LCD Monitor LCD Farbmonitor Moniteur LCD Monitor LCD Monitor LCD LL-171A LL-171G OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D'EMPLOI MANUALE D'USO MANUAL DE FUNCIONAMIENTO LL-171A 171AG_cover1-2.
WARNING – FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user's authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Notice for Users in Europe This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/ EEG.
Deutsch Français Español Italiano FOR CUSTOMERS IN U.K.
TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use.
Deutsch Français Italiano English Español Tips and safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Angle adjustment, height adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips and safety precautions Location - Do not use the monitor where ventilation is poor, where there is a lot of dust, where humidity is high, or where the monitor may come into contact with oil or steam, as this could lead to fire. - Ensure that the monitor does not come into contact with water or other fluids. Ensure that no objects such as paper clips or pins enter the monitor as this could lead to fire or electric shock. - Do not place the monitor on top of unstable objects or in unsafe places.
Deutsch English Español Notes: - [LL-171A] Use only the cables supplied with the monitor. - Be sure to use cables that are less than 3 m in length. - [LL-171G] The analog signal cable (DVI-I29 pin – mini D-sub15 pin) is to be purchased separately. (model name: NL-C02E) - [LL-171G] The 2-input cable (DVI-I29 pin – DVI-D24 pin/mini D-sub15 pin) is to be purchased separately. (model name: NL-C03J) - You are advised to retain the carton in case the monitor needs to be transported.
Product description [LL-171A] [LL-171G] 15 8 6 15 8 6 7 7 5 5 1 2 3 4 5 5 9 10 11 13 14 1 2 3 4 9 10 1112 13 14 1. AUTO button [LL-171A] ........... This button is used to perform automatic adjustment of the screen (CLOCK, PHASE, H-POS and V-POS). (p.19) INPUT button [LL-171G] ......... To switch between the signal's input terminals. 2. MENU button ........................... This button is used to pop-up, select and close the OSD (On Screen Display) Menu. 3. / MODE button ...........
Angle adjustment, height adjustment Height adjustment [LL-171G] CAUTION! English 1. Release the lock. 2. Adjust the height of the stand. 3. Set the lock. - Be sure to hold both sides of the monitor when adjusting the viewing angle. The LCD panel used in this monitor is made of glass. Pressure from hands on the LCD panel could cause damage. - Be careful not to allow your fingers to be pinched. Deutsch approx. 70 mm 2 Angle adjustment approx.
Connecting the monitor and turning the monitor on and off CAUTION! Connecting the monitor to a computer - When connecting, ensure that both the monitor and computer are switched off. - Be careful not to over bend the cable or add extension cords as this could lead to a malfunction. Analog connection [LL-171A] Connect the accessory analog signal cable to the analog RGB output terminal of the computer.
Digital connection [LL-171G] Connect the accessory analog signal cable, or separately-sold analog signal cable (model name: NL-C02E) to the analog RGB output terminal of the computer. - Connect the accessory analog signal cable to the analog RGB input terminal (INPUT-1). - Connect the separately-sold analog signal cable (model name: NL-C02E) to the DVI-I input terminal (INPUT-2). Connect the accessory digital signal cable to the digital RGB output terminal of the computer.
Connecting the monitor and turning the monitor on and off When connecting using a separately sold 2-input cable [LL-171G] Notes: - When using the 2-input cable, set the connecting input terminal [INPUT-2] to [2LINES] under the MODE SELECT-2 Menu. (p.22) - The monitor connected to the 2-input cable by analog connection may not be automatically recognized and setup under Plug & Play. Perform storage of setup information manually. (p.
Connection of headphones (commercially available) Turning the power on 1. Turn on the main power of the monitor. Headphones (commercially available) can be connected. English Connecting the monitor and turning the monitor on and off Main power switch Deutsch Headphone terminal - When switching the main power switch on and off, always wait for an interval of at least 5 seconds. Rapid switching may result in malfunction.
Connecting the monitor and turning the monitor on and off Changing between input terminals Turning the power off [LL-171G] 1. Turn the computer off. 2. Press the monitor's power button. The power LED will disappear. Use the INPUT button to switch between signal input terminals. Analog RGB input terminal DVI-I input terminal Turn the computer off. INPUT-1 INPUT Press power button.
Adjusting the screen display and speaker volume Resetting all adjustment values All adjustment values can be returned to their original ex-factory values in one command. 1. Turn off the monitor power. 2. Press the MENU button and the / MODE button simultaneously, and while doing this press the power button (i.e. turn the power on). Continue to press the buttons until [ALL RESET] appears on the screen. Reset is complete when the displayed message disappears. Adjustment lock release 1.
Adjusting the screen display and speaker volume Adjusting the speaker volume Setting display mode 1. Without the OSD Menu being displayed, press the or the button. 2. Check that [VOLUME] is selected. / MODE button If it is not selected, press the and select [VOLUME]. Color tone or brightness can be changed with one command. 3. Adjust by pressing the button (increase). STD Displays image with the color tone results from original scheme of liquid crystal panel. OFFICE Display brightness is lowered.
