LCD MONITOR LCD FARBMONITOR MONITEUR LCD MONITOR LCD MONITOR LCD LL-T1803-H LL-T1803-B OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUALE D’USO MANUAL DE FUNCIONAMIENTO
Table of Contents / Inhaltsverzeichnis / Table des matières / Indice / Índice English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Deutsch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Notice for Users in the USA ............................................................................................................................ 4 TCO '95/ '99 ..................................................................................................................................................... 5 Notice for Users in Europe ............................................................................................................................... 7 Notice for Users in the UK ........
Notice for Users in the USA FCC Statement WARNING – FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user's authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
English LL-T1803-B LL-T1803-H Congratulations! You have just purchased a TCO’95 or TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.
This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/ EEG. Dette udstyr overholder kravene i direktiv nr.
Notice for Users in the UK FOR CUSTOMERS IN U.K. IMPORTANT The wires in this mains lead are coloured in accordance with the following code : GREEN-AND-YELLOW : Earth BLUE : Neutral BROWN : Live As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows.
- - - Monitor and accessory checklist - Please check that the following items are included in the package. - LCD monitor (1) - AC adapter (1) (model name: NL-A61J) - Analog signal cable (1) (model name: 0LTGD15180001) - Utility Disk (For Windows/Macintosh) (1) - Operation manual (1) Under certain display conditions, minute specks or spots may be noticeable. This is common for liquid crystal monitors and is not a malfunction. The LCD panel has been manufactured using highly elaborate technology.
Product description 11 11 11 7 1 2 3 4 8 9 10 5 6 1. INPUT button ............................ To switch between the signal’s input terminals. (Analog signal input terminal ↔ DVI-D input terminal) 2. MENU button ............................ This button is used to pop-up, select and close the OSD (On Screen Display) Menu. 3. SELECT button ........................ This button is used to select menu options when the OSD Menu is displayed. 4. buttons ..............................
Standing up and adjusting the monitor CAUTION! - Pressure from hands on the LCD panel could cause damage. Be careful not to allow your fingers to be pinched. Standing up the monitor Press down on the stand and lift up the top section of the monitor. Folding up the monitor 1. Remove the AC adapter and the RGB signal cable. 2. If carrying out adjustments to the monitor, place it upright. 3. While pressing the rear lock disable button (1), gently fold back the monitor (2).
Connecting the monitor and turning the monitor on and off CAUTION! - Digital RGB connection Connecting the monitor to a computer via a Digital signal cable. (to be purchased separately) - For digital RGB connection, the monitor has an input for connecting to a computer with a DVIcompatible output connector (DVI-D 24 pin or DVII 29 pin) and SXGA output capability. (Depending on the type of computer to be connected, the display may not work correctly.
CAUTION! - Turning the power off After unplugging the AC adaptor or power cord, be sure to wait at least 10 seconds before plugging in again. If you put the plug back in immediately after unplugging, damage may be caused and the screen malfunction or not display. 1. Turn the computer off. 2. Press the monitor's POWER button. The Power LED will disappear. Turn the computer off Turning the power on 1. Press the monitor's POWER button. 2. Turn on the computer.
Adjusting the screen display For analog signal 1. First perform an automatic adjustment. (p. 15) 2. Perform manual adjustment where necessary. (p. 16) For digital signal The monitor can generally be used without adjustment. If necessary perform manual adjustment. (p. 19) Adjustment lock function By disabling the control buttons (i.e. setting the lock) any attempted changes to adjusted values will be voided. 1. Turn off the monitor power. 2. While pressing the MENU button, press the power button (i.e.
(With analog connection) How to Adjust Automatic screen adjustment 1. Press the MENU button. The ADJUSTMENT Menu will be displayed. Options in the ADJUSTMENT Menu can be adjusted automatically (CLOCK, PHASE, H-POS V-POS). Note: - When setting up this monitor for the first time or after having changed an aspect of the current system, perform an automatic screen adjustment before use. 2. Press the button. The screen will become dark and [ADJUSTING] will be displayed.
Adjusting the screen display (With analog connection) ADJUSTMENT Menu Manual screen adjustment Adjustments can be made using On Screen Display (OSD) Menu provided. On Screen Display for adjustment If you are using Windows, open the Adjustment Pattern on the accompanying Utility Disk. (p. 15). If your system is not Windows, you can not use the Adjustment Pattern. Therefore display an image that makes the entire screen light and adjust it through checking visually its actual tone.
GAIN CONTROL Menu WHITE BALANCE Menu MANUAL: Individual menu options are manually adjusted. AUTO: Every menu option is automatically adjusted using the Auto Gain Control* function. Notes: - On settings other than [STD] not all graduations can be displayed. To display all graduations, set to [STD]. buttons to select [COOL], [·], [STD], - Use the [·], [WARM] or [USER]. - Selecting USER will display the setting values for [R-CONTRAST], [G-CONTRAST] and [B-CONTRAST], in order to make fine adjustments.
Adjusting the screen display (With analog connection) MODE SELECT Menu Notes: - Depending on the resolution of the input signal, even if menu options can be selected, the display may not change. - To choose a menu option: SELECT button - When adjustment complete: MENU button OSD H-POSITION (OSD horizontal position) The position of the OSD display can be moved to the left and right. ( buttons) OSD V-POSITION (OSD vertical position) The position of the OSD display can be moved up buttons) and down.
Adjustments can be made using On Screen Display (OSD) Menu provided. (With digital connection) WHITE BALANCE Menu On Screen Display for adjustment If you are using Windows, open the Test Pattern on the accompanying Utility Disk. (p. 15) If your system is not Windows, you can not use the Adjustment Pattern. Therefore display an image that makes the entire screen light and adjust it through checking visually its actual tone. Notes: - On settings other than [STD] not all graduations can be displayed.
Adjusting the screen display (With digital connection) MODE SELECT Menu Notes: - Depending on the resolution of the input signal, even if menu options can be selected, the display may not change. - To choose a menu option: SELECT button - When adjustment complete: MENU button OSD H-POSITION (OSD horizontal position) The position of the OSD display can be moved to the buttons) left and right. ( OSD V-POSITION (OSD vertical position) The position of the OSD display can be moved up buttons) and down.
Monitor care Troubleshooting Always remove the plug from the AC outlet when cleaning the monitor. If you think the monitor may be faulty, please check the following points before taking it to be repaired. If afterwards it still does not work, please contact the shop where you purchased the monitor or your nearest Sharp authorized Service Center. Cabinet and control panel section Use a soft dry cloth to lightly wipe away any grime from the cabinet and control panel.
Specifications Dimensions (Units: mm) Product specifications 420 372 422 LCD display 46 cm measured diagonally TFT LCD module Resolution (max.) SXGA 1280 x 1024 pixels Displayable colors (max.) 16.77 million colors (8 bit) Brightness (max.) 220cd/m2 Dot pitch 0.2805(H) 0.2805(V) mm Contrast ratio 400:1 Angle of visibility Left-right 170°; Up-down 170° Screen display size Horizontal 359 mm x Vertical 287.2 mm Video signal Analog: Analog RGB (0.7Vp-p) [75Ω] Digital: DVI standard based on 1.
Relevant signal timings (digital) Relevant signal timings (analog) Display mode VESA US text Power Macintosh series Sun Ultra series - - - 640x480 Hsync 31.5kHz 37.9kHz 37.5kHz 800x600 35.1kHz 37.9kHz 48.1kHz 46.9kHz 1024x768 48.4kHz 56.5kHz 60.0kHz 1152x864 67.5kHz 1280x960 60.0kHz 1280x1024 64.0kHz 80.0kHz 720x400 31.5kHz 640x480 35.0kHz 832x624 49.7kHz 1024x768 60.2kHz 1152x870 68.7kHz 1280x1024 64.0kHz 80.0kHz 1024x768 48.3kHz 53.6kHz 56.6kHz 1152x900 61.8kHz 71.8kHz 1280x1024 71.7kHz 81.
