R KC-A60J KC-A50J AIR PURIFIER with Humidifying Function OPERATION MANUAL Device of this mark is a trademark of Sharp Corporation. Plasmacluster is a registered trademark or a trademark of Sharp Corporation. Free standing type SHARP CORPORATION OSAKA, JAPAN OM_KC-A60J_EN.indd 1 * The number in this technology mark indicates an approximate number of ions supplied into air of 1 cm3, which is measured around the center of a room with the “high-density plasmacluser 7000” applicable floor area (at 1.
Please read before operating your new Air Purifier The air purifier draws in room air from the air intake, passes the air through a PreFilter, a Washable Deodorizing Filter and a HEPA Filter inside of the unit, then discharges the air through the air outlet. The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns that pass through the filter and also helps absorb odours. The Washable Deodorizing Filter gradually absorbs odours as they pass through the filter.
ENGLISH FEATURES Unique Combination of Air Treatment Technologies Triple Filtration System + Plasmacluster + Humidification TRAPS DUST* Washable pre-filter traps dust and other large airborne particles. DECREASES ODOURS Washable deodorizing filter absorbs many common household odours. REDUCES POLLEN & MOLD* HEPA filter traps 99.97% of particles as small as 0.3 microns. FRESHENS Plasmacluster treats the air similar to the way nature cleans the environment by emitting a balance of positive and negative ions.
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING – To reduce the risk of electrical shock, fire or injury to persons: • Read all instructions before using the unit. • Use only a 220~240 volt outlet. • Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet is loosened. • Periodically remove dust from the plug.
CAUTIONS CONCERNING OPERATION • Do not block the intake and/or air outlet. • Do not use the unit near or on hot objects, such as stoves or heaters, or where it may come into contact with steam. • Always operate the unit in an upright position. • Hold the unit by using the handles on both sides when moving. Do not move when the unit is in operation. • Do not move or change the direction of the main unit while dragging the casters.
PART NAMES FRONT / BACK 1 1 2 2 3 Main Unit Display (Ref.E-5) Front Monitor Main Unit 3 1 2 9 3 4 10 11 5 12 6 7 13 8 (Shape of plug depends on country.
MAIN UNIT DISPLAY 2 3 4 5 1 a b c 2 3 4 1 a 6 b 7 8 c POWER ON Button CLEAN AIR MODE Button / INDICATOR LIGHT (green) CLEAN AIR & HUMIDIFY MODE Button / INDICATOR LIGHT (green) CLEAN ION SHOWER MODE Button / INDICATOR LIGHT (green) LIGHT CONTROL Button 5 CHILD-LOCK Button / INDICATOR LIGHT (green) Plasmacluster Ion ON / OFF Button / 6 Plasmacluster Sign INDICATOR LIGHT (green) FILTER RESET Button / 7 FAN SPEED Button / INDICATOR LIGHT (red) INDICATOR LIGHT (green) 8 POWER OFF Button ILLUSTRATIVE D
PREPARATION Be sure to remove the power plug from the wall outlet. FILTER INSTALLATION 1 1 Remove the Back Panel. 2 HEPA filter (White) Deodorizing filter (Black) 2 Remove the Filters from the plastic bag. 3 Install the Filters in the correct order as shown. Deodorizing filter (Black) HEPA filter (White) Click 4 Install the Back Panel. 5 Fill in the usage start date on the Date Label. E-6 OM_KC-A60J_EN.
REFILLING THE WATER TANK When using the Clean Air & Humidify Mode, or the Clean ION Shower Mode. 1 2 Remove the Water Tank. 3 1 2 Fill the Water Tank with tap Water. MAX CAUTION • Check to see that there is no water leaking. • Be sure to wipe off any excess water on the outside of the Water Tank. • When carrying the Water Tank, hold it with both hands so that the Water Tank opening is facing up. Tighten 3 Install the Water Tank. 2 Click 1 CAUTION • Do not expose the unit to water.
OPERATION CLEAN AIR & HUMIDIFY Using to quickly clean the air, reduce odours and to humidify. START • Select the desired fan speed. (Ref. E-9) • Unless the power cord has been unplugged, the operations starts in the previous mode it was operated in. NOTE • Fill the Water Tank. (Ref. E-7) • When the Water Tank is empty, the unit will operate in “CLEAN AIR MODE” and (red).
CLEAN ION SHOWER Releases high-density Plasmacluster ions and discharges strong air flow for 60 minutes. START NOTE • If the “Plasmacluster Ion ” is OFF, the plasmacluster ion will be not released. • When the operation finishes, the unit will return to the prior operation mode. It is possible to switch this mode to another while operating. However, the CLEAN ION SHOWER mode will not function after switching mode. FAN SPEED Select the desired fan speed.
USEFUL FUNCTIONS LIGHT CONTROL Use this function to select the desired brightness. brighter darker turn off CHILD LOCK Operation of the unit display will be locked. It is the same method as starting operation. ON CANCELLATION more 3 sec. more 3 sec. SOUND INDICATOR SETTING The unit can be set to give an audible signal when the Water Tank is empty. ON CANCELLATION (with the unit OFF) (with the unit OFF) more 3 sec. more 3 sec.
