Signamax Connectivity Systems Gigabit Ethernet Converter Series U S E R ’ S G U I D E
Signamax Connectivity Systems Gigabit Ethernet Converter Series User’s Guide
Signamax Gigabit Ethernet Media Converter FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Signamax Gigabit Ethernet Media Converter Preface This manual describes how to install and use the Signamax Gigabit Ethernet Media Converter. The Converter introduced here provides one channel media conversion solution: 10/100/1000BaseT/TX to 1000BaseSX/LX/BX with Link Fault Signaling function The Signamax Gigabit Ethernet Media Converter fully complies with IEEE802.3 10BaseT, IEEE802.3u 100BaseTX, IEEE802.3ab 1000BaseT, and IEEE802.3z 1000BaseSX/LX Ethernet standards.
Signamax Gigabit Ethernet Media Converter Table of Contents FCC WARNING ............................................................. 1 CE MARK WARNING ..................................................... 1 TRADEMARKS ............................................................... 1 PREFACE ....................................................................... 2 TABLE OF CONTENTS .................................................... 3 INTRODUCTION .........................................................
Signamax Gigabit Ethernet Media Converter Introduction The Gigabit Ethernet Media Converter provides one channel for media conversion between 10/100/1000BaseT/TX to 1000BaseSX/LX/BX with Link Fault Signaling function. It can be used as a stand-alone device or with a standard 19” chassis as shown below. Product Overview Gigabit Ethernet Media Converter with Link Fault Signaling function 4 The chassis is to be ordered separately.
Signamax Gigabit Ethernet Media Converter Product Features Complies with IEEE802.3 10BaseT, IEEE802.3u 100BaseTX, IEEE802.3ab 1000BaseT, and IEEE802.3z 1000BaseSX/LX. Supports IEEE802.3x Flow control: Flow control for Full-duplex and Back pressure for Half-duplex. DIP Switch configuration for “Link Fault Signaling”. Gigabit transmission supports 9K Bytes jumbo frame. 1000Mbps-Full-duplex, 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX. Full wire-speed forwarding rate.
Signamax Gigabit Ethernet Media Converter One-Channel Media Converter Physical Ports Gigabit Ethernet Media Converter This converter provides one TX port and one 1000BaseSX/LX/BX port. For the 1000BaseSX/LX/BX port, it provides options of multimode/singlemode or WDM multimode/singlemode fiber. For the TX port, it uses RJ-45 connector and supports auto MDIX for uplink purpose.
Signamax Gigabit Ethernet Media Converter Installation This chapter gives step-by-step installation instructions for the Converter. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: The ambient temperature should be between 32 and 122 degrees Fahrenheit (0 to 50 degrees Celsius).
Signamax Gigabit Ethernet Media Converter Specifications Applicable Standards Fixed Ports 10/100/1000BaseT/TX to 1000BaseSX/LX/BX: Speed 10BaseT 100BaseTX 1000BaseT/SX/LX/BX Forwarding Rate 10BaseT 100BaseTX 1000BaseT/SX/LX/BX LED Indicators Dimensions Weight Power Power Consumption Operating Temperature Storage Temperature Humidity Emissions 8 IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX IEEE 802.3ab 1000BaseT IEEE 802.
Signamax Gigabit Ethernet Media Converter Contact Information SIGNAMAX CONNECTIVITY SYSTEMS An AESP Company 999 N.W. 159th Drive Miami, Florida 33169, U.S.A. Phone: 305-944-7710 Fax: 305-949-4483 Sales: 800-446-2377 Tech. Support: 800-4462377, ext. 201 Http://www.signamax.com E-mail: info@signamax.