Specifications The analog signal input connector pin Power management (Mini D-sub connector with 15 pins) 5 4 10 15 Number 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 3 9 14 2 8 13 The monitor is based on the VESA DPMS*1 and the DVI DMPM*2 standards. To activate the monitor's Power Management function, both the video card and the computer must conform to the VESA DPMS standard and the DVI DMPM standard.
Depending on the computer or OS, it may be necessary to use the computer to operate the installation of monitor set-up information etc. If so, follow the steps below to install the monitor set-up information. (Depending on the type of computer or OS, command names and methods may differ. Please follow the computer’s own operation manual while reading this.) For Windows98 Installing monitor set-up information into Windows98, and setting the monitor's ICC profile as a predetermined value.
Installing set-up information and the ICC profile (For Windows) For Windows2000 For WindowsMe Installing monitor set-up information into Windows2000, and setting the monitor's ICC profile as a predetermined value. This explanation assumes that the floppy disk drive is "A drive". 1. Place the Utility Disk (provided) into the computer's A drive. 2. Click on the [Start] button. From [Settings], choose [Control Panel]. 3. Double click on [Display]. 4. Click on [Settings], [Advanced] and [Monitor]. 5.
Installing the ICC profile For WindowsXP Installing the monitor’s ICC profile. (If the set-up information has already been installed, so too has the profile, and there is no need to install it.) This explanation assumes that the floppy disk drive is "A drive". 1. Place the Utility Disk (provided) into the computer's A drive. 2. Click on the [Start] button. From [Settings], choose [Control Panel]. 3. Double click on [Display]. 4. Click on [Settings] and [Advanced]. 5.
Information about the ColorSync profile (For MacOS) About the ColorSync profile ColorSync is the Apple Corporation's color management system and is a function that enables color resolution to be realized when used with a compatible application. A ColorSync profile describes the color characteristics of the LCD monitor. Notes: - This monitor's ColorSync profile works with MacOS8.5 or above. - When using the ColorSync profile, please set the [WHITE BALANCE] to [STD].
An arm or stand based on the VESA standard (purchased separately) can be attached to the monitor. Procurement of the arm or stand is at the customer's discretion. 6. Remove the four screws and then remove the stand from the monitor. Arms or stands able to be used Attachments must satisfy the following. - Compatible with the VESA standard - Have a gap of 100 mm x 100 mm between the screw holes on the section to be attached - Not be likely to fall off or break off after being attached to the monitor.
Deutsch F I 32 33 35 36 36 37 38 40 40 40 41 41 41 42 42 42 42 43 43 44 47 49 49 49 49 50 53 56 57 E Hinweis für Benutzer in den USA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TCO'95/'99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hinweis für Benutzer in Europa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hinweis für Benutzer in den USA FCC-Hinweis ACHTUNG – Änderungen oder Modifikationen an diesem Gerät, die nicht ausdrücklich vom Hersteller genehmigt wurden, können laut FCC-Richtlinie zum Erlöschen der Betriebsberechtigung führen. Hinweis: Dieses Gerät wurde geprüft und entspricht den Grenzwerten für digitale Geräte der Klasse B gemäß Teil 15 der FCC-Richtlinien. Diese Grenzwerte dienen dem ausreichenden Schutz gegen Störungen bei einer Installation in Wohnbereichen.
GB Deutsch Warum haben wir Computer mit Umweltkennzeichnung? In vielen Ländern dient die Kennzeichnung mit Umweltzeichen als Anreiz für die Fertigung und Bereitstellung umweltverträglicher Konsumgüter und Dienste. Das Hauptproblem im Zusammenhang mit Computern und anderen elektronischen Geräten besteht darin, dass umweltschädliche Stoffe in den Produkten enthalten sind und auch während der Fertigung eingesetzt werden.
Umweltanforderungen Flammschutzmittel Flammschutzmittel kommen in Platinen, Kabeln, Drähten, Verkleidungen und Gehäusen vor. Sie sollen die Ausbreitung eines Brandes verhindern oder zumindest verzögern. Bis zu 30% der Kunststoffteile in einem Computergehäuse können aus Flammschutzsubstanzen bestehen. Die meisten Flammschutzmittel enthalten Brom oder Chlorid und lassen sich in chemischer Hinsicht mit einer anderen Gruppe umweltschädigender Stoffe, den PCBs, in Verbindung bringen.
GB Hinweis für Benutzer in Europa Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. Deutsch This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillæg nr. 93/68/EEC.
Hinweis für Benutzer in GB FÜR KUNDEN IN GB WICHTIG Die Drähte in diesem Netzkabel sind nach folgendem Code farbig gekennzeichnet: GRÜN/GELB : Masse BLAU : Nulleiter BRAUN : Stromführend Da die Farben der Drähte im Netzkabel dieses Gerätes möglicherweise nicht den Farbkennzeichnungen der Anschlüsse in Ihrem Stecker entsprechen, müssen Sie folgendermaßen vorgehen.
- - - Checkliste für Monitor und Zubehör - Prüfen Sie den Kartoninhalt auf Vollständigkeit. - LCD-Monitor (1) - Netzadapter (1) (Modellbezeichnung: NL-A61J) - Analogsignalkabel (1) (Modellbezeichnung: 0LTGD15180001) - Utility Disk (für Windows/Macintosh) (1) - Bedienungsanleitung (1) Hinweise: - Das Digitalsignalkabel (DVI-D 24polig – DVI-D 24polig) muß separat gekauft werden. (Modellbezeichnung: NL-C01E) - Bewahren Sie den Karton für einen eventuellen Transport des Monitors auf.
Produktbeschreibung 11 11 11 7 1 2 3 4 8 9 10 5 6 1. Taste INPUT .................................... Für die Umschaltung zwischen den Signaleingangsanschlüssen. (Analogsignal-Eingangsanschluß ↔ DVI-D-Eingangsanschluß) 2. Taste MENU .................................... Mit dieser Taste öffnen, wählen und schließen Sie das OSD (On screen Display) -Menü. 3. Taste SELECT ................................ Mit dieser Taste wählen Sie die Menüoptionen aus, wenn das OSDMenü angezeigt wird. 4. Tasten .....
GB Produktbeschreibung Aufstellen und Justieren des Monitors Deutsch ACHTUNG: - Wenn Sie mit der Hand auf den LCD-Bildschirm drücken, kann dieser beschädigt werden. - Vorsichtig vorgehen und darauf achten, dass die Finger nicht eingeklemmt werden. I F Aufstellen des Monitors Drücken Sie auf den Fuß, und heben Sie den oberen Teil des Monitors an. E Zusammenklappen des Monitors 1. Trennen Sie die Netzadapter und Sie die RGBSignalkabel ab. 2.
Anschließen des Monitors und Einund Ausschalten des Monitors - Bevor Sie den Monitor anschließen, müssen Sie den Monitor und den Computer ausschalten. Achten Sie darauf, daß Sie das Kabel nicht überdehnen, und schließen Sie kein Verlängerungskabel an, da dies Funktionsstörungen hervorrufen kann. Digitaler RGB-Anschluss Schließen Sie den Monitor über ein Digitalsignalkabel (separat erhältlich) an einen Computer an. Bevor Sie das Kabel anschließen, müssen Sie den Monitor und den Computer ausschalten.
