3.2.19 Storage Manager Table 3-38 Storage Manager ICON ITEM & FUNCTION l “Storage Manager” Tab : (Figure 3-83) To change Storage properties control panel default settings: Insert. Compact Flash(CF) or Secure digital (SD) storage card into the unit. Ø Select Start > Settings > Control Panel > Storage Properties Ø From the “Storage Info” pull-down list, select the desired storage device. Ø You can also format, dismount, and create partitions on storage devices using this control panel.
3.2.20 Stylus Table 3-39 Stylus ICON ITEM & FUNCTION l “Double-Tap” Tab : (Figure 3-86,Figure 3-87) ü Double-tap the checkerboard grip at a comfortable speed. Double-tap clapboard to test your settings The function is OK if the figures are changed from Figure 3-86 to Figure 3-87. To tap “OK” to exit the Stylus Properties.
Figure 3-86 Stylus Properties Figure 3-87 Stylus Properties 3.2.21 System Table 3-40 System ICON ITEM & FUNCTION l “General” Tab : (Figure 3-90) ü To show: Ø Firmware information Ø Information about Processor type, Memory size, Expansion card “Memory”: (Figure 3-91) l Move the slider to adjust memory allocation. Default storage memory is normally is normally set to about 8MB with the reminder assigned to Program memory. ü Press the “OK” key on the Keypad.
ü ü ü Your device uses this information to identify itself to other computers. The input panel will open to facilitate data entry. To close the Device Name , press the “OK” button, or press the key on keypad. l “Copyrights” ü Refer to this tab for specific copyright data. As a user, you are responsible to read this statement.
Figure 3-90 System Properties Figure 3-91 System Properties 3.2.22 Volume & Sounds Properties Table 3-41 Volume & Sound ICON ITEM & FUNCTION l “Volume” Tab : (Figure 3-94) ü The factory default for Volume is the forth level. You can adjust the volume to your environment and comfort.
3.3 Taskbar and Start Menu Table 3-42 Taskbar and Start menu ICON Taskbar and Start Menu ITEM & FUNCTION l “General” Tab : ü In this tab, You can change the position of the Taskbar and Start menu Ø Is always on top or not Ø Auto hide or not Ø Show Clock or not “Advanced ” Tab: l ü ü Tap the “Clear” button to remove the contents of the Documents Menu. Enable “□ Expand Control Panel” to list all icons of Control Panel from top to bottom.
Chapter 4. Communication 4.1 Installing & Setting Up Microsoft ActiveSync 4.1.1 Installing Microsoft ActiveSync on the Host PC Microsoft ActiveSync is a file transfer tool to synchronize the files on a PC with the files on your PDT. To install Microsoft ActiveSync, complete the following steps on the PC: 1. Go to the Microsoft Windows CE.NET website and download the latest current version of ActiveSync: http://www.microsoft.com/mobile/pockeypc/downloads/ . 2. 3. 4. 5.
Only devices that have a partnership with a desktop computer can synchronize information between the two computers. For more information on partnerships, please refer to your Microsoft ActiveSync documentation or help file. Transferring Files: To transfer files, complete the following steps on the host PC: ü Select Start> Programs >Communication > (Serial, or USB) Activesync.
4.2.2 ActiveSync File Synchronization ActiveSync files synchronization requires an ActiveSync partnership between the PDT and the Host PC. Refer to “Setting up a Partnership”, above: ü Select the files in the synchronization configuration for the PDT partnership. ü Select Tools > Options from the ActiveSync command bar to configure the synchronization options. ü Place the file to be synchronized in the Synchronization folder created you’re My Documents directory. Defaults to the desktop.
Chapter 5. Software Applications 5.1 Introduction The PDT includes Calculator, Inbox,… .. You can switch to any software program by tapping the Start Menu. 5.2 Software Applications 5.2.1 Calculator It can process the basic numeric calculation with “+”, “-“ “*” and “/“.
To setup “Inbox”: ü Select Start> Programs> Inbox to open it. ü Select Service> Options from the command bar. Drag the dialog to show the right edge to configure e-mail. ü Select “Add… ” (Note 1) ü In the “Service Type” list, select POP3 Mail or IMAP4 Mail. (POP3 is the most common mail protocol for ISPs).Enter a unique name for e-mail service in the “Service name” field. This name cannot be changed later. ü Select “OK”. ü The Mail Service Setup wizard appears after you add a service.
