Instuction Manual – English 1. ICONS: New email Airplane Mode on USB connected USB debugging connected Return button Downloading Display options of a Home button selected function Battery Level WIFI connected, internet is available 2 Quick Start Guide 2.1 Keys Function Power button Short press to sleep/wake up, long press to startup and shutdown.
HOME button (home) Click it in any interface will return to main interface. click it in any interface will return to previous menu Back button(back) This button will display in menu interface. App button Touch this icon to access options of a selected function Menu button 3.0 Home Page Main interface as below, long press the blank and it will popup windows to set wallpaper. Search App button 3.
Before transmitting documents, you have to conduct storage configuration for your Phone: 1) Connect the Phone and computer by USB cable, the reminder column will show the remind information. 2) Open the reminder board; please view the Phone status and reminder to learn how to open the board. 3) In the reminder board, click the “USB Connected”, then click “Turn on USB storage configuration”. 4) Now the USB is connected successfully. 3.2 Copy the document into memory card 1.
Click settings in main menu, choose SIM Management 4.1-2 Messaging Click settings in main menu, choose SIM Management, click message, choose the defaulted SIM card when sends message, 4.1-3 Data Connection Click setting application in main menu, choose SIM management, click data connection, choose the defaulted SIM card, 4.2 Wireless and Internet 1. Connect Wi-Fi 1) In the main menu or interface, choose setting application procedure.
3) Click user name already saved, click connect to use network 3. Network Notice If you open Network Notice, when WIFI signal appears, the right bottom will remind you available WLAN network. 4. Keep WI-FI on during sleep 1) Click icon, select advanced. 2) Click Keep WI-FI on during sleep. 4.3 Bluetooth Bluetooth function operation 1) Click setting application in main menu interface. 2) Click Bluetooth and open it.
5) After match successfully, choose the operation you want to, click 4.4 Data Usage Check SIM card data usage as below Check WIFI data usage Click icon in right top as above, click Data Usage, to enter into.
4.
Choose connect type Remark: (CMWAP transmitters data through GPRS, the webpage it visit belongs to wap webpage, and CMNET support www browse mobile phone network, it can also log in webpage in computer. And the charges are also different.
4.6 Storage Open setting function, click memory, click preferred install location, you can choose install new application to choose preferred install location. Check SD card and Phone storage space. 1. Enter into setting application. 2. Click storage, check storage space. Phone storage 1) System storage System storage is the space Phone leave For system file, it can’t be viewed.
2) Internal storage Internal storage is Phone local NAND storage, if you need to check the storage content, you can check it in main menu.
You can check storage space, SD card available space, unmount SD card and erase SD card Safely remove SD card 1. Click setting application. 2. Click storage. 3. Click unmount SD card. 4. Now you can remove SD card safely. Note: Removing SD card safely can protect SD card and increase its lifetime. 4.
4.8 Application program 1. Click setting application in Apps. 2. Select application, after enter, you can manage and delete installed application and check system used storage space and left space. 3.
4. View the working device, used space and available space 4.
1) Access to Mode Open access to my location, you can activate High accuracy, Battery saving and Device only. 2) Recent location requests You can view the recent location requests. 3) Google location reporting Know about location reporting and location history. 4.10 Safety setting Set locked screen Lock the touch screen by unlock icon or password to protect your Phone.
1) Click setting application in main interface. 2) Click Security. 3) Click Screen lock. 4) Click Pattern. 5) The unlocked pattern board pop up, there are nine touch spots, connect 4 points from vertical, horizontal or diagonal direction. move your finger from the screen when finish. The system will record yous new unlock pattern. 6) Click continue. 7) When you see the reminder, enter the unlock pattern, then click confirm. Set unlock PIN code 1) Click setting application in main interface.
