Customer Specification HL1916 19 Inch LCD Display Name Cheng HuanJun Department/Title SSME CT PL Date Signature Bigtide R&D VP Xu Bin th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
CONTENTS 1. 2. SCOPE..................................................................................................... 4 ELECTRICAL PERFORMANCE ....................................................... 5 2.1 Power Supply ...................................................................................................5 2.2 Power Management ........................................................................................5 2.3 Signal Interface .......................................................
6. 7. 5.2 Transport and storage (Packed) ..................................................................22 5.3 Mechanical requirements ............................................................................22 5.4 Drop Test (packed) .......................................................................................23 5.5 Safety specifications.....................................................................................23 5.6 Electromagnetic compatibility .................................
Federal Communications Commission (FCC) Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment FCC- Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a communications.
2. ELECTRICAL PERFORMANCE 2.1 Power Supply -Input Voltage : AC100-240 ± 10% - Current (max) : 0.25A(AC220-240V); 0.55A(AC100-120V) - Frequency : 50/60Hz ± 3Hz - Power Consumption : <54W 2.
2.3.1 Signal Specifications Item SPEC Analog: Frequency H 30 ~ 82kHz V 50 ~ 85Hz Signal Input (Analog) Pixel clock 25--165MHz D-SUB Analog 0.7Vpp Video Input Input Impedance 75 Ohm Signal Input Separate Sync, TTL (N or P) Video Level: CVS Signal 0.5---1.0V Sync level: 0.2---0.3V DVI-I Input Via DVI-I to VGA connector DVI-Digital DVI-D Input DDC via DVI 2.3.
2.3.
Figure 3 Female 9-PIN D-SUB connector Table3 th Pin Signal Pin Signal 1 Data Carrier Detect 6 Data Set Ready 2 Received Data 7 Request to Send 3 Transmitted Data 8 Clear to Send 4 Data Terminal Ready 9 Ring Indicator 5 Signal Ground Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
2.4 Product Features Specification Item Analog Input LCD Digital Input Panel Module LG.PHILIPS LM190E05-SL02 Size 19.0” (48 cm diagonal) Active Display Area 376.32 (H) x 301.056 (V) mm Resolution 1280 x 1024 dots (SXGA) Pixel Pitch 0.294(H) x 0.294(V) mm Color Depth 16.7M true 8 bit Luminance 280 cd/m2 (typical); 230cd/m2 (min.) Viewing Angle (Type.) H L 89 degree R 89 degree CR>10 H 89 degree V Input Signals Contrast Ratio 600:1 (typical); 400:1 (min.) Back Light CCFL x 6pcs.
Plug and Play VESA DDC2B Environment Temperature Condition Humidity 5-40 degree C 30-80% (without condensation) Input Voltage Power Supply Power Consumption AC100-240V, 50 / 60Hz; <0.5A Normal operation Power saving Input Connector VESA compatible arm mounting interface Height up/down <2W 3P IEC Type 100mm x 100mm 60mm—80mm (around) Tilt adjust Accessories <54W Up & Down –5--15 degree AC Power cord (Extension Type) 3.0 m Signal Cable 3.0 m: D-sub15pin VGA; 3.
2.5.2 Brightness Factory Preset (Gamma CIE) : Lmin = 0.36+0.15/-0.1 cd/m² Lmax = 137+5/-5 cd/m² Factory Preset (DICOM) : Lmin = 0.45+0.15/-0.1 cd/m² Lmax = 137+5/-5 cd/m² Max. Brightness: ≥230cd/m2 (adjust CCFL, Contrast and Brightness to Maximum) Test Condition: White Luminance (L max) is defined as a luminance of L255 Gray Level at the center point on LCD surface. Also Black Luminance (L min) is defined as a Luminance of L0 Gray level at the center point on LCD surface. (See Note 1 Note 4) 2.5.
2.5.9 Gamma Curve Within ± 10% tolerance of calculated value Factory Preset gamma value: Gamma CIE; DICOM; Gamma 2.0; 2.2; 2.4; NATIVE (Gamma CIE is default setting) Note1: Test Equipment Setup The measurement should be executed in a stable, windless and dark room between 20 minutes after the backlight at the given temperature for stabilization of the backlight. This should be measured in the center of screen. Test equipment should be equivalent with the following equipment.