ü ü address in the box. Set general preferences: If you are adjusting the setting of an existing service, select Service> Options, select the service you are using, select Properties, and then select Next. In the General Preferences dialog box, choose any of the following setting settings, all of which are optional: Ø Disconnect service after actions are performed: Select to automatically disconnect from the server upon completion of all pending actions. This option minimizes connect time and cost.
Ø Ø Ø meeting requests when getting full copies of messages. This setting applies whether you have chosen to download full copies of messages by default, or you selectively download full copies of messages by opening the message and selecting Services> Get Full Copy Limitations apply. Get file attachments (POP3 only): Select to download and save message attachments when getting full copies of messages. This option may use significant RAM and slow download time.
from your mail service or exit Inbox. Ø Immediately: Deletes messages as soon as you select File> Delete. Ø Manual: Deletes messages when you select File> Empty Deleted (local) Note: If you are working offline, messages that have been deleted from the device the next time you connect. ü Empty the Deleted (local) folder: Ø Select File> Empty Deleted (local). This permanently deletes messages in the Deleted (local) folder.
Rename a folder: Ø Select the folder you want to rename. Ø Select File> Folder> Rename Folder. Ø Type the new name for the folder. Notes: l Default folders, such as Inbox, can’t be renamed. l Folders you create for IMAP4 mail servers can’t be renamed. u Synchronize folders while connected: When you synchronize folders, the contents of your device folders and mail server folders are compared and updated. New mail messages are downloaded, and messages in your device Outbox folder are sent.
The message is not sent and is saved in the inbox folder of the active service. ü Reply to or forward a message: Ø Open the message, and then select Compose> Reply to Sender, Reply to All, or Forward. Ø Enter your response. Ø Select File> Send. Tips: l Selections in the Options dialog box determine whether the original text is included. l To see more header information, select the inverted triangle in the lower-right corner of the header area. Select the triangle again to collapse the header area.
Ø full copies of messages by default. When finished, select Services> Connect to disconnect. You also need to disconnect your dial-up connection by double-tapping the icon in the status bar and selecting Disconnect. Notes: l Receiving entire messages consumes storage memory. l The size column in the Inbox list view displays the local size and server size of a message.
connect. You can also set Inbox to download attachments automatically when you get a full copy of a message. For more information, see Receive attachments. Open an attachment: Ø With the message open, double-tap the attachment’s icon at the bottom of the message. If you don’t see this pane, select File> Attachments> Show Attachments. ü Store an attachment: Ø Select Service> Options> Storage tab. Ø Select to store attachments on internal RAM or a storage card.
Figure 5-1 Inbox 5.2.3 Internet Explorer With Internet Explorer, you can view Web or intranet Web pages on your device. You will need to use a modem or WLAN to connect to an Internet server provider (ISP) or network. 5.2.3.1 Connect to the Internet Before you can view Web pages, you must set up a remote connection to your ISP or network. 5.2.3.2 Start Internet Explorer ü Open Internet Explorer by selecting Start > Programs > Internet Explorer.
To achieve more screen real estate in Internet Explorer, you can hide the Status bar and View menu. From the top menubar, go to View > Hide Toolbars. Once it is hidden, you must cold reset to access these features again. Refer to 2.7.2 “Cold Reset “for more information. 5.2.3.4 Set up a proxy server Proxy servers are often used when connecting to the Internet through a local network, such as a corporate network, for added security. ü Select View > Internet Options > Connection Tab.
To view your favorite Web sites, select Favorites and the Web site you want to view. Note: To organize your Favorites list, select Favorites > Organize Favorites. ü 5.2.2.10 Browse Web pages ü To move to a page you have previously view, select View > Back ü To move to the next page (provided you have viewed it previously), Select View > Forward. ü To return to your Home page, select View > Go > Home . 5.2.2.11 Refresh current page ü Select View > Refresh. 5.2.2.12 Stop loading a page ü Select View > Stop.
ü ü Go to the document where you want to place the information and select the location. Select Edit > Paste. 5.2.2.18 Select security Options ü Select View > Internet Options > Security tab ü Select the security protocols you want. 5.2.2.19 Change the font size ü Select View > Text Size and select the desired size. 5.2.3 Media Player The PDT comes with Media Player for Windows CE.NET installed. ü Open Media Player by selecting Start > Programs > Media Player from the desktop.
