Smart GPS Pet Collar
The Smart GPS Collar is designed for monitoring and protecting pet. GPS, WIFI, Bluetooth and cellular technologies work together to allow you to find and protect your pet, giving you the peace of mind you’ve always needed. With this you can set custom safe zones for your pet. This creates a virtual boundary around specific areas that your setup and control via the app. Also, the LED light to see your pet in the dark and will blink when lost.
01 Introduction- Front Power button LED light
02 Back Charging contacts
03 Charging your device Please charge your device for at least 1 hour before using. When placing magnetic USB cable to device charging contacts make sure it is positioned correctly. The LED should blink when charging and solid when fully charged. When the battery level falls below 20% it will send low battery warning message to people on the contact list via text message or APP.
04 Turning on and off device 3-5 sec. To turn the device on- press the power button 3 to 5 seconds. The LED will flash rapidly for few seconds and then LED off (save power). The device can also be turned on automatically by charging the battery. To turn the device off- it can only be turned off from configuration tool.
05 Reboot device 1 sec. 20 sec. Loosen your hand To reboot the device-long press the power button 20 seconds and stop, then short press 1 second.
06 Download mobile app Or search smart locator from APP store or Google play
07 Create an account Create a login ID and password for this application.
08 Add device from APP TIP The IMEI number must be entered correctly.
09 How to set contact numbers Select the right country code and put the numbers you want to send alert. TIP It is not mandatory for all numbers to be set, however a minimum of one must always to be set.
10 Location update (Automatic) Select working mode and you can choose how often the map will refresh the device’s location by change reporting time, default working mode is 4 and refresh location every 1 hour. TIP Different working mode with different power consumptions, remember that more frequent location updates will reduce battery life.
11 Location update (Manual) 1 2 Sending text message “Loc“ from the app to device Single locate from APP TIP Better to click single locate when device in working mode 1,2 or 3.
12 Location update (Manual) 3 Continuous locate from APP Default continuous locate time is every 10 seconds to refresh location and last 10 minutes. you can change the time from APP. TIP Better to click continuous locate when device in working mode 1,2 or 3.
13 Creating a geofence A geofence is a virtual boundary around a particular location. If you have set a geofence, you will receive a notification when your device leaves or enters the boundary of geofence Zone.
14 LED light control Turn on led light to see your dog in the dark when lost.
15 Activity monitoring Use Activity Tracking to easily find out if your pet is getting enough exercise.
16 History playback
17 Specifications Dimension: 450mm*26mm Weight: 75g Battery: Rechargeable, 3.7V,300mAh Charging voltage: 5V DC Battery life: Up to 3 days under normal use.
www.eviewgps.
FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