GB Anschließen des Monitors und Ein- und Ausschalten des Monitors ACHTUNG: - Nach dem Abtrennen des Wechselstromadapters oder des Netzsteckers sollte mindestens 10 Sekunden gewartet werden, bevor der Adapter oder Netzstecker wieder eingesteckt wird. Wenn der Stecker sofort nach dem Abtrennen wieder eingesteckt wird, kann dies zu Beschädigungen führen; dadurch kann der Bildschirm Fehlfunktionen aufweisen oder es wird keine Anzeige auf dem Bildschirm wiedergegeben. 1. Schalten Sie den Computer aus. 2.
Einstellen der Bildschirmanzeige Analogsignal 1. Führen Sie zunächst eine automatische Einstellung durch. (S. 43) 2. Führen Sie bei Bedarf eine manuelle Einstellung durch. (S. 44) Digitalsignal Der Monitor kann in der Regel ohne Einstellung verwendet werden. Führen Sie bei Bedarf eine manuelle Einstellung durch. (S. 47) Einstellsperrfunktion Wenn Sie die Steuertasten deaktivieren (d. h. die Sperre setzen), können keine Werte eingestellt werden. 1. Schalten Sie den Monitor aus. 2.
GB Einstellen der Bildschirmanzeige (bei analogem Anschluss) 1. Drücken Sie die Taste MENU. Das Menü ADJUSTMENT wird angezeigt. Die Optionen im Menü ADJUSTMENT können automatisch eingestellt werden (CLOCK, PHASE, H-POS, V-POS). Deutsch Einstellen Automatische Bildschirmeinstellung Öffnen des Einstellmusters (für Windows) Diese Anweisungen betreffen Windows 95/98/2000/ Me/XP. Dabei wird von “Laufwerk A” als Diskettenlaufwerk ausgegangen. 1.
Einstellen der Bildschirmanzeige (bei analogem Anschluss) Menü ADJUSTMENT Manuelle Bildschirmeinstellung Die Einstellungen können über das OSD-Menü vorgenommen werden. OSD für die Einstellung Wenn Sie mit Windows arbeiten, können Sie das Einstellmuster auf der mitgelieferten Utility Disk verwenden.(S. 43) Falls Ihr System nicht unter Windows arbeitet, können Sie das Einstellmuster nicht verwenden.
GB Einstellen der Bildschirmanzeige (bei analogem Anschluss) WHITE BALANCE COOL .... Farbton mit stärkerem Blaustich als normal • ......... Farbton mit leicht stärkerem Blaustich als normal STD ...... Farbton entspricht der Standardeinstellung • ......... Farbton mit leicht stärkerem Rotstich als normal WARM .. Farbton mit stärkerem Rotstich als normal USER für blau-grün R-CONTRAST .... für rot für violett G-CONTRAST .... für grün für gelb B-CONTRAST ....
Einstellen der Bildschirmanzeige (bei analogem Anschluss) Menü MODE SELECT Hinweise: - - Abhängig von der Auflösung des Eingangssignals ändert sich die Anzeige eventuell selbst dann nicht, wenn die Menüoptionen ausgewählt werden können. So wählen Sie eine Menüoption: Taste SELECT Nach Abschluß der Einstellung: Taste MENU OSD H-POSITION (OSD horizontale Position) Die Position der OSD-Anzeige kann nach links und ) rechts verschoben werden.
GB Einstellen der Bildschirmanzeige (bei digitalem Anschluss) WHITE BALANCE Hinweise: - Bei einer anderen Einstellung als [STD] können nicht alle Abstufungen angezeigt werden. Um alle Abstufungen anzuzeigen, stellen Sie [STD] ein. - Wählen Sie [COOL], [·], [STD], [·], [WARM] oder aus. [USER] mit den Tasten - Wenn USER ausgewählt wird, werden die Einstellwerte für [R-CONTRAST], [GCONTRAST] und [B-CONTRAST] angezeigt, damit die Feineinstellung vorgenommen werden kann.
Einstellen der Bildschirmanzeige (bei digitalem Anschluss) Menü MODE SELECT Hinweise: - Abhängig von der Auflösung des Eingangssignals ändert sich die Anzeige eventuell selbst dann nicht, wenn die Menüoptionen ausgewählt werden können. - So wählen Sie eine Menüoption: Taste SELECT - Nach Abschluß der Einstellung: Taste MENU OSD H-POSITION (OSD horizontale Position) Die Position der OSD-Anzeige kann nach links und ) rechts verschoben werden.
Gehäuse und Bedienfeld Wischen Sie das Gehäuse und das Bedienfeld mit einem weichen, trockenen Tuch vorsichtig sauber. Falls starke Verschmutzungen auftreten, geben Sie etwas neutrales Reinigungsmittel auf ein feuchtes, weiches Tuch, wringen Sie es gut aus, und wischen Sie den Monitor sauber. Die Leuchtstoffröhren des Monitors weisen eine begrenzte Lebensdauer auf. - Wenn der Bildschirm dunkler wird, ständig flimmert oder überhaupt nicht mehr leuchtet, muß die Leuchtstoffröhre evtl. erneuert werden.
Technische Daten Produktspezifikationen Abmessungen (Einheiten: mm) LCD-Anzeige 46 cm diagonal gemessen TFT LCD-Modul Auflösung (max.) SXGA 1280 x 1024 Pixel Anzeigbare Farben (max.) 16,77 Millionen Farben (8 Bit) Helligkeit (max.) 220 cd/m2 Punktabstand 0,2805 (H) x 0,2805 (V) mm Kontrastverhältnis 400:1 Blickwinkel Links-rechts 170°, oben-unten 170° Bildschirmanzeigegröße Horizontal 359 mm x vertikal 287,2 mm Videosignal Analog: Analog RGB (0,7Vp-p) [75 Ω] Digital: DVI-Standard basiert auf 1.
GB Technische Daten - - - 60Hz 72Hz 75Hz 56Hz 60Hz 72Hz 75Hz 60Hz 70Hz 75Hz 75Hz 60Hz 60Hz 75Hz 70Hz 66.7Hz 74.6Hz 75Hz 75Hz 60Hz 75Hz 60Hz 66Hz 70Hz 66Hz 76.2Hz 67.2Hz 76Hz Anzeigemodus Punktfrequenz 25.175MHz 31.5MHz 31.5MHz 36.0MHz 40.0MHz 50.0MHz 49.5MHz 65.0MHz 75.0MHz 78.75MHz 108.0MHz 108.0MHz 108.0MHz 135.0MHz 28.3MHz 30.2MHz 57.3MHz 80.0MHz 100.0MHz 108.0MHz 135.0MHz 64.13MHz 70.4MHz 74.25MHz 94.88MHz 108.23MHz 117.01MHz 134.
Technische Daten Pinbelegung des AnalogsignalEingangsanschlusses Power Management (15poliger Mini-D-Sub-Stecker) 5 4 10 15 Nr. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 3 9 14 2 8 13 Der Monitor basiert auf den Standards VESA DPMS*1 und DVI DMPM*2. Um die Power Management-Funktion des Monitors zu aktivieren, müssen sowohl die Videokarte als auch der Computer den Standards VESA DPMS und DVI DMPM entsprechen.
Je nach dem verwendeten Computer oder Betriebssystem muß die Installation der Monitor-SetupInformationen usw. eventuell über den Computer erfolgen. Führen Sie in diesem Fall die unten beschriebenen Schritte zum Installieren der MonitorSetup-Informationen aus. (Je nach dem verwendeten Computertyp oder Betriebssystem können die Befehlsnamen und Verfahren von den hier beschriebenen abweichen. Lesen Sie auch das Benutzerhandbuch Ihres Computers.