ü Messenger supports high-quality voice calling r Windows CE device. Communicate using Session Initiation Protocol (SIP) or Hotmail contacts Windows Messenger supports. Communication with your colleagues in the enterprise with a SIP based communications service. You can also talk to your Hotmail contacts using the .NET Messenger. 5.2.
Ø Ø Ø ü a paragraph, enter ^p. For a tab stop, enter ^t. Select the replacement options you want. Select Find Next. On the Find/Replace toolbar, select the appropriate button. Move, copy, or delete text Ø Select the text you want to move, copy, or delete. Ø To move or delete text, select the Cut button. To copy the text, select the Copy button. Ø To paste the information, move the insertion point to the desired location, and select the Paste button. Notes: l To undo an action, select Edit > Undo.
Select desired text. Ø Select the Bold, Italic, or Underline button. Ø To change the color, select Format > Font and select the color you want from the Color list. ü Adjust the paragraph alignment Ø Select the paragraph you want to align. Ø Select the Align Left, Center, or Align Right button. Note: To see more formatting options, select Format > Paragraph. Ø ü Ø Ø Ø ü Ø Ø Indent a paragraph Select the paragraph you want to indent. Select Format > paragraph. Adjust the indentation settings as needed.
ü Ø Ø Assign and change outline levels Select View > Outline. Select the appropriate buttons on the toolbar. 5.2.5.5 Inserting Symbols ü Place the insertion point where you want to insert the symbol. ü Select Tools > Insert Symbols. ü Select the symbol you want, and then select Insert. Tips: If you select a different font ( or subset of a font), a different set of Symbols will be displayed. 5.2.5.6 Printing a Document ü Select File > Print. ü Select the printing options you want.
ü Ø Changes caused by Word document conversion Formatting l Borders and Shading Borders and shading are not displayed in WordPad, but are restored when converted back to a Word document. Shading is not restored when used in a table, but simple borders are restored. l Character formatting Bold, italic, strikethrough, superscript, subscript, and hidden text are retained and displayed. Other effects are changed or removed. l Colors Colors are retained and mapped to colors available on your device.
Ø OLE Objects OLE Objects are removed during conversion. Ø Revisions marks, annotations, and comments Revision marks are visible but cannot be changed. Annotations and documents are removed during conversion. 5.2.6 Remote Connection Using Remote Desktop Connection, you can log on to Windows Terminal Server and use all programs installed on this server. For example, instead of running Microsoft Pocket Word, you can run the desktop version of Microsoft Word. 5.2.6.
administrator has configured Remote Connection to reconnect to disconnected sessions). 5.2.6.3 Disconnecting and Ending a Session ü In the Remote Connection window, select Start > Shutdown. ü Select Log Off > OK. 5.2.7 Windows Explorer Windows Explorer works almost the same on your PDT as it does on your PC. See the topics below for information about the difference in Windows Explorer on your device. 5.2.7.1 Navigating in File View ü Go forwards and Back Ø To go to the previous folder, select Go > Back.
If necessary, open the folder where you want the new folder to reside. Ø Select File > New Folder. Add a folder to your Favorites list Ø Open the folder Ø Select Favorites > Add to Favorites. Ø In the Name box, type the shortcut name. Tips: l To open a favorite file or folder, select Favorites and then select the folder. l To organize your favorites, select Favorites > Organize Favorites.
5.3 DiskOnChip The DiskOnChip let the application or a data file can be stored into the Flash Memory. Note: The DiskOnChip storage memory persists all reset (warm/cold reboot) conditions and software/firmware updates. We strongly recommends installing all applications, applets, programs, and important data files to the DiskOnChip Flash location. Caution: If an application or a data file is only installed or saved in RAM, a hard reset will result in the loss of that application or data file. 5.3.
Figure 5-6 DiskOnChip 5.3.3 DiskOnChip Size The size of the DiskOnChip will vary, depending on the size of system firmware. ü Inside the DiskOnChip directory, tap File > Properties. ü The DiskOnChip Properties dialog: The number following Free is the amount of memory currently available on your device.
