AWU50G-US （WT-mU-MTRa01）(AWM503g-WT) User’s Manual Part Name：802.11b/g Wireless Module Part No.：AWU50G-US Version：V1.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Revi si on Hi st or y Rel ease Dat e Revi si on I ni t i al s 1. 0 2009- 6- 24 I ni t i al r el ease SH Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Table of Contents 1. PRODUCT OVERVIEW 4 2. KEY FEATURE 4 3. SPECIFICATIONS 4 4. INSTALL THE DRIVER 5 5. CONNECT 8 6. MAKE INFRASTRUCTURE CONNECTION 9 7. HELP INFORMATION IN RAUI 10 8. MAKE AD-HOC MODE CONNECTION 10 APPENDIX A: TERMINOLOGY 15 APPENDIX B: IMPORTANT NOTICES 16 Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) AWU50G-US User’s Manual (WT-mU-MTRa01) (AWM503g-WT) 1. Product Overview The AWU50G-US is a 802.11b/g wireless Module is used on wireless termination. It delivers incomparable wireless performance for your device. As a value added Wi-Fi card, it provides 64/128/256 WEP, WPA/WPA-PSK、WPA2/WPA2-PSK security as well. 2. Key Feature • IEEE 802.11b、IEEE 802.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) RX sensitivity Power consumption 802.11b :11Mbps:≦-84dBm 802.11g :54Mbps:≦-70dBm 11b: RX: ≦ 226mA TX: ≦ 236mA 11g: RX: ≦228mA TX: ≦ 238mA Antenna RF Antenna Cable Assembly Operating Voltage DC 5V Output Power Security Supported OS Dimension (L*W *H) IEEE 802.11b: Min Typical Max 11/5.5/2/1 Mbps: 15dBm 17dBm 19dBm IEEE 802.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Step3 Choose Ralink Configuration Tool and click next to go on. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Step4 Choose Optimize for WiFi mode and click next to go on. Step5 Click Install to begin the setup. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Step6 Click Finish to end the setup. 5. connect Plug in your wireless LAN adapter, it will be recognized and auto installed. Just confirmed it like below: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) 6. Make infrastructure connection Double click the icon in red circle You will see: You can click the button Rescan to find which AP is in range, they will show on the window. Choice one you want to connect, and click the button connect to finish the connection. An infrastructure connection is completed. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) 7. Help information in RaUI How to find out which WIFI environment you are inside : How to find out your IP address: 8. Make Ad-Hoc mode connection 8.1 Make an Ad-Hoc SSID Step1 Click the button Add to make the Ad-Hoc SSID: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Step2 Choose the SSID and Network Type as blew,and click OK to go on. Step3 Clilk the PROF1 in the window，and you can see the information of Ad-Hoc SSID. 8.2 Setup static IP address for the Ad-Hoc link Step1 At its property page, double click item Internet Protocol (TCP/IP) Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Step2 You will get: Step3 Fill the IP address blank, example as below: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Step4 Click OK to finish the setup. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) 8.3 Ad-Hoc setup for one point completed. 8.4 Setup another Ad-Hoc point as step a,b,c,d. 8.5 Ad-Hoc mode link accomplished. And you can visit each other. Note: To make an Ad-Hoc mode link, we should choice the same channel. Its static IP address should be in the same subnet, and the SSID should be the same too. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Appendi x A: Ter mi nol ogy ad hoc network A network composed solely of stations within mutual communication range of each other via the wireless medium (WM). access point (AP) Any entity that has station functionality and provides access to the distribution ser-vices, via the wireless medium (WM) for associated stations. Station (STA) Any device that contains an IEEE 802.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) Appendi x B: I mpor t ant Not i ces The RF antenna cable assembly used for this product is designed that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna. The maximum peak Gain of this antenna is only 2dBi(Frequency Range 2.4GHz-2.5GHz, Length=12cm). This device complies with Part 15 of the FCC Rules.
AWU50G-US User’s Manual (WT-mU-MTRa01/AWM503g-WT) IMPORTANT NOTE: In the event that these conditions can not be met, then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China.