Installieren der Setup-Informationen und des ICC-Profils (Für Windows) Für Windows 2000 Für Windows Me Installieren der Monitor-Setup-Informationen unter Windows 2000 und Festlegen des Monitor-ICCProfils als vorbestimmter Wert. Die in den nachstehenden Bedienungshinweisen erwähnten Windows-Meldungen basieren auf der englischen Windows-Version. Dabei wird von “Laufwerk A” als Diskettenlaufwerk ausgegangen. 1. Legen Sie die (mitgelieferte) Utility Disk in Laufwerk A des Computers ein. 2.
Für Windows XP GB Installieren der Setup-Informationen und des ICC-Profils (Für Windows) F Bei Verwendung des ICC-Profils setzen Sie [WHITE BALANCE] auf [STD]. E - I Installieren des Monitor-ICC-Profils (Wenn die SetupInformationen bereits installiert wurden, ist auch das Profil bereits installiert. Es braucht dann nicht mehr extra installiert zu werden.) Dabei wird von “Laufwerk A” als Diskettenlaufwerk ausgegangen. 1. Legen Sie die (mitgelieferte) Utility Disk in Laufwerk A des Computers ein. 2.
Informationen zum Profil ColorSync (Für MacOS) Informationen zum Profil ColorSync ColorSync ist das Farbverwaltungssystem der Apple Corporation. Damit erkennt das System die Farbauflösung bei Verwendung mit einer kompatiblen Anwendung. Ein ColorSync-Profil beschreibt die Farbeigenschaften des LCD-Monitors. Hinweise: - Das ColorSync-Profil dieses Monitors kann zusammen mit MacOS8.5 oder höher eingesetzt werden. - Bei Verwendung des Profils ColorSync setzen Sie [WHITE BALANCE] auf [STD].
Ein Arm oder Fuß basierend auf dem VESA-Standard (separat erhältlich) kann am Monitor angebracht werden. Der Arm oder Fuß muß vom Kunden gesondert erworben werden. 6. Lösen Sie die vier Schrauben, und nehmen Sie den Monitorfuß ab. GB Deutsch Anweisungen zum Anbringen eines VESAkompatiblen Monitorarms Verwendbare Arme oder Füße Hinweise: - Der Fuß ist nur für diesen Monitor bestimmt, verwenden Sie ihn für keine anderen Geräte oder nutzen Sie ihn auf keine andere Weise.
D Français I 60 61 63 64 64 65 66 68 68 68 69 69 69 70 70 70 70 71 71 72 75 77 77 77 77 78 81 84 85 E Avis aux utilisateurs américains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TCO'95/'99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Avis aux utilisateurs européens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Avis aux utilisateurs américains Déclaration FCC AVERTISSEMENT – La réglementation FCC stipule que toute modification/changement non autorisé(e) apporté(e) à cet équipement et non expressément approuvé(e) par le fabricant peut annuler la capacité de l'utilisateur à se servir dudit équipement. Remarque : Cet équipement a été testé et jugé conforme aux limites d'un appareil numérique de Classe B, conformément à la section 15 de la réglementation FCC.
Qu’implique la labellisation environnementale ? Les exigences environnementales ont été développées par Svenska Naturskyddsforeningen (Société suédoise pour la protection de la nature). Ces exigences imposent des restrictions à la présence et à l’usage de métaux lourds, de retardateurs de flamme au brome et au chlore, des CFC (fréons) et des solvants chlorés - parmi d’autres choses.
Exigences environnementales Retardateurs de flamme Les retardateurs de flamme sont présents dans les cartes à circuits imprimés, les câbles , les fils, les boîtiers et enceintes closes. Leur objectif est de prévenir, ou tout au moins de retarder, la propagation du feu. Jusqu’à 30 % du plastique contenu dans un boîtier d’ordinateur peut être composé de substances retardatrices de flamme.
This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. GB Avis aux utilisateurs européens Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. D Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillæg nr. 93/68/EEC.
Avis aux utilisateurs britanniques Destiné aux clients britanniques IMPORTANT Les fils du câble d'alimentation portent le code de couleurs suivant : VERT/JAUNE : Terre BLEU : Neutre MARRON : Phase Étant donné que les fils du câble d'alimentation de cet appareil peuvent ne pas correspondre aux marques colorées identifiant les bornes de votre prise, veuillez procéder de la manière suivante.
- - - Moniteur et liste des accessoires - S’assurer que les éléments suivants sont bien présents dans l’emballage: - Moniteur LCD (1) - Adaptateur secteur (1) (nom du modèle : NL-A61J) - Câble du signal analogique (1) (nom du modèle : 0LTGD15180001) - Disque utilitaire (pour Windows/Macintosh) (1) - Mode d’emploi (1) Remarques : - Le câble de signal numérique (DVI-D 24 broches) est fourni séparément.
Description du produit 11 11 11 7 1 2 3 4 8 9 10 5 6 1. Bouton INPUT ...................................... Pour passer d’une borne d’entrée du signal à l’autre. (Borne d’entrée du signal analogique ↔ Borne d’entrée DVI-D) 2. Bouton MENU ...................................... Ce bouton est utilisé pour faire apparaître, sélectionner et refermer le menu OSD (On Screen Display). 3. Bouton SELECT ..................................
GB Description du produit Relevage et réglage de l’inclinaison du moniteur D Attention : - Une pression des mains sur l’écran LCD peut provoquer un endommagement. - prendre garde de ne pas se coincer les doigts. I Français Relevage du moniteur Appuyer sur le support et relever la partie supérieure du moniteur. E Repliement du moniteur 1. Enlever l’adaptateur secteur et câble de signal RVB. 2. Si des réglages sont apportés au moniteur, il convient de placer celui-ci à la verticale. 3.
Raccordement, activation et désactivation du moniteur Attention : - Lors du raccordement, s’assurer que l’alimentation tant du moniteur que de l’ordinateur est désactivée. - Ne pas courber le câble de manière excessive ni y ajouter de rallonge car cela peut provoquer un dysfonctionnement. Raccordement numérique RVB Connexion du moniteur à un ordinateur via un câble de signal numérique.
GB Raccordement, activation et désactivation du moniteur Attention : - Après avoir débranché l’adaptateur secteur ou le cordon d’alimentation, assurez-vous d’attendre au moins 10 secondes avant de le rebrancher. Si vous rebranchez l’appareil immédiatement après l’avoir débranché, il risque d’être endommagé et l’écran risque de ne pas fonctionner correctement ou ne pas afficher d’image. 1. Mettre l’ordinateur hors tension. 2. Presser le bouton d’alimentation du moniteur. La diode d’alimentation s'éteind.
Réglage de l’image au moniteur Pour le signal analogique 1. Effectuer tout d’abord un réglage automatique. (p. 71) 2. Effectuer au besoin un réglage manuel. (p. 72) Pour le signal numérique Le moniteur peut généralement être utilisé sans réglage. Effectuer au besoin un réglage manuel. (p. 75) Fonction de verrouillage des réglages En désactivant les boutons de commande (c’est-àdire en les verrouillant), toute tentative de modification des valeurs sera vaine. 1. Mettre l’ordinateur hors tension. 2.
GB Réglage de l’image du moniteur (avec un raccordement analogique) Comment procéder aux réglages Réglage automatique de l'image 1. Presser le bouton MENU. Le menu ADJUSTMENT s'affiche. D'abord afficher une image qui rend la totalité de l'écran du moniteur très lumineuse. Si l’on se trouve sous un environnement Windows, on peut se servir du Modèle de réglage se trouvant sur le disque utilitaire. Remarques : - Dans la plupart des cas, le réglage automatique s'avère suffisant.
Réglage de l’image du moniteur (avec un raccordement analogique) Menu ADJUSTMENT Réglage manuel de l’image Des réglages peuvent être effectués au moyen du menu du moniteur actif (OSD) proposé. Affichage à l’écran pour le réglage Si l’on se trouve sous un environnement Windows, ouvrir le Modèle de réglage se trouvant sur le disque utilitaire. (p. 71) Si le système utilisé ne se trouve pas sous un environnement Windows, il est impossible d’utiliser le Modèle de Réglage.
