mxm503_us_saf.fm -1 ページ ２００９年５月１４日 木曜日 午後８時２５分 MODEL: MX-M283N MX-M363N MX-M453N MX-M503N DIGITAL MULTIFUNCTIONAL SYSTEM Safety Guide Before installing this product, be sure to read the "CAUTIONS" and "INSTALLATION REQUIREMENTS" sections. CAUTIONS INSTALLATION REQUIREMENTS SUPPLIES SPECIFICATIONS TO THE ADMINISTRATOR OF THE MACHINE Keep this manual close at hand for reference whenever needed.
mxm503_us_saf.fm 0 ページ ２００９年５月１４日 木曜日 午後８時２５分 Each instruction also covers the optional units used with these products. Caution! For complete electrical disconnection, pull out the main plug. The socket-outlet shall be installed near the equipment and shall be easily accessible. To reduce the risk of fire, use only UL-Listed No.26 AWG or larger telecommunication line cord. FAX interface cable and Line cable: These special accessories must be used with the device. FOR YOUR RECORDS ...
mxm503_us_saf.fm 1 ページ ２００９年５月１４日 木曜日 午後８時２５分 Contents CAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Finisher specifications . . . . . . . . . . . . . . . . . . . . . 13 Laser information . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Finisher (large stacker) specifications . . . . . . . . . 14 INSTALLATION REQUIREMENTS . . . . . . . . . . . . . 5 SUPPLIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Storage of supplies. . . . . . . . . . . .
mxm503_us_saf.fm 2 ページ ２００９年５月１４日 木曜日 午後８時２５分 CAUTIONS Symbols in this manual To ensure safe use of the machine, this manual uses various safety symbols. The safety symbols are classified as explained below. Be sure you understand the meaning of the symbols when reading the manual. WARNING Indicates a risk of death or serious injury. CAUTION Indicates a risk of human injury or property damage. Meaning of the symbols The symbol indicates the need for caution.
mxm503_us_saf.fm 3 ページ ２００９年５月１４日 木曜日 午後８時２５分 CAUTIONS CAUTION Do not install the machine in a location with poor ventilation. Install so that exhaust from the machine does not directly contact people. A small amount of ozone is produced within the printer during operation. The emission level is insufficient to cause any health hazard. The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m3) calculated as an 8 hr. time-weighted average concentration.
mxm503_us_saf.fm 4 ページ ２００９年５月１５日 金曜日 午前１１時５１分 CAUTIONS Laser information Wave length 790 nm ± 10 nm Pulse times (North America and Europe) MX-M283N/MX-M363N: 6.1 µs ± 8.3 ns /7 mm MX-M453N/MX-M503N: 4.8 µs ± 6.4 ns /7 mm Output power Max 0.6 mW (LD1+ LD2) Caution Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This Digital Equipment is CLASS 1 LASER PRODUCT (IEC 60825-1 Edition 1.
mxm503_us_saf.fm 5 ページ ２００９年５月１４日 木曜日 午後８時２５分 INSTALLATION REQUIREMENTS The performance of the machine is affected by the ambient conditions of the installation location. Do not install in the following locations: CAUTION: Do not install the machine in a location with poor air circulation. A small amount of ozone is created inside the machine during printing.
mxm503_us_saf.fm 6 ページ ２００９年５月１４日 木曜日 午後８時２５分 SUPPLIES Standard supplies for this product that can replaced by the user include paper, toner cartridges, and staple cartridges for the finisher. Be sure to use only SHARP-specified products for the toner cartridges, finisher staple cartridge, saddle stitch finisher staple cartridge, and transparency film.
mxm503_us_saf.
mxm503_us_saf.fm 8 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Machine specifications / copier specifications (Continued) Paper sizes: 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR (Includes automatic paper size detection function. Entry of paper sizes up to 11-5/8" x 17" (297 mm x 432 mm) is possible.
mxm503_us_saf.fm 9 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Continuous copying speeds* Model MX-M283N Copy ratio MX-M363N MX-M453N MX-M503N 100% / Reduce / Enlarged 11" x 17", A3, 8K 15 copies/min. 17 copies/min. 20 copies/min. 22 copies/min. 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", B4 17 copies/min. 20 copies/min. 23 copies/min. 25 copies/min. 8-1/2" x 11", A4, B5, 16K 28 copies/min. 36 copies/min. 45 copies/min. 50 copies/min.
