2: MODEL DK-KP95PH SLIM MICRO SYSTEM OPERATION MANUAL Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. ™ AirPlay, the AirPlay logo, iPad, iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.
Special Notes WARNINGS ● When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still present inside the unit. When the ON/STAND-BY button is set at STAND-BY position, the unit may be brought into operation by the remote control. ● This unit contains no user serviceable parts. Never remove covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug from the socket before any service operation and when not in use for a long period.
Precaution ● Hold the AC power plug by the head when removing it from the wall socket, as pulling the lead can damage internal wires. ● The AC power plug is used as a disconnect device and shall always remain readily operable. ● Do not remove the outer cover, as this may result in electric shock. Refer internal service to your local SHARP service facility. ● The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, tablecloths, curtains, etc.
System connections Make sure to unplug the AC power lead before making any connections. FM aerial External FM aerial for better reception (not supplied) Wall socket (AC 220 - 240 V ~ 50/60 Hz) AM loop aerial ■ Aerial connection ■ AC power connection After checking all the connections have been made correctly, plug the AC power lead of this unit into the wall socket. Note: Unplug the AC power lead from the wall socket if the unit will not be in use for a prolonged period of time.
General control ■ Auto power on During stand-by mode, when you select DK-KP95PH speaker through AirPlay icon on your AirPlay device, the unit will automatically power on to Network function and stream the music from your AirPlay device. This condition applies when: ● The AirPlay network has previously been set up between the unit and your AirPlay device. ● Set the Network Stand-by mode to ON.
Wi-Fi network Setup for AirPlay / DLNA 7� Select SHARP_DK-KP95 from the list of available (AirPlay) With Apple AirPlay technology, you can stream your music from your iTunes on a Mac, PC, iPod touch, iPhone, or iPad to external speakers (DK-KP95PH) via a Wi-Fi network. AirPlay usage requires: ● MacBook or MacBook Pro running MacOS 10.6.6 or greater. ● iTunes 10.2 or greater (Mac/PC). ● iOS 4.
Wi-Fi network Setup for AirPlay / DLNA (continued) 9� Select Network Configuration tab. 0�Select your router SSID from the pull-down list of ■ Connection via wireless router with WPS Service Set ID (SSID). � Press the WPS button on the wireless router. WPS � 3� � 5� Press the ON/STAND-BY button. Press the NETWORK button. Press the iPod MENU button on the remote control. Press the / button to select ‘Wi-Fi Setup’. Press the ENTER button. 6� Press the / button to select ‘WPS’.
For Mac iTunes: � On the toolbar menu, click iTunes and select Preferences. � Under Devices tab, check the ‘ Allow iTunes audio control from remote control speakers’ box. For Window iTunes: � On the toolbar menu, click Edit and select Preferences. � Under Devices tab, check the ‘ Allow iTunes control from remote control speakers’ box. Note: For more details, refer to the iTunes guide.
Listening to the iPod, iPhone or iPad (continued) ● This product is made for iPod, iPhone and iPad. To prevent random interference when iPod, iPhone or iPad is connected, the headphone output of main unit is disabled, and “HP INVALID” will be displayed. You may also experience brief audio interference during incoming calls. ● The headphone output of main unit is switched off during inserting iPod, iPhone and iPad unit. This is an Apple product specification.
Listening to the iPod, iPhone or iPad (continued) Enter Cursor Up/ Down ■ Navigating the iPod, iPhone or iPad menus � Press the iPod MENU button to view the menu on iPod, iPhone or iPad unit. Press it again to go back to previous menu. � Use the PRESET ( or ) button to select an item on the menu and then press ENTER button. ____ Press to confirm the selection. ____ Press to select the iPod menu.
Listening to a CD or MP3/WMA disc (continued) ■ Various disc functions Function Main unit Remote control ■ Random play (shuffle) Operation Play Press in the stop mode. Pause Press in the playback mode. Press the / button to resume playback from the paused point. Press in the playback mode. Stop Track up/down Fast forward/ reverse The tracks on the disc can be played in random order automatically.
Listening to a CD or MP3/WMA disc (continued) Listening to USB mass storage device/MP3 player Caution: At USB mode, once the iPod or iPhone is docked onto the unit, the iPod or iPhone will automatically start charging. ‘iPod DOCK Charge Mode’ will be displayed. In order to listen to any USB mass storage device / MP3 player, the iPod or iPhone must be removed from the docking station. Notes: 1. Remove the USB terminal cover before use. Keep it away from children as it may be swallowed. 2.