GB Réglage de l’image du moniteur (avec un raccordement analogique) Menu WHITE BALANCE MANUEL : Les options individuelles du menu sont réglées manuellement. AUTO : Chaque option du menu est automatiquement réglée via la fonction de Auto Gain Control*. Remarques : - En ce qui concerne les paramètres autres que les [STD], toutes les graduations ne peuvent pas être affichées. Pour afficher toutes les graduations, définir le paramètre sur [STD].
Réglage de l’image du moniteur (avec un raccordement analogique) Menu MODE SELECT LANGUAGE (LANGUE) Il est possible de choisir la langue d’affichage du menu OSD. 1. Enfoncer le bouton . Le menu de sélection de la langue d’affichage (LANGUAGE) apparaît. 2. Sélectionner la langue souhaitée via le bouton SELECT. 3. Presser le bouton MENU ou le bouton , et le menu de sélection de la langue d’affichage disparaîtra.
GB Réglage de l'image du moniteur (avec un raccordement numérique) Menu WHITE BALANCE Des réglages peuvent être effectués au moyen du menu interactif (OSD) proposé. Comment procéder aux réglages 1. Presser le bouton MENU. Le menu WHITE BALANCE s’affiche. À ce stade, les options principales du menu peuvent être réglées. À chaque fois que le bouton MENU est pressé, le menu suivant est sélectionné. (Le menu WHITE BALANCE → MODE SELECT → le menu OSD disparaît) COOL .....
Réglage de l’image du moniteur (avec un raccordement numérique) Menu MODE SELECT Remarques : - En fonction de la résolution du signal d’entrée, même si les options peuvent être sélectionnées, l’affichage ne peut pas être modifié. - Pour choisir une option du menu: Bouton SELECT - Lorsque le réglage est terminé: Bouton MENU OSD H-POSITION (positionnement horizontal OSD) Le positionnement de l’affichage OSD peut être modifié vers la gauche et vers la droite.
Si le moniteur est jugé défectueux, vérifier les points suivants avant de l’emmener en réparation. Si après cela, il ne fonctionne toujours pas correctement, contacter le magasin où il a été acheté ou votre mainteneur agréé Sharp le plus proche. Châssis et panneau de réglage Utiliser un chiffon doux et sec pour éliminer les poussières du chassis et du panneau de réglage.
Caractéristiques techniques Caractéristiques techniques du produit Dimensions (Unités : mm) 420 372 422 Moniteur LCD 46 cm en diagonale Module TFT à cristaux liquides Résolution (max.) SXGA 1280 X 1024 pixels Couleurs affichables (max.) 16,77 millions de couleurs (8 bits) Luminosité (max.
GB Caractéristiques techniques Saisie de texte US Série Macintosh Série Sun Ultra - - - 31.5kHz 37.9kHz 37.5kHz 800x600 35.1kHz 37.9kHz 48.1kHz 46.9kHz 1024x768 48.4kHz 56.5kHz 60.0kHz 1152x864 67.5kHz 1280x960 60.0kHz 1280x1024 64.0kHz 80.0kHz 720x400 31.5kHz 640x480 35.0kHz 832x624 49.7kHz 1024x768 60.2kHz 1152x870 68.7kHz 1280x1024 64.0kHz 80.0kHz 1024x768 48.3kHz 53.6kHz 56.6kHz 1152x900 61.8kHz 71.8kHz 1280x1024 71.7kHz 81.
Caractéristiques techniques La broche du connecteur d’entrée du signal analogique Gestion de l’alimentation (Mini connecteur de type D-sub 15 broches) 5 4 10 15 N° 3 9 14 2 8 1 7 13 Le moniteur est basé sur les normes VESA DPMS*1 et DVI DMPM*2 Pour activer la fonction de gestion de l’alimentation du moniteur, la carte vidéo et l'ordinateur doivent être conformes aux normes VESA DPMS et DVI DMPM.
En fonction du type d’ordinateur ou du système d’exploitation, il peut parfois s’avérer nécessaire d’utiliser l’ordinateur pour consulter les paramètres relatifs à la configuration du moniteur. Si c’est le cas, il convient de procéder comme suit pour installer sur l’ordinateur les fichiers relatifs à la configuration du moniteur. Le nom des commandes et les procédures peuvent varier en fonction du type d’ordinateur ou du système d’exploitation.
Installation des fichiers relatifs au paramétrage du moniteur et au profil ICC (Pour Windows) Pour Windows 2000 Pour Windows Me Installation des fichiers relatifs au paramétrage du moniteur sous Window2000, et au réglage du profil ICC du moniteur en tant que valeur par défaut. Les messages Windows mentionnés dans le mode d´emploi suivant se réfèrent à la version anglaise de Windows. Les explications qui suivent considèrent que le lecteur de disquettes est le "lecteur A". 1.
GB Installation des fichiers relatifs au paramétrage du moniteur et au profil ICC (Pour Windows) Français Lors de l’utilisation du profil ICC, régler la [WHITE BALANCE] sur [STD]. E - I Installation du profile ICC du moniteur (Si l’information relative à l’installation a déjà été installée, alors le profile l’a été également, et il n’est donc plus nécessaire de l’installer.) Les explications qui suivent considèrent que le lecteur de disquettes est le "lecteur A". 1.
Informations sur le profil ColorSync (Pour MacOS) A propos du profile ColorSync ColorSync est le système de gestion des couleurs de Apple Corporation et est une fonction qui permet de d’optimiser l’affichage des couleurs lors d’une utilisation avec une application compatible. Un profil ColorSync décrit les caractéristiques de couleur du moniteur LCD. Remarques : - Le profil ColorSync de ce moniteur fonctionne sous MacOS8.5 ou version ultérieure.
6. Enlever les quatre vis et ensuite le support du moniteur. D Un bras ou un support conforme à la norme VESA (à acheter séparément) peut servir de support au moniteur. L’acquisition du bras ou du support est laissée à l’appréciation du client. GB Instructions relatives à l’installation d’un bras conforme VESA Remarques : - Le support est conçu spécifiquement pour ce moniteur, ne pas l'utiliser pour un autre équipement ou à d'autres fins.
D F Italiano 88 89 91 92 92 93 94 96 96 96 97 97 97 98 98 98 98 99 99 100 103 105 105 105 105 106 109 112 113 E Avviso per gli utenti negli the USA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TCO '95/ '99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Avviso per gli utenti in Europa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Avviso per gli utenti negli the USA Dichiarazione FCC AVVERTIMENTO – I regolamenti FCC stabiliscono che qualsiasi cambiamento o modifica, apportati a quest'apparecchio senza l'espressa approvazione del fabbricante, possono invalidare la facoltà dell'utente di mettere in funzione questo apparecchio. Nota : Questo apparecchio è stato sottoposto a prova e si è constatato che esso rientra nei limiti stabiliti per un dispositivo digitale di classe B in conformità alla Parte 15 dei regolamenti FCC.
GB D Perché serve riconoscere i computer rispettosi dell’ambiente? In molti paesi, la classificazione in base all’impatto sull’ambiente è diventato un metodo stabilito per incoraggiare l’adeguamento di beni e servizi alle esigenze del rispetto dell’ambiente. Il problema principale, per quanto riguarda i computer e le altre apparecchiature elettroniche, è dovuto al fatto che nei prodotti, e durante il processo di produzione dei prodotti, si usano sostanze pericolose per l’equilibrio dell’ambiente.