CARE AND MAINTENANCE Be sure to remove the power plug from the wall outlet. FILTER INDICATOR The Indicator Light will turn on after approximately 720 hours. (30days×24hours=720) Reminder to perform maintenance of parts below. After performing maintenance, reset the Filter Indicator. (Ref. E-12) more 3 sec. CARE INDEX • Notice an unpleasant odour from the air • Filter Indicator Light turn on. outlet. Humidifying Filter (Ref. E-12) • Filter performance appears fall and / or odour persist. Unit (Ref.
CARE AND MAINTENANCE WATER TANK Rinse the inside with a small amount of water. CAUTION • Do not shake the Water Tank with holding the carrying handle. NOTE for stubborn dart... Clean inside of the water tank with a soft sponge and the tank cap with a cotton swab or a toothbrush. Tank cap Tooth brushs HUMIDIFYING FILTER Rinse with plenty of water. CAUTION • Do not remove the Humidifying Filter from a filter frame. • Avoid spilling water from the Humidifying Tray. NOTE for stubborn dart... 1.
Be sure to remove the power plug from the wall outlet. HUMIDIFYING TRAY AND COVER Humidifying Tray Cover 1. Remove the Humidifying Tray Cover. 2. Rinse the inside of the Humidifying Tray and the Humidifying Tray Cover with a tooth brush. CAUTION • Do not remove the Float and the Roller. • If the Float and / or the Roller comes off. (Ref. E-17) NOTE Float for stubborn dart... TRAY 1. Fill the tray half way with water. 2. Add a small amount of kitchen detergergent. 3. Sork for 30 minutes. 4.
CARE AND MAINTENANCE DEODORIZIING FILTER HAND WASH ONLY! DO NOT DRY IN CLOTHES DRYER! 1 Remove the dust on the DEODORIZING FILTER. 2 Rinse the DEODORIZING FILTER with water. CAUTION • When washing the filter for the first time, the rinse water may be brown. This does not affect deodorization performance. • Avoid bending or folding the filter when washing. 3 Remove as much of the moisture as possible. 4 Dry filter completely in a well ventilated area. When possible, dry outdoors.
FILTER REPLACEMENT Replacement timing Filter life will vary depending on the room environment, usage, and location of the unit. If dust or odour persists, replace the filter. (Refer to “Please read before operating your new Air Purifier”) The following filter life and replacement period is based on the condition of smoking 5 cigarettes per day and the dust collection/deodorization power is reduced by half compared wirh that of new filter.
TROUBLESHOOTING Before calling for service, please review the Troubleshooting chart below, since the problem may not be a unit malfunction. SYMPTOM REMEDY (not a malfunction) Odours and smoke are not removed. • Clean or replace the filters if they appear to be heavily soiled. (Ref. E-11,E-12,E-14) The Front Monitor illuminates green even when the air is impure. • The air could be impure at the time the unit was plugged in. Unplug the unit, wait one minute, and plug the unit in again.
SYMPTOM REMEDY (not a malfunction) • Install the Roller / Float in order below. When the Roller / Float was removed. FLOAT ROLLER Fix the roller in the tray from side way. 1. Insert the float under this tab. Float 2. Inner the tab of float into the hole. NOTE Tab Check the direction of the roller. Float 3. Insert the tab on the other side of the float into the hole. Cross-Section view AUTO RESTART After a power failure, automatically resume the operation when the power recovers.
TROUBLESHOOTING ERROR DISPLAY DIGITAL INDICATION If error occurs again, contact the Sharp Service Centre. LAMP INDICATION ERROR DETAILS REMEDY Flashing of the Clean Air & Humidify Indicator Light. Abnormal humidity filter. Verify if the Humidifying Filter, Humidifying Tray and Water Tank are properly installed and then turn power ON again. Flashing of the Fan Speed Indicator Light ' '. Abnormal fan motor. Turn power OFF to cancel the error display, wait one minute, and then turn power ON.
FOR CUSTOMER ASSISTANCE WARRANTY Consumer Electronic Products Congratulations on Your Purchase! This Sharp product is warranted against faults in material and manufacture for the period as stated in the table below. If service is required during the warranty period, please contact your nearest Sharp Approved Service Centre. These repairs would be carried out at no charge to the owner, subject to the conditions specified herein.
FOR CUSTOMER ASSISTANCE SHARP FOR LOCATION ENQUIRIES WITHIN AUSTRALIA REGARDING YOUR LOCAL SHARP APPROVED SERVICE CENTRE VISIT OUR WEBSITE AT www.sharp.net.au OR CALL SHARP CUSTOMER CARE 1300 135 022 (LOCAL CALL COST6 APPLY WITHIN AUSTRALIA) SHARP CORPORATION OF AUSTRALIA PTY LTD SHARP FOR LOCATION ENQUIRIES WITHIN NEW ZEALAND REGARDING YOUR LOCAL SHARP APPROVED SERVICE CENTRE VISIT OUR WEBSITE AT www.sharp.net.
OM_KC-A60J_EN.indd Sec1:21 Noise Level (dBA) 40 *4 *3 *2 *1 Deodorization 11.0 19 300 24 9 120 600 47 36 288 49 42 306 2.0 9.2 250 23 7.4 90 16 4.3 60 LOW 399 (W) × 273 (D) × 603 (H) Washable Deodorizing HEPA with Microbial control *4 3.6 ~28 500 ~38 41 20 216 41 18 216 MED KC-A50J Standby Power In order to operate the electrical circuits while the power plug is inserted in the wall outlet, this product consumes about 0.9 W of standby power.