5) Enter new PIN code(numbers) and click continue. 6) Enter new PIN code again and click confirm. Set unlock password 1) Click setting application in main interface. 2) Click Security. 3) Click Screen lock. 4) Click Password. 5) Set new password(letters and numbers) and then click continue. 6) Enter the password again and the click confirm. Unknown source 1) In main interface, click setting. 2) Click Security.
4.11 Language and Input Method Click setting, select language and input method, choose language to switch language. 4.12 Backup and Reset Connect WIFI and login your Google account, choose backup my data, system will backup your data into google server. 4.13 Account 1. Select setting application 2.
4.14 Date and Time According to the preset, system will voluntarily apply the date, zone, and time provided by internet. Manual set date, time and zone 1) Click Settings application procedure. 2) Slide down the screen, then click Date & time. 3) Turn off “Automatic date & time”. 4) Turn off “Automatic time zone”. 5) Click Select time zone, then choose the zone lists. Slide down the list to view more zones.
4.15 Scheduled power on & off 1) Click Settings application procedure 2) Click fixed-time power on and power off. 5 Multi-Media 5.1 Music Enter into music player: in menu or desktop click music icon to enter into music player, click the music you want to play Drag the progress bar to adjust play progress. Operation of music player button 5.2 Video Enter video player: choose application in main menu, choose the video you want to play. 5.
View pictures Click application in main interface. Enter into Gallery; click the folder you want to view. Click the picture you want to view; the system will play it in full screen mode automatically. The pictures can be zoom in and zoom out, put two fingers on the screen, the separate the fingers (gather up the fingers, the picture will be zoom in) or double click the screen. Note: when you browse the pictures, slide left or right to view more pictures. 5.
Enter into channel list Save button Current Frequency Next channel Previous channel Save channels: Click button in the main interface to save the channel, and the channel will be saved in channels list. Note: You need to insert earphone as antenna when using FM radio, if no antenna, your phone can’t search any frequency band. 6 Communication Function 6.
Call log Contacts Delete Enter call log dial Speed Dial, People 6.2 Text Message 1) Enter into main menu, choose application procedure. 2) Click “Edit new message” 6.
Search contact: click Add contact: click button, enter into search function button, enter into add contact interface. 7 Internet 7.1 Browser In case of Wi-Fi or mobile internet is connected well, click IE browser in the main menu or desktop to enter the IE interface. 7.2 Email Email application procedure contains email setting guide, you can add the external POP3 OR IMAP email account of normal web email service provider (For instance, Yahoo, Gmail, Hotmail and 163).
a. Email Setting 1. After you click the sending email icon can help you to set. , you can see the email setting guide, which 2. Input your email address and password. 3. Click “Next step” button, choose your email type is POP3 or IMAP. 4. Click “Next Step” button to check whether the email box servicer can receive or send emails 5. Input the email account and display the email subiject, and click finish. 6. If the email box is available, you will enter into your mail box automatically. b.
8 Other Application Procedures 8.1 Clock Click , enter into below interface. There are alarm clock, timer and stopwatch buttons.
8.2 Calculator 1) Click . 2) Enter into the basic board of calculator. 3) Soft touch the numbers or operator in calulator to calculate. 8.3 Sound Recorder In the main interface or desktop, click recorder icon record key to start record. Click Stop key to enter into record interface, click to stop recording. Click Play key to play the recorded sound. The system will auto remind you to use or abandon this record, please choose it manually.
1) Click 2) Enter into the calendar interface. 3) You can use Calendar to create events . 8.5 To Do 1) Click 2) Enter into the To Do interface. 3) You can create the note you need to do to remind you . EC COMPLIANCY DECLARATION The company S.p.A., with legal headquarters in Via B. Gozzoli n.
EN 300 328 V1.8.1 EN 62311 : 2008 The compliance with the above mentioned requirements is shown by the label The product complies with the 2004/108/CE Directive relating to the electromagnetic compliancy and with the 2006 /95 / CE (LVD) concerning safety regulations. The Product complies with the ROHS 2011 / 65 / EU Standard.
FCC Waring: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.
