1. About subsystem Requirement The minimum configuration of the computer switch connected with the machine as follows: Pentium processor of 2.
2. Start to use 1.3 Function Introduction of Related Key image | Button Name | Function Introductions 52 Power key Long press to open / close power, short press fo open / close IR lamp. oO Mode key Switch camera / photo / playback / setting mode 88 stand for the wane camera mods, IS stand for camera mode [BF] stand for playback made, "setting" stand for setting mode.
2. Start to use Attention! Please install the battery correctly, otherwise it will damage the camera 1. Move the battery compartment switch 0 or cause accident! do not use forward to open the battery door non-standard charger power of adapter for the camera is: AC 3. Push the battery door up 2 Install the battery into the battery compartment as shown 2.2 install battery install the matched lithium battery in the battery cabin according to the direction in picture 1.
2. Start to use 2.6 Instructions on the use of the remote control {optional accessories) 2.6.1The machine besides can use keystrokes, you can also use the remote control equipped with remote control: 1.Photo shooting key: Photo shooting in photo mode 2.Rec. Key : Record /stop recording in video mods 3.IR light key: Turn the IR light / off 4 Page right key: Turn the file right in all modes 5.Page left key: Turn the file left in all modes 8.Enter: Confirm the function 7.
2. Start to use 2.7 Connect to computer Help you to connect the machine to the computer in order {o transmit the document, watch and edit the video and the photo; see the picture. L/ Connect the terminal and the standard USB interface of the computer. Connect the terminal and the standard USB (5 interface of the machine. 2.8 Connect to standard television As shown, the camera can be connected to a TV Set, to display video or photo file Connect the terminal and the HD interface of the standard TV.
2. Start to use : 2.8 Use an external microphone{optional accessories) 1. This machine supports external microphones ,Can effectively reduce the picked up ambient noise improve video quality to give users a better audio experience. Please read carefully before using the external microphone about its characteristic, technical parameters, functional operation, Instructions and dos and don't for avoiding damaging to the machine. 2.
2. Start to use The chapter assist you to be familiar with this machine 2.10 Video Recording mode Shoot video clip according to the video mode and store in the internal memory or memory card. The meaning of icon in video recording mode as show: 1.REC.Mode indicator scene mode indicator | 7.Memory card indicator 2.Image quality indicator | 5.Frame indicator 8.Battery indicator 3.Exposure indicator 8. Rec. time indicator 9.iR light indicator 12345 6 2.
3.Use the camera 3 2.12 Zoom function The camera with zoom function, zoom in by sliding the [Zoom Key J to right side. Zoom out by sliding the [Zoom Key] to left side. 2.13 Use the IR light The camera bully-in IR light, it can make light compensating in a dark environment. In video recording or photo shooting mode, press the [Power Key] to turn on/off the light, the icon will show on the screen. The machine sterns night vision mode.
3.Use the camera : 3.1.3 Metering function This function can meter the mode you need in any environment 1. Press the [Menu Key] to call out the menu option in the shooting mode. Press [UP/Down Key] to choose the “Metering” option. 2. Press [OK Key] to enter sub menu. 3. Press [UP/Down Key] to choose: Center/ Multi Spot, press [OK Key] to save and back to photo metering mode. 3.1.
3.Use the camera i 3.1.8 Continuous shooting settings This function permits the user to set the number of the continuous shooting photo for having a perfect one. 1.Press the [Menu Key] to call out the menu option in the shooting mode. Press [UP/Down Key] to choose the “continuous shooting” option. 2. Prass [OK Key to enter sub menu. 3.Press [UP/Down Key] to choose: off /5/10, press [OK Key] to save and back to Continuous shooting mode. 3.1.
3.Use the camera 3.2.2 Photo quality settings This machine permits the users to choose different quality video, the better the duality is, the clearer the video will be. 1.In video shooting mode, press [Menu Key] to call out menu, press [UP/Down Key] to select "Photo quality” menu. 2.Press [OK Key] to enter sub menu. 3.Press [UP/Down Key] to select: super/good/normal. Press [OK Key] to save and back to Photo quality mode. 3.2.
3.Use the camera 3.3 Playback mode Play back the photo or watch the video on the machine at the shooting or video mode. Protect, revolve, delete and use Pict Bridge interface to print the photo from the machine: protect and delete the video document. 3.3.1 Play back the photo and related operation ‘You may do in play back preview photo mode: 1. In play back preview photo mode: press left [W key 1 to enter the nine character preview mode 2.
3.Use the camera 3.3.2.1 Protect (To protect the video files from deleting by accident.) 1. Press the [ Menu Key] to call out the menu option in the play back mode, Press [UP/Down Key] to choose Protect” option. Press [OK Key] to enter sub menu. 2. Press [UP/Down Key] to choose: lock this/ unlock this/ lock all unlock all. 3. Press [OK Key] to confirm operation with pressing the [OK Key] and back to the Protect mode. 3.3.2.2 Deletes (This function deletes one photo or deletes all photos on teems) 1.
3.Use the camera : 3.4.5 Date and time settings This function permits the users to set the date and time. 1. Press [UP/Down Key] to choose the “Date and time” menu, press [OK Key] to enter the sub menu. 2. Press the [Four directions Key] to adjust, press [OK Key] to confirm and save the back to the date and time setting mode. 3.4.86 TV output settings To set a compatible TV output mode when connecting the camera with TV set 1.
4.Appendix 4.1 Technical § pacification Sensor 800-megapixel COS sensor, Up to 24 million pixels (interpolation) Sensibly Alta, ISOBAR, IBO, 180200, 180400 Singaporean media class 6 SD/SDHC card or higher ,max memory 32GB Lens Lens fixed Focus Range Normal 0.
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
