1.Introduction

BL-M5621DS2A

IEEE 802.11b/g/n/ac 866Mbps

2T2R SDIO WiFi+BT5.1 Module

Specification

Summary of content (15 pages)

PAGE 1
BL-M5621DS2A IEEE 802.11b/g/n/ac 866Mbps 2T2R SDIO WiFi+BT5.
PAGE 2
Top view Module Name: BL-M5621DS2A Module Type: IEEE 802.11b/g/n/ac 866Mbps 2T2R SDIO WiFi+BT5.1 Module Revision: V1.
PAGE 3
Revision History Revision 1.0 Summary Release Date Official release 2020-12-11 1. Introduction BL-M5621DS2A module design is based on UWE5621DS solution, The UWE5621DS is a is a highly integrated 2-in-1 connectivity single chip which has built in a 2x2 dual-band wireless LAN radio and Bluetooth radio. It includes 2.4 GHz and 5 GHz WLAN IEEE 802.11 a/b/g/n/ac 2x2 MU-MIMO 20/40/80 MHz VHT R2 MAC/PHY/Radio, Bluetooth 5 with supporting high power mode, Mesh, Direction Finding and Long Range.
PAGE 4
1.2 Specification reference This specification is based on additional references listed below. _ IEEE Std. 802.11a _ IEEE Std. 802.11b _ IEEE Std. 802.11g _ IEEE Std. 802.11n _ IEEE Std. 802.11ac _ Bluetooth 2.1+EDR/4.2/5.0 1.3 System Functions Table1: General Specification as below: Main Chipset Operating Frequency WiFi Standard Bluetooth Modulation Data rates Form factor Host Interface PCB Stack Dimension Antenna Operation Temperature Storage Temperature Operation Voltage Uwe5621DS 2.4G/5G 802.
PAGE 5
2.0Mechanical Specification 2.1 Mechanical Outline Drawing Typical Dimension (W x L ): 13.0mmx 15.0mm x 1.80mm General tolerance: ±0.
PAGE 6
24 25 GPIO1 ESMD0 GPIO1 ESMD0 49 50 U2RXD INT U2RXD INT 3. Electrical Specification This Specification is based-on conductive DVT testing result. The extreme condition include overall temperature (0℃,+25℃,+40℃) and overall voltage (3.0V,3.3V,3.6V). 3. 1 IEEE 802.11g /a Section: Items Contents Specification IEEE802.11g&IEEE802.11a Mode BPSK, QPSK, 16QAM, 64QAM and OFDM Channel CH1 to CH13 @ 11g CH36 to CH165 @ 11a Data rate 6, 9, 12, 18, 24, 36, 48, 54Mbps TX Characteristics Min. Typ. Max.
PAGE 7
3) 12Mbps (PER ≦10%) - -79 dBm 4) 18Mbps (PER ≦10%) - -77 dBm 5) 24Mbps (PER ≦10%) - -74 dBm 6) 36Mbps (PER ≦10%) - -70 dBm 7) 48Mbps (PER ≦10%) - -66 dBm 8) 54Mbps (PER ≦10%) - -65 dBm - dBm 6. Maximum Input Level (PER ≦10%) 1) IEEE802.11g/a -20 -5 3.2 IEEE 802.11b Section: Items Contents Specification IEEE802.11b Mode DBPSK, DQPSK and CCK and DSSS Channel CH1 to CH13 Data rate 1, 2, 5.5, 11Mbps TX Characteristics Min. Typ. Max. Unit 1.
PAGE 8
3.3 IEEE 802.11n HT20 Section: Items Contents Specification IEEE802.11n HT20 @ 2.4G/5G Mode BPSK, QPSK, 16QAM, 64QAM and OFDM CH1 to CH13 @ 2.4G CH36 to CH165 @ 5G Channel Data rate (MCS index) TX Characteristics MCS0/1/2/3/4/5/6/7/8/9/10/11/12/13/14/15 Min. Typ. Max. Unit 1. Power Levels 1) 14dBm Target (For Each antenna port) @ 2.4G MCS7 12±2 14±2 18±2 dBm 2) 14dBm Target (For Each antenna port) @ 5G MCS7 12±2 14±2 16±2 dBm 2.
PAGE 9
3.4 IEEE 802.11n HT40 Section: Items Contents Specification IEEE802.11n HT40 @ 2.4G/5G Mode BPSK, QPSK, 16QAM, 64QAM and OFDM CH3 to CH11 @ 2.4G CH38 to CH163 @ 5G Channel Data rate (MCS index) TX Characteristics MCS0/1/2/3/4/5/6/7/8/9/10/11/12/13/14/15 Min. Typ. Max. Unit 1. Power Levels 1) 14dBm Target (For Each antenna port) @ 2.4G MCS7 12±2 14±2 18±2 dBm 2) 14dBm Target (For Each antenna port) @ 5G MCS7 12±2 14±2 16±2 dBm 2.
PAGE 10
3.5 IEEE 802.11 ac Section: Items Contents Specification IEEE802.11ac @ 5G Mode BPSK, QPSK, 16QAM, 64QAM, 256QAMand OFDM CH36 to CH165 @ VHT-20 CH38 to CH163 @ VHT-40 CH42 to CH157 @ VHT-80 Channel Data rate (MCS index) TX Characteristics MCS0/1/2/3/4/5/6/7/8/9/10/11/12/13/14/15 Min. Typ. Max. Unit 1.
PAGE 11
10) MCS9 (PER ≦10%) -54 -51 6. Maximum Input Level (PER ≦10%) 1) IEEE802.11ac -30 - dBm 3.6 Bluetooth Section: 3.6.1 BR Specification Items Contents Host Interface UART Antenna Reference Small antennas with 0~2 dBi peak gain Channel CH0 to CH78 Modulation GFSK Min. Typ. Max. Unit TX Characteristics 1.Output Average Power -6±2 5±2 10±2 dBm 2.Modulation Characteristics 1)Delta f1(Avg) 157 kHz 2)Delta f2max(For at least 99.9% of all Delta f2max) 121 kHz 3)Delta f2/ Delta f1 0.
PAGE 12
3.6.2 EDR Specification Items Contents Host Interface UART Antenna Reference Small antennas with 0~2 dBi peak gain Channel CH0 to CH78 π/4-DQPSK 、8PSK Modulation Min. Typ. Max. Unit TX Characteristics 1.Relative Transmit Power 1) π/4-DQPSK -1.5 dBm 2) 8PSK -1.5 dBm kHz 2. Frequency Stability 1) Omega-i +/-4 2) Omega-0 +/-4 3) Omega-0 + Omega-i +/-4 kHz - kHz 3.
PAGE 13
3.6.3 LE Specification Items Contents Host Interface UART Antenna Reference Small antennas with 0~2 dBi peak gain Channel CH0 to CH39 Min. Typ. Max. Unit TX Characteristics 0±2 1. Output power at NOC dBm 2. Modulation Characteristics 1)Delta f1(Avg) 225 2)Delta f2max(For at least 99.9% of all Delta f2max) 185 3)Delta f2/ Delta f1 0.8 275 kHz kHz 0.94 Hz/Hz 3.
PAGE 14
FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) thi s device may not cause harmful interference, and (2) this device must accept any interference received, incl uding interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment.
PAGE 15
Integration instructions for host product manufacturers according to KDB 996369 D03 OEM Manual v01 2.2 List of applicable FCC rules CFR 47 FCC PART 15 SUBPART C has been investigated. It is applicable to the modular transmitter 2.3 Specific operational use conditions This module is stand-alone modular.
