Microwave Motion Sensor MC613V D RC Version: A0 SPECIFICATION Product Name: Microwave Motion Sensor Model No.: MC613V D RC Issue Date: January 30, 2018 CUSTOMER APPROVED PRODUCT DIRECTOR APPROVED SALES CHECKED R&D CHECKED PREPARED Shenzhen Merrytek Technology Co.,Ltd Add: 2nd and 3rd floor, NO.3 Building, 380 Xiangshan Avenue, Luotian, Yanluo, Baoan, Shenzhen, 518127,China Tel: +86 (0)755-2305 7253 Fax: +86 (0)755-2786 3012 Website: www.merrytek.
Microwave Motion Sensor MC613V D RC Version: A0 1. Features 1. Built-in motion sensor and daylight sensor for Intelligent control 2. Attachable design ,suitable for more luminaires 3. 1-10v port can match dimmable driver to achieve corridor function 4. Dim+/Dim- to set occupancy light level 5. All sensor Parameters can be set by DIP switch or Remote 6. North American version for linear & batten lights 7. With Ambient learning function 8. 5 years warranty 2.
Microwave Motion Sensor Environment MC613V D RC Version: A0 Storage Temperature Temperature: -40℃…+80℃; Humidity: 85% (non-condensing) Safety standards EN61058-1,EN61058-1-2,UL60730 Certificate EMC standards EN55015,EN61547,EN6100,EN301489,EN300440 Standards Environmental Requirement Compliant to RoHS Certificate CE, RED, UL Wiring Method Copper wire only (10-18AWG) IP Rating IP20 Protection Class Class II Installation Built-in installation (indoor use only) Dimension Inch;3.
Microwave Motion Sensor MC613V D RC Version: A0 3) 3-step dimming function (stand-by period be set to “10s/1min/3min/5min/10min/30min”) 4. Dimension (mm) Detachable sensor head: Main part 5. Wiring 6. Structure a Shenzhen Merrytek Technology Co.,Ltd Add: 2nd and 3rd floor, NO.3 Building, 380 Xiangshan Avenue, Luotian, Yanluo, Baoan, Shenzhen, 518127,China Tel: +86 (0)755-2305 7253 Fax: +86 (0)755-2786 3012 Website: www.merrytek.
Microwave Motion Sensor MC613V D RC Version: A0 7. Detection Pattern Ceiling mounting Ceiling mounted height: 3m Ceiling mounted height: 6m Sensitivity: 100%/75%/50%/25% Sensitivity: 100% Normal moving (Speed:1m/s) Normal moving (Speed:1m/s) Slow moving (Speed 0.3m/s) Slow moving (Speed 0.3m/s) *Only 100% detection sensitivity is workable when installed at 6m mounting height. able to detect motion signal. 8. Remote Control Shenzhen Merrytek Technology Co.,Ltd Add: 2nd and 3rd floor, NO.
Microwave Motion Sensor MC613V D RC Version: A0 9. DIP Switch Setting Detection Area 1 2 Ⅰ ON ON 100% Ⅱ ON - 75% Ⅲ - ON 50% Ⅳ - - 25% 3 4 5 Ⅰ ON ON ON 8S Ⅱ ON - ON 30s Ⅲ - ON ON 1min Ⅳ ON - - 5min Ⅴ - ON - 10min Ⅵ - - ON 15min VⅡ - - - 30min 6 7 8 Ⅰ ON ON ON 0s Ⅱ ON - ON 1min Ⅲ - ON ON 3min Ⅳ ON - - 5min Ⅴ - ON - 10min Ⅵ - ON 30min ⅤⅡ - - +∞ Hold Time Stand-by Period - Shenzhen Merrytek Technology Co.
Microwave Motion Sensor MC613V D RC Version: A0 Stand-by DIM Level Stand-by DIM Level S1 S2 Ⅰ ON ON 10% Ⅱ ON - 20% Ⅲ - ON 30% Ⅳ - - 40% Daylight Sensor S3 S4 S5 S6 Daylight sensor ON ON ON ON 5Lux - ON ON ON 15Lux ON - ON ON 30Lux - - ON ON 50lux ON ON - ON 100lux ON ON ON - 150lux - - - - Disable 10. Initialization 1) On/Off function /3-step dimming function: After power on, the sensor automatically turns on light at 100% brightness.
Microwave Motion Sensor MC613V D RC Version: A0 11. Factory settings Detection area: 100%, Hold time: 8s, Stand-by Period: 0s, Stand-by dim level: 10%, Daylight Sensor: Disable 12. Application Notice 1) The sensor should be installed by a professional electrician. Please turn off the power before installing, wiring, changing the setting of the DIP switch. 2)The sensor is installed in the plastic, the glass lampshade will reduce the sensitivity of the sensor.
FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
