User Manual

1)
2)Range of Frequency:
3)Operating Voltage: 3.7Vdc(powered by Li-ion)
4)Operation current: <5mA
5)Standby current: 1.0mA
6)Sleep current: <0.25mA
Transmit Range: up to 10 meters
Product Specifications
If the keyboard is not working with the iPad (or other Bluetooth
devices) make sure:
Troubleshooting
1) The Bluetooth function on the iPad (or other Bluetooth devices)
is enabled.
2) The Bluetooth keyboard is within 33 feet of the iPad.
3) The passkey is entered correctly.
4) Restart your device.
5) Make sure the keyboard is charged, recharge if low.
6) If you press the “ ” button when both devices
have been connected already it will disrupt the
established connection. The keyboard will exhibit
as though it not connected with the keyboard. To
solve the issue simply restart the keyboard by
turning it OFF and then ON again. You do not need to
repair the device if it was done previously.
Wireless Keyboard
User Guide
How to Charge the battery:
To charge the keyboard, Connect the 5V.DC input from the
keyboard into the computer USB port with the connector cable
provided. The Keyboard can function while charging.
Step 2.Pairing your Bluetooth Keyboard with your iPad/iMac/
iPhone or other Bluetooth enabled device.
The following sample shows how to pair the Bluetooth keyboard
with your iPad.
Before you can use your keyboard, you have to pair it with your iPad.
Pairing allows your keyboard to communicate wirelessly with your
iPad.You only have to perform the pairing once.
2.Enable the Bluetooth function, and it will search for the
Bluetooth keyboard automatically. When the Bluetooth
keyboard is discovered, select the “Bluetooth keyboard”
from the ipad screen, a passkey will appear on the screen
of the iPad. Type in the passkey provided and press the
ENTER key on the keyboard. Your Bluetooth keyboard will
then be successfully paired with your iPad.
1. Turn on the keyboard and press the “ ” key on the keyboard.
The LED light will blink blue. Then on the screen of the iPad, you
search for Settings-->Bluetooth.
(1)
(2)
(3)
(4)
(5)
(6)
Prompted
Blue LED blinking: Pairing
Red LED on: Charging
Green LED on: Battery is fully charged
Green LED blinking: Low in Battery
Installation Guide
1. For the first time user, Please charge the keyboard for at least 6
hours before using it. Thereafter, charge for at least 2 hours when
the battery runs low.
2.The LED (green) will blink when battery is low. The
LED (green) will stay solid when fully charged.
3.Connect the charging cable ( included) to charge keyboard
Step 1.Charging the battery
Overview
Mute
Volume -
Volume +
PrevTrack
NextTrack
Play/pause
Main screen/Esc
Virtual Keyboard
Lock screen
Command
Copy
Paste
Cut
Control key spacebar key to change the
keyboard input method.
+
Brightness +
Brightness -
Search
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
the device cannot be co-located with any other device,
except in accordance to FCC multi-transmitter RF Exposure
procedures.
Model:P130
FCC ID:2ACGLP130
2402-2480MHz
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user's
authority to operate the equipment.
Consult the dealer or an experienced radio/TV technician for help.
-