MENU button 1. Press the MENU button. The ADJUSTMENT Menu will be displayed. (Example: Displayed screen of the LL-171G) Screen display for adjustment First display an image that makes the entire screen light. If you are using Windows, you can use the Adjustment Pattern on the accompanying CDROM. 2. Press the button. The screen will become dark and [ADJUSTING] will be displayed. After a few seconds the ADJUSTMENT Menu will return. (The automatic adjustment is now complete.) 3.
Adjusting the screen display ADJUSTMENT Menu Manual screen adjustment When the LL-171G is used with a digital connection, this menu adjustment is not necessary. 1. Display an image that makes the entire screen light. (p.19) 2. Display the OSD Menu by pressing the MENU button. (Example: Displayed screen of the LL-171G) ADJUSTMENT Menu Select the option by pressing the / MODE button.
Adjusting the screen display COLOR CONTROL Menu When the LL-171G is used with a digital connection, this menu adjustment is not necessary. WHITE BALANCE 1. After selecting [WHITE BALANCE], press the button. The WHITE BALANCE menu will be displayed. CONTRAST While watching the color pattern, adjustments can be made so that all gradations appear.
Adjusting the screen display MODE SELECT-1 Menu MODE SELECT-2 Menu Note: - Depending on the resolution of the input signal, even if menu options can be selected, the display may not change. INFORMATION A model name (MODEL), a serial no. (S/N), and usage time (USAGE TIME) of the monitor can be checked. 1. After selecting [INFORMATION], press the button. The product information will display. 2. Press the MENU button.
Use a soft dry cloth to lightly wipe away any grime from the cabinet and control panel. If they are very dirty, apply neutral detergent to a dampened soft cloth, wring it out well and wipe away grime. The monitor's fluorescent tubes have a limited life span. - If the screen darkens, persistently flickers or does not light up, the fluorescent tube has reached the end of its operational life span. Please inquire at the shop where you purchased the monitor or your nearest Sharp authorized Service Center.
Specifications Product specifications Temperature of operating environment 5 - 35°C Power consumption 30 W (with no audio input) (35 W maximum, 1 W when in power-saving mode) Dimensions [LL-171A] Approx. 374 (W) x 205 (D) x 374 (H) mm [LL-171G] Approx. 374 (W) x 236 (D) x 368 - 438 (H) mm Weight [LL-171A] Approx. 6.0 kg (approx. 4.2 kg excluding stand) (Excluding cables.) [LL-171G] Approx. 5.6 kg (approx. 4.2 kg excluding stand) (Excluding cables.
[LL-171G] - Digital signal cable: approx. 1.8 m - Analog signal cable, NL-C02E (purchased separately): approx. 2.0 m - 2-input cable, NL-C03J (purchased separately): approx. 0.25 m Note: - As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
Specifications Relevant signal timings (analog) Display mode Hsync Vsync Relevant signal timings (digital) [LL-171G] Dot frequency Display mode Hsync Vsync Dot frequency VESA VESA US text - Recommended resolution is 1280 x 1024. - All are compliant only with non-interlaced. - A computer with an output terminal conforming to DVI (DVI-D24 pin or DVI-I29 pin) and with SXGA output capability can be connected here. (Depending on the type of computer to be connected, the display may not work correctly.
No.
Installing set-up information and the ICC profile (For Windows) Depending on the type of computer or OS, you may need to install the monitor set-up information on your system. If so, follow the steps below to install the monitor set-up information. (Depending on the type of computer or OS, command names and methods may differ. Please follow the computer's own operation manual while reading this.
If the "Add New Hardware Wizard" has appeared: 1. Load the accessory CD-ROM into the CD-ROM drive of the computer. 2. Check [Specify the location of the driver [Advanced]] and click [Next]. 3. Check [Display a list of all the drivers in a specific location, so you can select the driver you want.], then click [Next]. 4. When [Models] is displayed, click on [Have disk], confirm that [Copy manufacturer's files from:] is [D:], and click [OK]. 5.
Installing set-up information and the ICC profile (For Windows) Installing the ICC profile For Windows XP Installing the monitor's ICC profile. (If the set-up information has already been installed, so too has the profile, and there is no need to install it.) This explanation assumes that the CD-ROM drive is "D" drive. Installing monitor set-up information into Windows XP, and setting the monitor's ICC profile as a predetermined value. This explanation assumes that the CD-ROM drive is "D" drive. 1.
Information about the ColorSync profile (For MacOS) Deutsch English About the ColorSync profile ColorSync is Apple Computer's color management system and enables color reproduction characteristics to be realized when used with a compatible application. A ColorSync profile describes the color characteristics of the LCD monitor. Français Notes: - This monitor's ColorSync profile works with MacOS 8.5 or above.
Instructions for attaching a VESA-compliant arm An arm or stand based on the VESA standard (commercially available) can be attached to the monitor. Procurement of the arm or stand is at the customer's discretion. Notes: - The stand is specially made for use with this monitor. Once having removed the stand, never attempt to attach it to another device. - Once having removed the screws, store them together with the stand and if the stand is ever re-attached be sure to use the original screws.
137 171AG_es.
138 171AG_es.
171AG_cover4.
SHARP CORPORATION Printed in China Gedruckt in China Imprimé en Chine Stampato in Cina Impreso en China 0NW170184302A (1) 171AG_cover4.
