User's Manual

AVERTISSEMENT

PRECAUTIONS

MODEL NO : WM-737

Thank you for buying our company product. Please read through these

operation instructions. So you will know how to operate your model

properly. After you reading it, put them away in a safe place for future

reference.

- To prevent fire or shock hazard, do not expose the unit to rain or

moisture.

To avoid electrical shock, do not open the cabinet.

- Refer servicing to qualified personnel only.

- Do not drop or give any physical shocks to the wireless microphone.

- Do not use the system where it may be subjected to : direct or

indirect sunlight, excessive heat from radiators or other heat sources,

excessive dust or humidity, mechanical or other vibrations.

- Should any liquid or external object fall into the unit, disconnect the

unit from the power source and have it checked by qualified

personnel before operating it any.

- If you have any questions or problems concerning this system which

are not covered in this manual, please consult the nearest company

dealer.

- Be sure to bring the wireless microphones and thereceiver (the

whole system) to the company dealer when requiring repair work.

OPERATION INATRUCTIONS

WIRELESS MICROPHONE SYSTEM

Applicant

: Shen Zhen JWL Electronic Co., Ltd.

FCC ID: PVDWM-737

PAGE 1
Applicant: Shen Zhen JWL Electronic Co., Ltd. FCC ID: PVDWM-737 MODEL NO : WM-737 OPERATION INATRUCTIONS WIRELESS MICROPHONE SYSTEM Thank you for buying our company product. Please read through these operation instructions. So you will know how to operate your model properly. After you reading it, put them away in a safe place for future reference. AVERTISSEMENT - To prevent fire or shock hazard, do not expose the unit to rain or moisture. - To avoid electrical shock, do not open the cabinet.
PAGE 2
OPERATION: 1. Remove the battery cover of handheld or body-pack transmirrer, put a 9 volt battery in she compartment as the polarities and then close the cover. (if a body-pack transmitter is used, you should put a 3.5 plug of a headset or tie-clip microphone into the 3.5 jack on the transmitter.) 2. Connect the matched adapter to the AC power and plug the DC plug at the other end into the DC jack on the receiver. 3. Put one end or the matched connecting wire 6.3MO.(P)/6.3MO.
PAGE 3
Receiving system S/N Ratio Image and Spurious Rejection Power supply TROUBLE SHOOTING GUIDE The on air Indicator does Not light The wireless microphone is not turned on. Turn on the wireless microphone The microphone receiver is not turned on. Turn on the microphone receiver and the connected AV equipment The microphone receiver is not connected Properly. Turn on the microphone receiver and the connected AV equipment The battery in the wireliss microphone is weak.
