Owner’s Manual

WiFi/DLNA/Spotify/Internet Radio/

DAB/DAB+/FM/AUX/Bluetooth

M2+ Table Internet Radio

Table of content

1 Introduction

1.1 Safety

1.2 Features

1.3 Carton contents

1.4 External resources

1.5 Conventions used in this manual

2 Controls, connectors and display

2.1 Main controls

2.2 Connectors

2.3 Screens

2.4 Operation

2.5 Menu navigation

3 Started and setup

3.1 Setup wizard

3.2 Other settings

3.3 Internet radio portal registration

3.4 Setting up a music server

3.5 Sharing media with Windows Media Player

3.6 Setting up M2+ for “Play To” Windows 7 streaming media feature.

4. Internet radio mode

4.1 Last listened

4.2 Presets

4.3 Favorites

4.4 Browse

4.5 Search

4.6 My added stations

4.7 Now playing information

5. Spotify Connect

6. Music player mode (network)

6.1Shared media (from UPnP media server)

…… …………………………………01………………

…… …………………………………02………………

…… …………………………………03…………

…… …………………………………03……

…… ………………………03……

…… … ………………………………03…… …

…… … ………………………………05…… …

…… …………………………………06………

…… …………………………………07………

…… …………………………………08………

…… … ………………………………09…… …

…… …………………12………………………

…… …………………13…………

… … ……………15……… ……

… 15……………………

…16

…… …… ………………………18…… ………

…… …… ………………………17…… ………

…… …… ……………………………18…… ………

…… …………………………18……………………

…… …… ……………………………19…… ………

…… … …………………19…… ………………

…… … …………………20…… ………

…… ………………20……………………

…… …………………………21……

…………………………21

Summary of content (10 pages)

PAGE 1
Table of content 1 Introduction Owner’s Manual …… ……………… …………………………………01 1.2 Features …… ……………… …………………………………02 1.3 Carton contents …… ………… …………………………………03 1.4 External resources …… …… …………………………………03 M2+ Table Internet Radio …… …… ………………………03 2 Controls, connectors and display …… …… ………………………03 …… …… … … ………………………………03 2.1 Main controls 1.1 Safety 1.5 Conventions used in this manual WiFi/DLNA/Spotify/Internet Radio/ DAB/DAB+/FM/AUX/Bluetooth 2.2 Connectors …… …… … … ………………………………05 2.
PAGE 2
6.2 USB playback 6.3 Playlists 6.4 Repeat/shuffle …… …………… ………………………………23 …… …………… ………………………………23 …… …………… ………………………………24 6.5 Now playing information …… … ………………………………24 7 Using the “Play To” feature in Windows 7 to stream media 7.1 Use “Play To” in Windows Media Player 7.2 Use “Play To” elsewhere in Windows 7 ………24 …………………………24 ……………………………25 …… …… ………………………………25 8 DAB radio mode …… …………… ………………………………25 7.3 Now playing information 1. Safety 1.
PAGE 3
Ÿ Do not put it in a closed bookcase or a cabinet that may keep air from flowing through its ventilation openings. Ÿ Remote control from an Android or iOS Smart Device, using Spotify App or Ÿ Do not install near any heat sources, such as radiators, heat registers, stoves or other appliances that produce heat. Ÿ Clock with auto-update capability and dual independent alarms Sleep/snooze.
PAGE 4
7. BACK/MENU: a. BACK: press the BACK to return to the previous screen. b. MENU: press the MENU to show the MENU for the current mode. Press again to show now playing screen. 1 8 3 6 9 11 4 10 7 5 2 8. PRESET: Long press 1,2,3,4,5+ to preset and save the favorite stations (save 20 favorite stations); Short Press to 1,2,3,4,5+ to select the favorite station or Preset recall. You can preset 20 stations by press 5+ and by scroll the preset list to achieve. 9.
PAGE 5
Ÿ 1.DC power in (14V) 2.Power switch (ON/OFF) 3.LAN for Ethernet connect 4.USB socket for USB stick with MP3 music playback (not for charging). Now playing screens show information about the audio source and track 5.Headphones out. 6.Line out (to connect to an external amplifier) now playing, where available. 7.Aux in (to connect external media like iPod) 8. B attery compartment: open compartment to find the Battery. 2.
PAGE 6
input. See the relevant Mode section for details of how to use each listening mode. -connected modes such as Internet radio, you also need a broadband Internet connection. The Common local controls for sound volume, Mute and Play/Pause are available in all listening modes. 2.5 Menu navigation The primary control for moving through menus and options is the Select Control. Rotate the control to move up or down a menu. Once the required option or value is highlighted press the Select Control.
PAGE 7
use regularly. DAB and FM use time signals broadcast with radio transmissions. Network uses a time signal sent from the Internet radio portal when in any network-connected mode. 1.Select Update from DAB, Update from FM, Update from Network or No update. 2. If you are updating from the network, set your time zone. 3. If your country uses daylight saving, the automatically updated time from the network may be wrong by one hour.
PAGE 8
Ÿ Pin > (code number) 3.2.2 Network M2+ generates an 8-digit code number which you enter into the wireless router, access point. M2+ remembers the last four wireless networks it has connected to, and automatically tries to connect to whichever one of them it can find. You can see the list of registered networks through Menu > System settings >Network > Network profile >From here you can delete unwanted networks by turning and pressing Select then confirming delete Yes.
PAGE 9
Ÿ Ÿ Ÿ Ÿ access code, your e-mail address, passphrase, radio model (M2+). If you already have an account and wish to add an additional radio, log in to your account and select My preferences > Add another Wi-Fi radio. Once your radio is registered with the portal, you can immediately use the Internet radio favorites and added stations features. 3.4 Setting up a music server In order for M2+ to play music files from a computer, the computer must be set up to share files or media.
PAGE 10
*) To change the name of your device, right click on icon and choose properties. Then choose UPnP and click on “device webpage”. 4. Internet radio mode M2+ can play thousands of radio stations and podcasts from around the world though a broadband Internet connection. When you select Internet radio mode, M2+ contacts the Frontier Silicon Internet radio portal to get a list of stations, organized into different categories like Country, Most popular and Genre.