Requisiti ambientali Additivi ignifughi Gli additivi ignifughi sono presenti in circuiti stampati, cavi, fili, rivestimenti e alloggiamenti. Il loro scopo consiste nel prevenire o almeno ritardare l’espandersi delle fiamme. Fino al 30% dei materiali plastici di cui sono formati gli alloggiamenti dei computer è costituito da additivi ignifughi.
This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. GB Avviso per gli utenti in Europa Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. D Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/ EEG.
Avviso per gli utenti nel Regno Unito PER CLIENTI NEL REGNO UNITO IMPORTANTE I conduttori in questo cavo di collegamento alla rete sono colorati conformemente al seguente codice: VERDE E GIALLO : Terra BLU : Neutro MARRONE : Sotto tensione Dato che i colori dei conduttori nel cavo rete di quest'apparecchiatura potrebbero non corrispondere ai contrassegni colorati che identificano i terminali nella vostra spina, procedete come segue.
- - - Lista di controllo del monitor e degli accessori - Per favore controllate che la confezione contenga i seguenti articoli. - Monitor LCD (1) - Adattatore AC (1) (nome del modello: NL-A61J) - Cavo del segnale analogico (1) (nome del modello: 0LTGD15180001) - Dischetto dei programmi di utilità (per Windows/Macintosh) (1) - Manuale operativo (1) Note - Il cavo segnali digitali (DVI-D24 pin – DVI-D24 pin) va acquistato separatamente.
Descrizione del prodotto 11 11 11 7 1 2 3 4 8 9 10 5 6 1. Tasto INPUT ........................................................ Per commutare tra i terminali di ingresso del segnale. (Terminale di ingresso del segnale analogico ↔ Terminale di ingresso DVI-D) 2. Tasto MENU ........................................................ Questo tasto si usa per visualizzare, selezionare e chiudere il menu OSD (On Screen Display). 3. Tasto SELECT ....................................................
GB Descrizione del prodotto Collocare il monitor verticalmente e regolarlo ATTENZIONE: - La pressione con le mani sul pannello LCD può produrre dei danni. Fare attenzione a non rimanere con le dita incastrate. D - Italiano F Mettere su il monitor Premete verso il basso sul supporto ed alzate la sezione superiore del monitor. E Ripiegare il monitor 1. Rimuovete l’adattatore AC e cavo del segnale RGB. 2. Se eseguite delle regolazioni sul monitor, disponetelo verticalmente. 3.
Collegamento del monitor ed accensione e spegnimento del monitor Collegamento RGB digitale Collegamento del monitor ad un computer Usando il cavo per segnale digitale, che è un accessorio, collegare usando il terminale d’uscita RGB digitale del computer. - Per il collegamento RGB digitale, il monitor ha un ingresso per il collegamento a un computer con un connettore d’uscita DVI compatibile (DVI-D a 24 pin o DVI-I a 29 pin) e capacità d’uscita SXGA.
GB Collegamento del monitor ed accensione e spegnimento del monitor ATTENZIONE: - Dopo aver disinserito la spina dell’adattatore per AC o del cavo di alimentazione, bisogna attendere almeno 10 secondi prima di ricollegare queste sorgenti di alimentazioni. Se dopo aver disinserito una spina di una sorgente di alimentazione la si reinserisce subito, senza attendere, è possibile che il prodotto si guasti e lo schermo non funzionerà correttamente o non visualizzerà immagini. 1. Spegnete il computer. 2.
Regolazione della visualizzazione sullo schermo Per il segnale analogico 1. Prima di tutto eseguite una regolazione automatica. (p. 99) 2. Eseguite la regolazione manuale, se necessario. (p. 100) Per il segnale digitale Di solito si può utilizzare il monitor senza regolarlo. Se necessario, eseguite la regolazione manuale. (p. 103) Funzione di blocco delle regolazioni Disattivando i tasti di controllo (cioè settando il blocco) si impedirà ogni tentativo di cambiare i valori regolati. 1.
GB Regolazione della visualizzazione sullo schermo (con collegamento analogico) Come eseguire la regolazione Regolazione automatica dello schermo 1. Premete il tasto MENU. Il menu ADJUSTMENT verrà visualizzato. D Le opzioni nel menu ADJUSTMENT (REGOLAZIONE) si possono regolare automaticamente (CLOCK, PHASE (FASE) , H-POS V-POS). Note: - Nella maggioranza dei casi la regolazione automatica è sufficiente.
Regolazione della visualizzazione sullo schermo (con collegamento analogico) Menu ADJUSTMENT (REGOLAZIONE) Regolazione manuale dello schermo Le regolazioni si possono fare mediante il menu On Screen Display (OSD) fornito. On Screen Display per la regolazione Se state utilizzando Windows, potete usare il monoscopio sul Disco delle Utilità accluso. (p. 99) Se il vostro sistema non è Windows, non potete usare il monoscopio.
Menu WHITE BALANCE (BILANCIAMENTO DEL BIANCO) COOL .... tonalità del colore più tendente al blu rispetto allo standard • ......... tonalità del colore leggermente più tendente al blu rispetto allo standard STD ...... Impostazione standard della tonalità di colore • ......... Tonalità del colore leggermente più tendente al rosso rispetto allo standard WARM .. tonalità di colore più tendente al rosso rispetto allo standard USER tasto per blu - verde R-CONTRAST ....
Regolazione della visualizzazione sullo schermo (con collegamento analogico) Menu MODE SELECT Note: - A seconda della risoluzione del segnale di input, anche se si possono selezionare delle opzioni di menu, il display potrebbe non cambiare. - Per selezionare un'opzione di menu: Tasto SELECT - Quando la regolazione è stata completata: Tasto MENU OSD H-POSITION (posizione orizzontale dell'OSD) La posizione del display dell'OSD si può spostare ) verso sinistra e verso destra.
Menu WHITE BALANCE (BILANCIAMENTO DEL BIANCO) D Le regolazioni si possono fare mediante il menu On Screen Display (OSD) fornito. GB Regolazione della visualizzazione sullo schermo (con collegamento digitale) On Screen Display per la regolazione A questo punto si possono regolare le opzioni di menu rilevanti. Ogni volta che si preme il tasto MENU, viene selezionato il menu successi.
Regolazione della visualizzazione sullo schermo (con collegamento digitale) Menu MODE SELECT Note: - A seconda della risoluzione del segnale di input, anche se si possono selezionare delle opzioni di menu, il display potrebbe non cambiare. - Per selezionare un'opzione di menu: Tasto SELECT - Quando la regolazione è stata completata: Tasto MENU OSD H-POSITION (posizione orizzontale dell'OSD) La posizione del display dell'OSD si può spostare ) verso sinistra e verso destra.
GB Cura e riparazione del monitor Sezione pannello LCD Usate un panno morbido ed asciutto per portare via la sporcizia e la polvere dalla superficie del pannello LCD. (E’ adatto un panno morbido come la garza oppure quello che si usa per pulire le lenti.) ATTENZIONE! - - Non usate mai dei solventi, della benzina, dell’alcol, del detersivo per vetri, ecc. in quando ciò può dare luogo a cambiamenti di colore o di forma.
Specifiche Dimensioni (Unità: mm) Display LCD 46 cm misurati diagonalmente Modulo TFT LCD Risoluzione (max.) SXGA 1280 X 1024 pixel Colori visualizzabili (max.) 16.77 million di colori (8 bit) Luminosità (max.) 220cd/m2 Dimensione dei pixel 0,2805(H) x 0,2805(V) mm Rapporto del contrasto 400:1 Angolo di visibilità Sinistra - destra 170°; alto - basso 170° Dimensioni di visualizzazione dello schermo Orizzontale 359 mm X Verticale 287,2 mm Segnale video Analogico: RGB analogico (0.