Note2: Viewing angle is measured as follow: Note 3: Definition of contrast Ratio (CR): Ratio of gray max (Gmax) & gray min (Gmin) at the center point of the panel. Gmax: Luminance with all pixels white Gmin: Luminance with all pixels black Note 4: Definition of Luminance of White: Luminance of white at center point. Note 5: Definition of brightness uniformity Bmax: Maximum brightness Bmin: minimum brightness th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
Note 6: Definition of response time is as follows: Sum of TrD, TfR When the display data is changed from white to black, response time is measured TrD TrR % 100 90 Optical Response 10 0 Note 7: white white black Definition of Color Chromaticity (CIE 1931) Color coordinate of Red , Green, Blue & White at center point . 3. OPERATING GUIDE 3.1 Keys assignment LED MENU UP DOWN SET Figure 4 th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
3.2 Key Functions without active OSD Menu Key Action Menu Activate OSD Up Select VGA (DVI-A) input source Down Select DVI-D input source Note: This choice is in case all the signal sources are available. If not, the signal on the any one input will be displayed. 3.
Main Menu Function Adjustment range Description It is used to adjust the black level of the monitor. Brightness 0…100% This allows the darker area to be seen more distinctly. Note: for DVI-D signals the brightness setting is optimized. Manual changes are not recommended. Adjustment of contrast Contrast 0…100% This allows the brighter area to be seen more distinctly. Note: for DVI-D signals the Contrast setting is optimized. Manual changes are not recommended.
Auto brightness /contrast On/Off Automatically get input signal match with the monitor Auto position /phase /frequency On/Off Automatically adjusts the image position, H-Size (or V-Size) and Fine settings. Improve focus clarity and image stability. The selected auto functions are executed. Execute selected auto function Language Note: The quality of the function depends on the applied picture contents.
menu using the Set key. Note: if the OSD menu is quit by changing the timing or by switching off the monitor, the modification you have made are saved. OSD locked is If this message is displayed, you do not have the authority to carry out the changes in the OSD menu. Please contact your servicing partner in this case. * Service level 2 enter: while the highlight line is on the service level 2 position, press 1 x Up, and 2 x Down keys, it will enter the following submenu. Service level 2 4.
Item Set Size of set Width 425mm Depth 210mm Height 493 (-60) mm Tilt 0 degree – 20degree Housing components Aluminum Kensington lock Yes Visible screen surface Approx. 376mm×301mm Ventilation slots In rear panel Degree of protection IP20 to DIN40050 Connection panel At rear, covered Net weight Approximately 5.5 Kg (without stand) Approximately 8.8 Kg (with stand) 4.2 Screen Quality 4.2.1 H/V outline position H: |L-R|≤1.0mm V: |U-D|≤1.0mm th Last change: 27 , Oct.
4.2.2 Outline edge position ∣A-B∣≤1.0mm ∣C-D∣≤1.0mm ∣E-F∣≤1.0mm ∣G-H∣≤1.0mm 4.2.3 Structure width position ∣A-B∣≤2.0mm th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
4.3 Packaging Figure 6 4.3.1 Package dimension and weight Box Outer size of box Gross weight Width (mm) 570 Depth (mm) 370 Height (mm) 575 Approximately 12.5Kg 5. ENVIRONMENT CONDITONS 5.1 Operation Temperature Ambient temperature range +5 -- +40℃ Temperature gradient Max. 5℃/h, no condensation Atmospheric pressure 1040 – 674 hPa th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
5.2 Transport and storage (Packed) Ambient temperature range -20 -- +60℃ Temperature gradient Max. 5℃/h, no condensation Atmospheric pressure 1040 – 674 hPa (0 -- 3048m) 5.3 Mechanical requirements Operation According to EN60068-2-6 Vibration 10--58 Hz within ± 0.075 mm deflection 58—500 Hz at 10 m/s2 According to EN 60068-2-27 (single shock) Shock 150m/s2, 6ms No permanent shock allowed in operating conditions Packed unit According to EN60068-2-6 Vibration 5--9 Hz within ± 3.
