User's Manual

PS2-7002 2.4GHz Wireless Controller

Instruction Manual

Brief Introduction

Thank you for purchasing our PS2 2.4GHz Radio Frequency Wireless Controller. Along with

our highest manufacturing standards and testing throughout its development, we ensure you

could get the best possible product. To make it fully fits your Playstation®2 Console, please

review this user’s instruction manual carefully for operation.

Regulation Statement

The users manual or instruction manual for an intentional or unintentional radiator shall

caution the user that changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

The antenna(s) used for this transmitter must be installed to provide a separation distance of at

least 20 cm from all persons" for the host device, and specify "The antenna(s) used for this

transmitter must not be colocated or operating in conjunction with any antenna or transmitter

other than those contained in this device."

Characteristic

1, Applicable for Sony Playstation2 Console and various of software the console supported;

2, Available for vibration function with two built-in motors, and Non-vibration function

without motor built-in.

3, All game software supported with Digital mode and Analog mode, performed by Red LED

4, Special device of low power consumption feature;

5, Turbo/Macro function, performed by Green LED

6, Alarm function for lower voltage;

7, FC function (Short for “Force Connection”) between the appointed controller and the

appointed receiver;

8, Available over 7 meter straightaway range;

9, Available 20 RF controllers playing at the same time within valid range;

10, Working voltage: 3.5V – 7V (4 X AAA batteries)

PAGE 1
PS2-7002 2.4GHz Wireless Controller Instruction Manual Brief Introduction Thank you for purchasing our PS2 2.4GHz Radio Frequency Wireless Controller. Along with our highest manufacturing standards and testing throughout its development, we ensure you could get the best possible product. To make it fully fits your Playstation®2 Console, please review this user’s instruction manual carefully for operation.
PAGE 2
Buttons Layout Connection and Installation 1, Insert the receiver to the socket of Sony Playstation2 Console and turn on the power. 2, Place the 4 X AAA batteries inside the controller first, and move the switch to the position of “ON”. 3, The LED of receiver is flicker under connecting, and will last for light when connecting. Function Description 1, Low Power Consumption Mode To save the power consumption, there is a special “sleeping mode” built into this controller.
PAGE 3
1) PROGRAM sourcing buttons includes: ○, X, □, △, L1, L2, R1, R2, D-PAD 2) The programmable buttons includes: L2,R2,L3,R3. 3) At most 15 times input of sourcing button can be programmed into each programmable button. 4) The latest program setting can be saved once power off. 5) Select button is used as separator when input the same sourcing buttons to set up the program. 6) PROGRAM method: A. Press MACRO buttons for 3 seconds, the green LED is on. B.