GB Specifiche - - - 60Hz 72Hz 75Hz 56Hz 60Hz 72Hz 75Hz 60Hz 70Hz 75Hz 75Hz 60Hz 60Hz 75Hz 70Hz 66.7Hz 74.6Hz 75Hz 75Hz 60Hz 75Hz 60Hz 66Hz 70Hz 66Hz 76.2Hz 67.2Hz 76Hz 25.175MHz 31.5MHz 31.5MHz 36.0MHz 40.0MHz 50.0MHz 49.5MHz 65.0MHz 75.0MHz 78.75MHz 108.0MHz 108.0MHz 108.0MHz 135.0MHz 28.3MHz 30.2MHz 57.3MHz 80.0MHz 100.0MHz 108.0MHz 135.0MHz 64.13MHz 70.4MHz 74.25MHz 94.88MHz 108.23MHz 117.01MHz 134.99MHz La risoluzione consigliata è 1280 x 1024. Tutti sono conformi solo al non interlacciamento.
Specifiche I pin del connettore di ingresso del segnale analogico Gestione dell'energia (Connettore D sub mini a 15 pin) 5 4 3 10 15 9 14 N° 2 8 13 Il monitor è basato sulle norme VESA DPMS*1 e DVI DMPM*2 . Per attivare la funzione della gestione dell'energia del monitor, sia la scheda video che il computer devono essere conformi alle norme VESA DPMS e DVI DMPM. 1 7 12 6 11 *1 DPMS: Display Power Management Signalling Sinc. Sync.
Per Windows95 Installazione delle informazioni per il setup del monitor in Windows95. I messaggi di Windows, citati nelle istruzioni per l´uso che seguono, si basano sulla versione inglese di Windows. In questa spiegazione si parte dall'ipotesi che l'unità per dischetti floppy sia "A". 1. Inserite il Disco delle Utilità (fornito) nel drive A del computer. 2. Fate clic sul pulsante [Start]. Da [Settings], scegliete [Control Panel]. 3. Fate doppio clic su [Display]. 4.
Installazione delle informazioni per il setup e del profilo ICC (Per Windows) Per Windows2000 Installazione delle imformazioni di setup del monitor in Windosw2000, e impostazione del profilo ICC del monitor come valore predeterminato. I messaggi di Windows, citati nelle istruzioni per l´uso che seguono, si basano sulla versione inglese di Windows. In questa spiegazione si parte dall'ipotesi che l'unità per dischetti floppy sia "A". 1. Inserite il Disco delle Utilità (fornito) nel drive A del computer. 2.
GB Installazione delle informazioni per il setup e del profilo ICC (Per Windows) - F Italiano Quando usate il profilo ICC , per favore impostate [WHITE BALANCE] su [STD]. E Installazione delle imformazioni di setup del monitor in WindoswXP, e impostazione del profilo ICC del monitor come valore predeterminato. I messaggi di Windows, citati nelle istruzioni per l´uso che seguono, si basano sulla versione inglese di Windows.
Informazioni sul profilo ColorSync (Per MacOS) Il profilo ColorSync ColorSync è il sistema di gestione del colore della Apple Corporation ed è una funzione che consente di realizzare la risoluzione del colore, quando lo si usa con un'applicazione compatibile. Un profilo ColorSync descrive le caratteristiche cromatiche del monitor LCD. Note: - Il profilo ColorSync di questo monitor funziona con MacOS8.5 o superiore. - Quando usate il profilo ColorSync, per favore impostate [WHITE BALANCE] su [STD].
E’ possibile collegare al monitor un braccio oppure un supporto basati sullo standard VESA (acquistati separatamente). L’acquisto del braccio oppure del supporto è a discrezione del cliente. 7. Attaccate il braccio al monitor con le quattro viti. Italiano Note: - Il supporto è progettato appositamente per questo monitor, non usatelo per altri apparecchi e scopi.
Nota para usuarios en EE.UU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TCO’95/'99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nota para usuarios en Europa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nota para usuarios en el Reino Unido . . . . . . . . . . . . . . . . . . . .
Nota para usuarios en EE.UU. Certificación FCC PRECAUCIÓN - Las regulaciones FCC determinan que cualquier cambio o modificación introducida en el presente equipo no autorizada expresamente por la marca puede conducir a la anulación del permiso de uso del mismo. Nota: Este equipo ha sido comprobado y cumple los valores límites para equipos digitales de la Categoría B conforme a la Sección 15 de las normas FCC.
LL-T1803-B LL-T1803-H ¿Por qué ofrecemos ordenadores con distintivo medioambiental? En numerosos países, el distintivo ambiental se ha convertido en un método establecido para alentar la adaptación de productos y servicios para el entorno ecológico. El problema principal, en cuanto a los ordenadores y otros equipos electrónicos se refiere, es que tanto en los productos como en su fabricación se usan sustancias perjudiciales para el medio ambiente.
Requisitos medioambientales Productos antiinflamantes Los productos antiinflamantes se encuentran en las tarjetas de circuitos impresos, cables, hilos, cajas y carcasas. Su finalidad es la de prevenir o, al menos, retardar la propagación del fuego. Hasta el 30% del plástico de la carcasa de un ordenador puede estar compuesto de sustancias antiinflamantes.
Nota para usuarios en Europa This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/ EEG.
Nota para usuarios en el Reino Unido PARA CLIENTES EN EL REINO UNIDO IMPORTANTE Los colores de los conductores en este cable de alimentación están definidos conforme al siguiente código: VERDE Y AMARILLO : Tierra AZUL : Neutro MARRÓN : Conductor de corriente Puesto que los colores de identificación del cable de alimentación del presente equipo pueden no corresponder con las señales de color que identifican su enchufe, proceda de la forma siguiente.
Sugerencias y precauciones de seguridad - - - - - - Bajo determinadas circunstancias pueden apreciarse diminutas manchas o puntos. Esto es normal en el caso de monitores de cristal líquido y no se trata de una anomalía. El panel LCD ha sido fabricado con la tecnología más sofisticada y avanzada. Pixels operando correctamente incluyen el 99,99% del total de pixels. No obstante, debe saber que el 0,01% o menos de los pixels puede fallar o ser un poco más brillante de lo normal.
Descripción del producto 11 11 11 7 1 2 3 4 8 9 10 5 6 1. Botón INPUT ................................................ Para conmutar entre los bornes de entrada de la señal. (Borne de entrada de señal analógica ↔ Borne de entrada DVI-D) 2. Botón MENU ................................................ Este botón se utiliza para ampliar, seleccionar y cerrar el menú OSD (On Screen Display). 3. Botón SELECT ............................................
Descripción del producto Levantamiento y ajuste del monitor Precaución: - Si presiona el panel LCD con las manos podría dañarlo. - Tenga cuidado para que sus dedos no queden atrapados. Levantamiento del monitor Ejerza presión sobre la base y levante la sección superior del monitor. Español Bajada del monitor 1. Retire el adaptador de CA y cable de señal RGB. 2. Si va a ajustar el monitor, colóquelo en posición vertical. 3.
Conexión del monitor y encendido/ apagado del mismo Precaución: - Antes de realizar la conexión, asegúrese de que tanto el monitor como el ordenador están apagados. - Tenga cuidado de no doblar excesivamente el cable ni utilizar cables de prolongación ya que ello podría llevar a un funcionamiento anómalo. Conexión RGB digital Conexión del monitor a un ordenador a través de un cable de señal digital .
Conexión del monitor y encendido/apagado del mismo Precaución: - Después de desenchufar el cable de alimentación o el adaptador de CA, asegúrese de esperar un mínimo de 10 segundos antes de volver a enchufarlos. Si enchufa la clavija inmediatamente después de haberla desenchufado, podrán producirse daños y la pantalla funcionará mal o no mostrará nada. Apagado 1. Apague el ordenador. 2. Pulse el botón de encendido/apagado del monitor. El LED indicador de conexión se apagará.