mxm503_us_saf.fm 10 ページ ２００９年５月１５日 金曜日 午後３時２０分 SPECIFICATIONS Acoustic noise emission (measurement according to ISO7779) MX-M283N MX-M363N MX-M453N MX-M503N Printing mode (continuous printing) 6.4 B 6.6 B 6.7 B 6.8 B Standby mode 4.0 B 4.6 B 4.6 B 4.
mxm503_us_saf.fm 11 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Exit tray unit (right tray) specifications Model MX-TRX2 Output method Face-down output Output capacity* 100 sheets (using SHARP-recommended 8-1/2" x 11" or A4 paper) Dimensions When tray is folded up: 12-23/64" (W) x 15-61/64" (D) x 2-3/64" (H) (314 mm (W) x 405 mm (D) x 52 mm (H)) When tray is extended: 17-31/64" (W) x 15-61/64" (D) x 2-3/64" (H) (444 mm (W) x 405 mm (D) x 52 mm (H)) Weight Approx. 2 lbs. (0.
mxm503_us_saf.fm 12 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Stand/2x500 sheet paper drawer specifications Model MX-DEX9 Paper sizes 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, A3, B4, A4, A4R, B5, B5R, 8K, 16K, 16KR Paper weight Plain paper (16 lbs. to 28 lbs. (60 g/m2 to 105 g/m2)), heavy paper (28 lbs. bond to 110 lbs. index (106 g/m2 to 209 g/m2)) Paper capacity 500 sheets (21 lbs.
mxm503_us_saf.fm 13 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Finisher specifications Model MX-FNX9 Paper sizes 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR Paper weight Thin paper (15 lbs. to 16 lbs. (56 g/m2 to 59 g/m2)) plain paper (16 lbs. to 28 lbs. (60 g/m2 to 105 g/m2)) heavy paper (28 lbs. bond to 110 lbs.
mxm503_us_saf.fm 14 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Finisher (large stacker) specifications*1 Model MX-FN11 Paper sizes 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR Paper weight Thin paper (15 lbs. to 16 lbs. (56 g/m2 to 59 g/m2)) plain paper (16 lbs. to 28 lbs. (60 g/m2 to 105 g/m2)) heavy paper (28 lbs. bond to 110 lbs.
mxm503_us_saf.fm 15 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Saddle stitch finisher specifications*1 Model MX-FN10 Paper sizes 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR Paper weight Thin paper (15 lbs. to 16 lbs. (56 g/m2 to 59 g/m2)) plain paper (16 lbs. to 28 lbs. (60 g/m2 to 105 g/m2)) heavy paper (28 lbs. bond to 110 lbs.
mxm503_us_saf.fm 16 ページ ２００９年５月１５日 金曜日 午後３時２０分 SPECIFICATIONS Punch module specifications (for finisher) Model MX-PNX1B Hole punching 3 holes or 2 holes Allowed paper sizes for punching 3 holes: 11" x 17", 8-1/2" x 11", A3, A4 2 holes: 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11"R, 7-1/4" x 10-1/2" Punchable paper weights 15 lbs. to 34 lbs.
mxm503_us_saf.fm 17 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Printer specifications Type Built-in Continuous printing speed Same as continuous copying speed (When printing same document continuously on 8-1/2" x 11" (A4) plain paper in non-offset mode, excluding processing time.
mxm503_us_saf.fm 18 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Network scanner / Internet Fax*1 specifications Type Built-in 100 x 100, 200 x 200, 300 x 300, 400 x 400, 600 x 600 Scanning resolution (dpi) Internet Fax: 200 x 100, 200 x 200, 200 x 400, 400 x 400, 600 x 600 (200 x 100, 200 x 200 when file type is TIFF-S) Halftone can be selected for resolutions other than 200 x 100 dpi. Scanning speed MX-M363N/MX-M453N/MX-M503N: Color (8-1/2" x 11" / A4) One-sided: 70 pages/min.
