminum filters on hood. 2. Remove the safety filter under the aluminum filter by unscrewing two screws, then position the charcoal filter and align the screw holes, reinstall and fasten two screws. 3. Reinstall the aluminum filters back to the hood. 4.
Preparation WARNING Excessive Weight Require three or more person to move and install this range hood. Spinal or other bodily injuries could occur if it is not followed. Advanced Preparations: 1. Read the entire installation guide and users manual thoroughly, understand instructions and warnings. 2. Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13. 3. Place the range hood on a flat, stable surface.
Installation Installations (refer to Page 4 for parts): 1. As illustrated in Figure 1A, drill four holes with diameter not exceeding 5/8” and depth of 3” to 3-1/2” on the false ceiling. Fasten two hexagonal wood screws at two of these holes opposite from each other, reserve approximately 1/8” for the top support plate as shown in Fiture 1B. Cut out a circle of 7-1/2” diameter for duct work. Use appropriate anchors for your ceiling composition: • Wood ceiling: Use the provided hexagonal wood screw.
WARNING Installation (Continued) 4. As shown in Figure 4A, 4B and 4C, slide in both upper chimExcessive Weight ney and lower chimney, pay extra attention to sharp edges Require three or more person to move and on the chimneys and minimize chimney movements to avoid install this range hood. Spinal or other bodiscratches on the chimneys. You may use a screw driver to ly injuries could occur if it is not followed. prevent them from sliding down as illustrated in Figure 4C.
Installation (Continued) WARNING Due to excessive weight, two or more person is recommended for this step. 6. Install the hood body onto the support frame and secure it with sixteen (16) 4mm x 16mm Phillips Head Tapping Screw, see Figure 6A. Make sure the hood is secure before releasing. Run the duct tube and power cord through the top support plate above the ceiling, see Figure 6B. Recirculating (Non-Vented) Kit: If Re-Circulating Kit is not purchased, skip this step.
Range Hood Operations & Wiring Diagram SV168/198 Series Standard Class (3 Speed Mechanical Control) Low Speed Power Switch High Speed Medium Speed Light Switch Turn On: • Press the speed control (Low Speed, Medium Speed, High Speed) switch to select the desired level of power. Once button is pressed, the previous speed mode will cancel. • Press the Light Switch to power on the lights. CAUTION: DO NOT touch the lights until switched OFF and cooled.
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “R” Class (4 Speed Electronic Control w/ Remote) Power-Off Delay Control Remote Control Sensor Power / Fan Speed Control Speed / Timer Indicator Light Control This range hood is equipped with a credit card size remote control (approximately 20ft range), three built-in electronic controls, a powerful centrifugal squirrel cage motor, grease filters and two bright 12V 20W halogen lights.
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “R” Class (4 Speed Electronic Control w/ Remote) Power-Off Delay Control Remote Control Sensor Power / Fan Speed Control Speed / Timer Indicator Light Control The credit card size remote control controls the power of the Lights , Power-Off Delay , Power (ON/OFF) and Fan Speeds: Quiet (F1), Low (F2), Medium (F3) and High (F4). The Power-Off Delay offers up to 99 minutes delay shutoff.
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “R” Class Wiring Diagram NOTE: Wiring Diagrams shown above with GU10 light configuration. A transformer is required for MR16 Lights.
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “E” Class (4 or 6 Speed Electronic Touch Control) Power Power-Off Delay Decrease Value Blower Speed Indicator Light Increase Value Power-Off Delay Digital Timer Cleaning Reminder Indicator This range hood is designed to remove smoke, cooking vapors and odors from the cook top area.
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “E” Class (4 or 6 Speed Electronic Touch Control) Power Power-Off Delay Decrease Value Blower Speed Indicator • Light Increase Value Power-Off Delay Digital Timer Cleaning Reminder Indicator Controls: • Adjusting the timer function: • While the blower (motor) is not running, press and hold Decrease Value button over 3 seconds to enter timer mode.
Range Hood Operations & Wiring Diagram (Continued) SV168/198 Series “E” Class Wiring Diagram (4 Speed) SV168/198 Series “E” Class Wiring Diagram (6 Speed) NOTE: Wiring Diagrams shown above with GU10 light configuration. A transformer is required for MR16 Lights.
Troubleshooting 1. If the range hood or halogen light does not operate after installation: • • Check if the range hood has been plugged in, make sure that all power has been turned back ON, fused not blown and all electrical wiring are properly connected. Swap out light assembly to working ones to determine whether it is caused by defective bulbs. See Replacing the light bulbs on Page 22-23. 2.
Use and Care Information Operations: • • • • • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers. NEVER leave cooking unattended.
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood & all filter/oil container regularly. Regular care will help preserve the range hood’s performance & appearance. WARNING Hazard of Burns! Light bulb become extremely hot when turned on. DO NOT touch bulb until switched off and cooled. Touching hot bulbs could cause serious burns.
Maintenance (Continued) Replacing J4 Type Halogen Light Bulb: • This range hood uses halogen light bulb: 20W 12V (Product ID: SV-ACS-HAL20W-B). • Make sure the range hood is unplugged or turn OFF breaker and the lights are cool to touch. • Place a small flat-head screwdriver between light housing and lens cover, carefully and gently pry up the lens cover. • Remove the old halogen light bulb by pulling in the direction of wavy arrow. Do not touch the new light bulb with bare hands.
Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replacement parts or components that failed due to manufacturing defects.
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. Failure to do so may result in the denial of your claim. The carrier will furnish you with necessary forms for filing a claim.
