User manual Please read and understand this manual before attempting installation of the product. X Series User Manual Jan, 2015 V1.
User manual Statement If the user manual doesn’t help you to solve the problem, please call our technology center for technical support. Notice 1. Installation Environment Keep away from the places for high-temperature, heat source and direct sunlight; Keep away from water and if wet, power off immediately. Avoid using in the damp environment; the reference range for operation humidity is below 85%RH.
User manual Index 1 2 3 4 5 Product Introduction ............................................................................................................... 4 1.1. Product Overview ....................................................................................................... 4 1.2. Product Exposition ..................................................................................................... 4 Device Connection ......................................................................
User manual 1 Product Introduction 1.1. Product Overview Thank you for choosing X series high definition SmartP2P IP Camera, the IP Camera combines a high definition digital video camera with network connectivity and a powerful web server to bring high definition video to your desktop from anywhere on your local network or over the Internet. It includes indoor HD PTZ camera, indoor HD cube camera, outdoor HD waterproof camera etc. It is very suitable for home, shops, offices and so on.
User manual lens for best effect if the video is fuzzy; PTZ: Control PTZ remotely, view video from several vision angle.
User manual 2 Device Connection 2.1. Connection Diagram IP Camera Router IP Camera Internet Computer Smartphone Local Network Figure1 Power on the camera by attaching the power adapter, and then connect the camera and router by network cable, so you can visit the camera via computer in LAN and view camera video as <<3. View video by browser>> You can also connect camera and router by Wi-Fi, you need to configure Wi-Fi of the camera as<<2.2 Wi-Fi Setting>>. 2.2.
User manual always on. Notice: Due to some router do not support WPS/QSS function, so you can not use the configuration way. Figure2 2.2.3. Mobile Phone Setting Install the iSmartViewPro App in android phone or iPhone at first,Open the App, access to More interface, select “One key configure Wi-Fi” and fill in Wi-Fi SSID and password, and then click configure to finish the setting as Figure3.
User manual 3 View Video by Browser 3.1. Access to camera webpage and install Plug-in Double click to Open the “SearchPro” in the attached CD and click Search as Figure4. Figure4 Select the founded device and double click it to open to view in the browser, enter user name and password at popup dialog to login camera webpage as Figure5. Tips: default username/password:admin/12345, please modify the password for safety.
User manual Figure6 3.2. View Live Video Access to Live Video interface, it plays video automatically as Figure7.
User manual 4 Query and Playback SD Record by Browser 4.1. Playback Video Click Playback Video to access to SD record playback interface, click record date which you want to query ,click Search to list recording file, select one to playback it, also can click download button to download the file as Figure8. Figure8 5 Device Configuration and Local Setting 5.1. Device Configuration 5.1.1. System 5.1.1.1.
User manual Figure9 5.1.1.2. Time Setting Figure10 5.1.1.3. PTZ Setting You can set up PTZ speed, cruise circles (1-10 turns) and disable motion detection when PTZ moving as Figure11.
User manual 5.1.1.4. Other Setting You can turn off the status LED of the camera and Wi-Fi status LED in other setting as Figure12. Figure12 5.1.1.5. System Maintenance The system maintenance includes system setting and timing reboot setting. You can set up reboot, backup setting, restore backup setting, upgrade camera and timing reboot etc as Figure13. Figure13 5.1.1.6.
User manual 5.1.2. Network 5.1.2.1. IP Address Setting You can modify IP address of the camera etc, the default is DHCP,achieve automatically as Figure15. Figure15 5.1.2.2. Port Setting You can change webpage http port here as Figure16. Figure16 5.1.2.3. Wi-Fi Setting Click Search, and switch on enable Wi-Fi, select the wireless router you want to connect, enter password of the router, click Save to finish the Wi-Fi configuration.
User manual Figure17 5.1.2.4. Port Forwarding Access to port forwarding, you can enable UPNP port forwarding and check the status of it as Figure18. Figure18 5.1.2.5. DDNS Setting You can enable manufacturer’s DDNS and set up third party DDNS (the third party DDNS support 3322.org/Dyndns.org/No-ip.com now, the manufacturer provide a free DDNS for every camera.
User manual Figure19 5.1.2.6. RTSP Setting You can set up RTSP port, also can close RTSP authentication as Figure20. Figure20 You can view video by some general RTSP stream media software, for example, VLC. The visit link as below: First stream:rtsp://user:password@IP:rtsp port/live/ch0 Second stream:rtsp://User:password@IP:rtsp port/live/ch1 Third stream:rtsp://user:password@IP:rtsp port/live/ch2 5.1.2.7.
User manual 5.1.2.8. SMTP(E-mail)Setting Please fill in relative parameters as the following case to achieve the E-mail transfer, as Figure22. Figure22 5.1.3. Audio and Video 5.1.3.1. Video Encoding Setting Access to Video Encoding setting, you can set up AC frequency and video stream as Figure23. AC frequency: 50HZ and 60HZ optional; Video stream: Bit rate(256~4096kbps),frame rate(1~30fps)、video encoding control etc; Tips: you can set up the video with audio or not.
User manual Figure23 5.1.3.2. Volume Setting Access to Volume setting, you can adjust the volume of MIC and speaker as Figure24. Figure24 5.1.3.3. Image Setting Access to Image Setting, you can flip and mirror the image, also can adjust the brightness, contrast, saturation and hue of image for getting best color effect as Figure25. Figure25 5.1.3.4. OSD Setting Access to OSD setting, you can overlay the time and name in Live video as Figure26.
User manual Figure26 5.1.3.5. Night vision Settings Access to Night vision Settings, you can set up IR LED and IRCUT as Figure27. Figure27 5.1.4. Safety Access to User management, you can add or edit the user as Figure28. Figure28 Tips: After setting up, click save and refresh button, the entering info will display in the webpage. 5.1.5. Alarm 5.1.5.1. IO Detect Access to IO detector, can enable detect function and set up input signal type as Figure29. Figure29 5.1.5.2.
User manual Figure30 5.1.5.3. Audio Detection Access to audio detection, you can enable audio detection and set up sensitivity of it as Figure31. Figure31 5.1.5.4. Linkage alarm setting You can set up IO detect, motion detection and audio detect, it can linkage to trigger the action: snapshot to Email or FTP server or SD card, recording to FTP server or SD card, and trigger IO output as Figure32.
User manual Figure32 5.1.5.5. Protected duration setting After setting up alarm detect type and alarm trigger linkage, you need to set up protected duration. You must set up it, then the camera perform trigger linkage; the time format is 7 days, 24 hours per day, 15 minutes per a block as Figure33. Figure33 5.1.6. Storage 5.1.6.1. SD Management Access to SD management, you can check and download recording and snapshot file in SD card, and check SD card remaining capacity, format SD as Figure34.
User manual Figure34 5.1.6.2. SD card snapshot setting(Timing Snapshot) Access to setting of timing snapshot to SD card, you can enable SD snapshot, you can set up snapshot time interval and snapshot duration; time format is 7 days, 24 hours per day, 15 minutes per a block as Figure35. Figure35 5.1.6.3.
User manual Figure36 5.1.7. Log Access to Log menu, you can check the user operation log as Figure37.
User manual 5.2. Local Setting Access to local setting, you can set up recording path, snapshot path and recording duration as Figure38. Tips: You must use administrator to run the browse, then recording path and snapshot path can be save successfully at above IE9; the default recording path is D:\HYRec,snapshot path is D:\HYSnap. You can enable show motion detection frame when viewing video.
User manual FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