Listening to USB mass storage device/MP3 player (continued) Notes: ● SHARP will not be held liable for the loss of data while the USB memory device is connected to the audio system. ● Files compressed in MP3 and/or WMA format can be played back when connected to the USB terminal. ● This USB memory’s format supports FAT 16 or FAT 32. ● SHARP cannot guarantee that all USB memory devices will work on this audio system. ● USB cable is not recommended for use in this audio system to connect to USB memory device.
Listening to the radio ■ Memorising a station You can store 40 AM and FM stations in memory and recall them at the push of a button. (Preset tuning) � Perform steps 2 - 3 in “Tuning”. � Press the MEMORY button. 3� Within 30 seconds, press the PRESET ( or ) button to select the preset channel number. Store the stations in memory, in order, starting with preset channel 1. � Within 30 seconds, press the MEMORY button to store that station in memory.
Using the Radio Data System (RDS) RDS is a broadcasting service which a growing number of FM stations provide. These FM stations send additional signals along with their regular programme signals. They send their station names, and information about the type of programme such as sport, music, etc. When tuned to an RDS station, “RDS” and the station name will be displayed.
Using the Radio Data System (RDS) (continued) INFO Programmes whose purpose is to impart advice in the widest sense. To specify programmed types and select stations (PTY search): You can search a station by specifying the programme type (news, sports, traffic programme, etc.) from the stations in memory. SPORT Programme concerned with any aspect of sport. EDUCATE Programme intended primarily to educate, of which the formal element is fundamental.
Using the Radio Data System (RDS) (continued) TRAVEL Features and programmes concerned with travel to near and far destinations, package tours and travel ideas and opportunities. Not for use for announcements about problems, delays, or roadworks affecting immediate travel where TP/TA should be used. LEISURE Programmes concerned with recreational activities in which the listener might participate. Examples include, Gardening, Fishing, Antique collecting, Cooking, Food & Wine, etc.
Timer and sleep operation (Remote control only) �When the preset time is reached, playback will start. Timer playback: The unit turns on and plays the desired source (CD, TUNER, USB, iPod, AUDIO IN) at a preset time. This unit has 2 types of timer: ONCE TIMER and DAILY TIMER. Once timer (“ ” indicator): Once timer play works for one time only at a preset time. Daily timer (“DAILY” indicator): Daily timer play works at the same preset time every day that we set.
Timer and sleep operation (Remote control only) (continued) � Set the sleep time (see above, steps 1 - 5). � While the sleep timer is set, set the timer playback To confirm the remaining sleep time: While “SLEEP” is indicated, press the SLEEP button. To cancel the sleep operation: Press the ON/STAND-BY button while “SLEEP” is indicated. To cancel the sleep operation without setting the unit to the stand-by mode, proceed as follows. � While “SLEEP” is indicated, press the SLEEP button.
Troubleshooting chart (continued) ■ Remote control Symptom ● The remote control does not operate. ■ Wi-Fi connection Possible cause ● Is the AC power lead of the unit plugged in? ● Is the battery polarity correct? ● Is the battery dead? ● Is the distance or angle incorrect? ● Does the remote control sensor receive strong light? Symptom ● Wi-Fi network connection failed. ■ Tuner Symptom ● The radio makes unusual noises continuously.
Troubleshooting chart (continued) ■ Condensation ■ Network reset Sudden temperature changes, storage or operation in an extremely humid environment may cause condensation inside the cabinet (CD pickup, etc.) or on the transmitter on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc in the unit until normal playback is possible (about 1 hour). Wipe off any condensation on the transmitter with a soft cloth before operating the unit.
Specifications As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
For Australia and New Zealand customers FOR LOCATION ENQUIRIES WITHIN AUSTRALIA REGARDING YOUR LOCAL SHARP APPROVED SERVICE CENTRE VISIT OUR WEBSITE AT www.sharp.net.au OR CALL SHARP CUSTOMER CARE 1300 135 022 (LOCAL CALL COSTS APPLY WITHIN AUSTRALIA) SHARP CORPORATION OF AUSTRALIA PTY LTD FOR LOCATION ENQUIRIES WITHIN NEW ZEALAND REGARDING YOUR LOCAL SHARP APPROVED SERVICE CENTRE VISIT OUR WEBSITE AT www.sharp.net.
For Australia and New Zealand customers