mxm503_us_saf.fm 19 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Pull scan function (TWAIN) specifications Supported protocol TCP/IP (IPv4) Supported client PC operating systems Windows 98 / Me / 2000 / XP / Server 2003 / Vista/ Server 2008 Color modes Full Color, Grayscale, Mono Diffusion, Mono 2 gradation Resolution settings 75 dpi, 100 dpi, 150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi (The resolution can be specified by entering a numerical value from 50 to 9600 dpi.
mxm503_us_saf.fm 20 ページ ２００９年５月１４日 木曜日 午後８時２５分 SPECIFICATIONS Facsimile specifications Model MX-FXX2 Applicable telephone line Public switched telephone network, PBX Scanning resolution (supports ITU-T standards) 8 x 3.85 lines/mm (Standard), 8 x 7.7 lines/mm (Fine, Fine-Halftone), 8 x 15.4 lines/mm (Super Fine, Super Fine - Halftone), 16 x 15.4 lines/mm (Ultra Fine, Ultra Fine - Halftone) Transmission speed 33.6 kbps down to 2.
mxm503_us_saf.fm 21 ページ ２００９年５月１４日 木曜日 午後８時２５分 ✂ Administrator Name: Contact at: Information that the administrator of the machine requires is printed on the back of this page. (Separate this page from the manual and keep it in a safe place. In addition, fill in the name of the administrator and the administrator's contact information in the left hand margin.
mxm503_us_saf.fm 22 ページ ２００９年５月１４日 木曜日 午後８時２５分 TO THE ADMINISTRATOR OF THE MACHINE (Separate this page from the manual and keep it in a safe place.) Factory default passwords When accessing the system settings, the administrator password is required to log in with administrator rights. The system settings can be configured in the Web pages as well as on the operation panel. To access the system settings using the Web pages, a password is also required.
mxm503_us_saf.
mxm503_us_saf.fm 24 ページ ２００９年５月１４日 木曜日 午後８時２５分 TO THE ADMINISTRATOR OF THE MACHINE FCC Notice to users: This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On this equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company. The REN is used to determine the number of devices that may be connected to a telephone line.
mxm503_us_saf.fm 25 ページ ２００９年５月１４日 木曜日 午後８時２５分 TO THE ADMINISTRATOR OF THE MACHINE NOTICE for users in the USA BE SURE TO ASK YOUR AUTHORIZED SHARP DEALER ABOUT THE WARRANTY THAT YOUR SELLING DEALER EXTENDS TO YOU. In order to assure you, the end-user, of warranty protection, Sharp extends a limited warranty to each of its authorized dealers and, in turn, requires each of its authorized dealers to extend its own warranty to you on terms that are no less favorable than those given to the dealer by Sharp.
mxm503_us_saf.fm 26 ページ ２００９年５月１４日 木曜日 午後８時２５分 TO THE ADMINISTRATOR OF THE MACHINE NOTICE FOR USERS IN CANADA "NOTICE : This product meets the applicable Industry Canada technical specifications." "NOTICE : The Ringer Equivalence Number is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.
mxm503_us_saf.fm 27 ページ ２００９年５月１４日 木曜日 午後８時２５分 TO THE ADMINISTRATOR OF THE MACHINE Trademark acknowledgments The following trademarks and registered trademarks are used in conjunction with the machine and its peripheral devices and accessories. • Microsoft®, Windows®, Windows® 98, Windows® Me, Windows NT® 4.0, Windows® 2000, Windows® XP, Windows Server® 2003, Windows Vista®, Windows Server® 2008 and Internet Explorer® are registered trademarks or trademarks of Microsoft Corporation in the U.S.A.
mxm503_us_saf.
mxm503_us_saf.
mxm503_us_saf.fm 30 ページ ２００９年５月１４日 木曜日 午後８時２５分 MX-M283N/MX-M363N/MX-M453N/MX-M503N Safety Guide SHARP ELECTRONICS CORPORATION 1 Sharp Plaza, Mahwah, New Jersey 07495-1163. www.sharpusa.com SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East, Mississauga, Ontario, L4Z 1W9 This manual has been printed using a vegetable-based soy oil ink to help protect the environment.
