User's Manual

- Compact size 88 keys slim wireless multimedia keyboard
- Totally Wireless freedom
- 34 two way R F channels
- Keyboard about 6~10 meters operation range
- Keyboard come with 6 hotkeys
- Optical tracking engine, no moving parts
- Nano receiver for this combo set
SK020AG RF2.4GHz Optical Keyboard
SPECIFICATIONS
Pa r t 1. 0 : Ge n er a l Fe a tu r es
Pa r t 2. 0 : Ph y si c al c h ar a ct eri sti cs
Mechanical Performance
Buttons and indicator:
Weight:
Keyboard: 490 10 g (2*AAA battery included)
Receiver: 2 1 g
Pa r t 3. 0 : El e ct r ic a l Sp e ci fic ati on
Interface : USB 1.1
Sensor report rate on mouse: 3000 times per second
Operation angle: 360 degrees
Operation distance: 6~10 meter for keyboard
Receiver power requirement: 5V DC from USB port
Battery
Battery type: two AAA alkaline for keyboard
Battery consumption:
Pa r t 4. 0 : Re l ia b il i ty
Operating temperature: -5 - 40 degrees celsius
Operating humidity: 20% - 90%
REV: 1.00
Pa r t 5. 0 S ys t em R e qu i re m en t
Windows 2000, Windows xp. Windows ME.
Windows VISTA,Windows 7
Operating force of keyboard keycaps
70 15gf
Keyboard Button Switch Activation: 8,000,000 cycle
Keyboard:Operating Mode: 8 mA
Sleep Mode 1: 0.2 mA
Receiver
Keyboard
R F frequency: 2.4 Ghz (2.408~2.474 GHz)
R F modulation : F S K
Hopping type : FHSS (frequency hopping spread
spectrum)
R F channel : 34 channels
ID numbers: 24 bits
R F bandwidth : 2.0 MH Z
R F output power : 1 mW
Sensor Tracking Speed: 30+ inches / Second
SK - 02 0 AG
Keyboard : 88 standard keys, 6 hotkeys ( www, favorite,
Email, sleep,Media, play/pause )
2 Red LED for caps lock and num lock