5.4 Drop Test (packed) Position Height Corner 1 76.0cm Edge 3,2,4 76.0cm A,B,C,D 76.0cm E 76.0cm F 76.0cm Surfaces (Cushion should be changed to new one.) Corner 5 76.0cm Edge 6,7 76.0cm Figure 7 5.5 Safety specifications Safety standards EN60601, IEC601 CAN/CSA – C 22.2 No 601.1 – M 90 Approvals CSA/us mark, UL 2601-1 Protection class Protection class 1 Degree of protection to IP 20 DIN 40050 Conformity th Last change: 27 , Oct.
5.6 Electromagnetic compatibility 5.7 MTBF Flat screen without Backlight: 50,000 operation hours. Flat screen with Backlight: 10,000 operation hours. th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
6. DEFECT, SCRATCH and DUST 6.1 Condition These defects are inspected under the following conditions: Temperature: 20 ~ 25 degrees C Humidity: 65 ± 5% RH Illumination: Single 20W fluorescent lamp non-directive (Appearance: 300 to 700 LUX) Viewing distance: The distance between the LCM and the inspector’s eyes shall be at least 30cm --50 cm. Viewing angle: The inspection shall be conducted within normal viewing angle range. 6.2 Dot Defect th Last change: 27 , Oct.
Note 1: a. every dot herein means Sub- Pixel (Each Red, Green, or Blue Color) b. Damaged less than half size of sub-pixels is not counted as defect c. Dots darker than half brightness of sub-pixel are not defined as bright dot defect and dots brighter than half brightness of sub-pixels is not defined as dark dot defect. d. The definition of range A is included in range B. Note 2: Panel Pixel Defect comply with ISO 13406-2 class 2 6.
Where W: Width L: D: Length Average diameter = (a+b)/2 Note) a. Average Diameter b. Linear: a>2b, Circular: a<=2b 6.5 Line Defect All kinds of line defects such as vertical, horizontal or cross are not allowed. 6.6 Others Issues, which are not defined in these criteria, shall be discussed with both parties, Customer and Supplier, for better solution. 7. NOTICE FOR HANDING 7.1 Handing (1) When the module is assembled, it should be attached to the system firmly using all mounting holes.
(8) If the liquid crystal material leaks from the panel, it should be kept away from the eyes or mouth. In case of contact with hands, legs or cloths, it must be washed away thoroughly with soap. (9) Protect the module from static which may cause damage to the CMOS Gate Array IC. (10) Use fingerstalls with soft gloves in order to keep display clean during the incoming inspection and assembly process. (11) Do not disassemble the module. (12) Do not pull or fold the lamp wire.
Appendix 1 Preset Timings th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
Analog Signal Timings Dot H.freq NO Timing H.dis freq (Khz) (us) (Mhz) H.bac k porch (us) Hs V.freq Vs porch Wid (us) (us) V.dis width (Khz) V.back (us) (us) Hs. Vs pol Inte rlac e 1 1024*768@43 HZ 44.900 35.522 22.806 1.247 3.920 86.958 10.810 0.296 0.056 P P YES 2 1024*768@60 HZ 65.000 48.363 15.754 2.462 2.092 60.004 15.880 0.600 0.124 N N NO 3 1024*768@70 HZ 75.000 56.476 13.653 1.920 1.813 70.069 13.599 0.513 0.
19 640*350@70 HZ 20 720*350@70 HZ 21 640*400@70 HZ 22 720*400@70 HZ 23 640*350@85 HZ 24 720*350@85 HZ 25 25.175 31.469 25.422 1.907 3.813 70.087 11.122 1.907 0.064 P N NO 25.175 31.469 25.422 1.907 3.813 70.087 12.711 1.112 0.064 N P NO 31.500 37.86 20.317 3.048 2.032 85.080 9.244 1.585 0.079 P N NO 640*400@85 HZ 31.500 37.86 20.317 3.048 2.032 85.080 10.565 1.083 0.079 N P NO 26 720*400@85 HZ 35.500 37.927 20.282 3.042 2.028 85.039 10.
Digital Signal Timings th Last change: 27 , Oct. 2005 Copyright @ SSME (SIEMENS Medical Equipment Ltd.
