ENGLISH

DW-41

DW-37

ELECTRIC REFRIGERATOR

OPERATION MANUAL

CONTENTS

Thank you very much for buying this URIL product. Before using your

URIL refrigerator, please read this operation manual to ensure that you

gain the maximum benefit from it.

• DESCRIPTION ...............................................................2

•WARNING.......................................................................3

• CAUTION........................................................................3

• INSTALLATION ..............................................................4

• OPERATION ...................................................................5

•STORING FOOD ............................................................6

• CARE AND CLEANING .................................................7

• WHAT TO DO BEFORE YOU CALL FOR SERVICE.....7

Summary of content (8 pages)

PAGE 1
DW-41 DW-37 ELECTRIC REFRIGERATOR OPERATION MANUAL CONTENTS • DESCRIPTION ............................................................... 2 • WARNING .......................................................................3 • CAUTION ........................................................................ 3 • INSTALLATION .............................................................. 4 • OPERATION ................................................................... 5 • STORING FOOD .........................
PAGE 2
DESCRIPTION 17 1 2 3 18 4 5 6 7 5 8 19 20 21 9 22 10 11 12 13 14 23 18 15 16 19 1. Freezer temp. control knob 2. Freezer shelf 3. Ice cube maker 4. Ice cube box 5. Deodorizing unit 6. Fresh case 11. Shelf 12. Vegetable crisper 13. Divider 14. Evaporating pan(rear side) 15. Casters 16. Adjustable foot 17. Light switch 18. Utility pocket 19. Magnetic door seal 20. Egg holder 21. Egg pocket 22. Bottle guard 23. Bottle pocket The cover of the Fresh case opens as the case is pulled. 7.
PAGE 3
WARNING 1. This refrigerator is airtight. TO PREVENT FATAL ACCIDENTS TO CHILDREN, please completely remove the door prior to discarding the refrigerator. 2. Highly volatile and inflammable materials such as ether, petrol, propane gas, adhesive agents and pure alcohol etc. are liable to explode. Do not store these materials in the refrigerator. 3. To prevent damage to the outer cabinet, avoid contact with lacquer, and paint, etc. 4.
PAGE 4
INSTALLATION 1. To ensure adequate ventilation for your refrigerator, it is recommended to provide space of 6cm on both sides and at the back, and space of 9cm above the refrigerator. Insufficient spacing 6cm 6cm 9cm 6cm 127 cm will decrease the cooling efficiency, resulting in unnecessary consumption of electricity. 115 cm 2. Using the front Adjustable foot, ensure that the refrigerator is positioned firmly and level on the floor. NOTE: • Position your refrigerator so that the plug is accessible.
PAGE 5
OPERATION CONTROLLING TEMPERATURES The refrigerator controls its temperature automatically. However, if needed, adjust the temperature as follows. Freezer compartment 7(MAX) For making ice rapidly or fast freezing. 4(MED) For normal freezing. 1(MIN) When frozen food or ice cream is not stored. • If the refrigerator is operated for a long time with FREEZER TEMP. CONTROL set at 7(MAX), foods stored in the refrigerator compartment may also freeze.
PAGE 6
STORING FOOD Refrigeration reduces the rate of food spoilage. To maximize the shelf life of perishable food products, ensure that the food is of the freshest possible quality. The following is a general guide to help promote longer food storage. Fruit / Vegetables To minimize moisture loss, fruit and vegetables should be loosely enclosed in a plastic material e.g. wrap, bags ( do not seal ) and place in Vegetable crisper. Those fruits and vegetables with thick skins e.g. oranges do not require wrapping.
PAGE 7
CARE AND CLEANING Some household cleaning chemicals may affect the inside surfaces and plastic shelves resulting in splitting or cracks occurring. When cleaning all plastic parts inside this refrigerator, only use diluted dishwashing liquid(soapy water). Make sure that all plastic parts are thoroughly rinsed with water after cleaning. Evaporating pan; How to remove/set Remove the two screws to take the Evaporating pan off. Please pay attention to the safety since the compressor is very hot.
PAGE 8
United Refrigeration Industries Limited 8 MADE IN THAILAND TINS-A628CBRZ 04B- TH 1