Ajuste de la pantalla Para la señal analógica 1. En primer lugar, lleve a cabo un ajuste automático. (p. 127) 2. En caso necesario, realice un ajuste manual. (p. 128) Para la señal digital Normalmente no es necesario ajustar el monitor antes de utilizarlo. En caso necesario, realice un ajuste manual. (p. 131) Función de bloqueo de ajustes Nota: - Todos los ajustes quedarán guardados incluso después de apagar.
Ajuste de la pantalla (con conexión analógica) Cómo realizar el ajuste Ajuste automático de la pantalla 1. Pulse el botón MENU. Aparecerá el menú ADJUSTMENT. Las opciones del Menú ADJUSTMENT (RELOJ, FASE, H-POS V-POS) se pueden ajustar automáticamente. Nota: - Al configurar por primera vez el monitor o tras cambiar cualquier aspecto del sistema actual, lleve a cabo un ajuste automático de la pantalla antes de su uso. En primer lugar aparece una imagen que pone toda la pantalla muy clara.
Ajuste de la pantalla (con conexión analógica) Ajuste manual de la pantalla Menú ADJUSTMENT Los ajustes se pueden realizar a través del Menú en pantalla (OSD). Máscara en pantalla para el ajuste Si está utilizando Windows, abra la Carta de ajuste incluida en el Disquete de utilidades. (p. 127) Si su sistema no es Windows, no podrá utilizar la Carta de ajuste. En tal caso, haga que aparezca una imagen que aclare toda la pantalla y ajústela comprobando visualmente su tono real. Cómo realizar el ajuste 1.
Ajuste de la pantalla (con conexión analógica) Menú WHITE BALANCE MANUAL: Las diferentes opciones del menú se ajustan manualmente. AUTO: Cada opción del menú se ajusta automáticamente con la función Control Automático de la Ganancia*. Notas: para seleccionar AUTO.
Ajuste de la pantalla (con conexión analógica) Menú MODE SELECT Notas: - Según sea la resolución de la señal de entrada, la pantalla puede no cambiar incluso si pueden seleccionarse las opciones del menú. - Para seleccionar una opción del menú: Botón SELECT - Una vez finalizados los ajustes: Botón MENU OSD H-POSITION (posición horizontal OSD) La posición de la pantalla OSD puede desplazarse ) hacia la izquierda y hacia la derecha.
Ajuste de la pantalla (con conexión digital) Los ajustes se pueden realizar a través del menú Máscara en pantalla (OSD). Menú WHITE BALANCE Máscara en pantalla para el ajuste Cómo realizar el ajuste 1. Pulse el botón MENU. Aparecerá el menú WHITE BALANCE. Notas: - No todos los colores pueden verse en ajustes diferentes a [STD]. Ajuste a [STD] para ver todas las graduaciones. para seleccionar [COOL], - Utilice los botones [·], [STD], [·], [WARM] o [USER].
Ajuste de la pantalla (con conexión digital) Menú MODE SELECT Notas: - Según sea la resolución de la señal de entrada, la pantalla puede no cambiar incluso si pueden seleccionarse las opciones del menú. - Para seleccionar una opción del menú: Botón SELECT - Una vez finalizados los ajustes: Botón MENU OSD H-POSITION (posición horizontal OSD) La posición de la pantalla OSD puede desplazarse ) hacia la izquierda y hacia la derecha.
Conservación y reparación del monitor Conservación del monitor Solución de problemas Desenchufe siempre la clavija de la toma de corriente alterna antes de limpiar el monitor. Si cree que el monitor pudiera estar averiado, compruebe los puntos siguientes antes de llevarlo a reparar. Si después de ello sigue sin funcionar, póngase en contacto con su proveedor o con el servicio autorizado de asistencia técnica de Sharp más cercano. Los tubos fluorescentes del monitor tienen una vida útil limitada.
Especificaciones Dimensiones (Unidades: mm) 422 420 Display LCD 46 cm medidos en diagonal Módulo TFT LCD Resolución (máx.) SXGA 1280 x 1024 pixels Colores reproducibles (máx.) 16,77 millones de colores (8 bits) Luminosidad (máx.) 220cd/m2 Retícula 0,2805(H) x 0,2805(V) mm Relación de contraste 400:1 Ángulo de visibilidad Izquierda-derecha 170°; arriba-abajo 170° Tamaño de pantalla Horizontal 359 mm x Vertical 287,2 mm Señal vídeo Analógica: Analógica RGB (0.7Vp-p) [75W] Digital: Estándar DVI basado en 1.
Especificaciones Modo display VESA US text Series Power Macintosh Series Sun Ultra - - - 640x480 Hsync 31.5kHz 37.9kHz 37.5kHz 800x600 35.1kHz 37.9kHz 48.1kHz 46.9kHz 1024x768 48.4kHz 56.5kHz 60.0kHz 1152x864 67.5kHz 1280x960 60.0kHz 1280x1024 64.0kHz 80.0kHz 720x400 31.5kHz 640x480 35.0kHz 832x624 49.7kHz 1024x768 60.2kHz 1152x870 68.7kHz 1280x1024 64.0kHz 80.0kHz 1024x768 48.3kHz 53.6kHz 56.6kHz 1152x900 61.8kHz 71.8kHz 1280x1024 71.7kHz 81.
Especificaciones Vías del conector de entrada de señales analógicas (Conector Mini D-sub de 15 vías) 5 4 3 10 15 Nº 9 14 2 8 13 1 7 12 6 11 El monitor está basado en los estándares VESA DPMS*1 y DVI DMPM*2. Para activar la función Power Management del monitor, tanto la tarjeta de vídeo como el ordenador deben cumplir el estándar VESA DPMS y el estándar DVI DMPM.
Instalación de la información de configuración y del perfil ICC (Para Windows) Según sea el tipo de ordenador o de sistema operativo, puede que sea necesario utilizar el ordenador para llevar a cabo la instalación de la información de configuración del monitor, etc. Si así fuera, siga los pasos que se indican a continuación para instalar la información de configuración del monitor.
Instalación de la información de configuración y del perfil ICC (Para Windows) Para WindowsMe Para Windows2000 Instalación de la información de configuración del monitor en Windows2000 y configuración del perfil ICC del monitor como valor predeterminado. Los mensajes de Windows mencionados a continuación se refieren la versión inglesa. En la explicación se da por supuesto que la unidad de disquetes es la "A". 1. Introduzca el Disquete de utilidades (Utility Disk) en la unidad A del ordenador. 2.
Instalación de la información de configuración y del perfil ICC (Para Windows) Instalación del perfil ICC Para WindowsXP Instalación del perfil ICC del monitor. (Si ya ha instalado la información de configuración, se habrá instalado también el perfil por lo que no hace falta que lo vuelva a instalar). Los mensajes de Windows mencionados a continuación se refieren a la versión inglesa. En la explicación se da por supuesto que la unidad de disquetes es la "A". 1.
Información acerca del perfil ColorSync (Para MacOS) Acerca del perfil ColorSync ColorSync es el sistema de gestión del color de Apple Corporation y se trata de una función que permite obtener una resolución cromática cuando se utiliza con una aplicación compatible. Un perfil ColorSync describe las características cromáticas del monitor LCD. Notas: - El perfil ColorSync de este monitor funciona con MacOS8.5 o superior. - Si utiliza el perfil ColorSync, en [WHITE BALANCE] seleccione [STD].
Instrucciones para acoplar un brazo de compatibilidad VESA Puede acoplar al monitor un brazo o una base (que se adquiere aparte) conforme al estándar VESA. La adquisición del brazo o la base queda a discreción del cliente. 6. Retire los cuatro tornillos y a continuación retire la base del monitor.
