Instruction manual Hello Thank you for purchasing our face recognition thermometer.
Installation suggestion: Suggestions for wall mounted installation： Installation height: About 1.4m from camera height: Installation position: try to avoid the camera directly facing the East and west direction, and the long-term sun exposure of the lens may affect the service life of the lens, as well as the recognition speed and accuracy。 1.
Phoenix terminal wiring diagram Wiring instructions： 1：Strip the wire to expose the wire; ② press the orange button corresponding to the hole, insert the wire head into the hole, release the orange button and fix the wire head (other wire connection methods are the same) Note: the equipment can be started normally only after the positive and negative poles of the power supply are connected correctly; the power adapter needs 12V 2A Device interface：
Matters needing attention Please pay attention to the position of power supply and + 5V output voltage, and distinguish between Fenghuang port 1 and Fenghuang port 2, so as to prevent the external equipment from being damaged by reverse connection。 Pay attention to the connection sequence of network cable to prevent network failure。 Face recognition instructions The distance between personnel and equipment can be adjusted according to height.
Temperature measurement instructions 1. After the thermal imager is turned on, it needs to be preheated for 10 minutes； 2. When measuring, please make sure the distance is 30-50cm and the measuring time is more than two seconds； 2. It is recommended to be used in indoor scene, and the ambient temperature is 0 ~ 40 ℃； 3. Direct sunlight is strictly prohibited, which will cause irreversible damage to the lens； 4.
Warning The product shall only be connected to a USB interface of version USB2.0 Please use common USB Cable or original charger, Otherwise, It may result to danger. When you use a charger for charging, adapter shall be installed near the equipment and shall be easily accessible. Manufacturer of Power Adapter: Shenzhen Mingxin Power Technologies Co., Ltd. Model: MX24W1-1202000V Parameters of Power adapter: Input:AC100-240V, 50/60Hz, 0.
