SCR-Smart Card Reader

The content of this document is protected by copyrights.

Date

Name

Created

28..11.11

Hen

File name:

--.--.--

Approved

28.11.11

Hen

03 65044 0 B.doc

Index

Date

Created

Approved

Standardization

30.11.11

Jor

Scheidt & Bachmann GmbH

D-41238 Mönchengladbach Breite Straße 132

Installation

Instructions SCR

03 65044 0 __

Page: 1 of 8

1 Introduction

The Scheidt & Bachmann (S&B) 13,56 MHz RFID Smart Card Reader System “SCR” is

designed for exclusive application with S&B devices only. It will never be sold as single

system. S&B devices are products like ticket vending machines, pay on foot machines,

ticket dispensers, ticket validators etc. with

13,56 MHz RFID functionality.

SCR is integrated by a set of one common sandwich circuit board and one or two (see cp. 4)

of 2 different antenna types.

For operational description, pls. see cp. 2.

For block diagram, pls. see cp. 3.

For detailed antenna adaptation and pin assignment, pls. see cp. 4.

For detailed pin assignment, pls. see cp. 5.

For FCC/ IC information, pls. see cp. 6.

Summary of content (8 pages)

PAGE 1
Installation Instructions SCR-Smart Card Reader 1 Introduction The Scheidt & Bachmann (S&B) 13,56 MHz RFID Smart Card Reader System “SCR” is designed for exclusive application with S&B devices only. It will never be sold as single system. S&B devices are products like ticket vending machines, pay on foot machines, ticket dispensers, ticket validators etc. with 13,56 MHz RFID functionality. SCR is integrated by a set of one common sandwich circuit board and one or two (see cp.
PAGE 2
Installation Instructions SCR-Smart Card Reader 2 Operational description 2.1 Basic operation principle SCR is a 13,56Mhz RFID Transponder Read/ Write Unit for use in S&B equipment. It can be used for various applications in S&B eqt, such as SmartCards, eTicketing, wireless creditcard processing (EMV), etc. All such devices are under responsibility of S&B. Corresponding partners for SCR are passive RFID Transponders, based on the ISO 14443 Type A and B or Mifare standard.
PAGE 3
Installation Instructions SCR-Smart Card Reader 2.3 RF coupling of SCR and Transponder Since electromagnetic coupling is used for data transmission between SCR and transponder and power supply of the transponder the electromagnetic field is the most important attribute. The following figure shows the run of the electromagnetic field lines with the transponder placed in the antenna field. The RF coupling is according to all layers of ISO 14443 Type A and B are supported.
PAGE 4
Installation Instructions SCR-Smart Card Reader 3 Block diagram: Circuit Board Transponder II 03 62101 0 CPU Module 03 53742 0 18,432MHz 32,768 KHz 8 Bit Bus Memory ARM 9 CPU I2C 20MHz Memory FPGA CONTROL DATA / CONTROL LED/BUZZER USB1.1 RS232 50 MHz +3.3V connector to baseboard The content of this document is protected by copyrights. File name: 03 65044 0 B.doc B Index --.--.
PAGE 5
Installation Instructions SCR-Smart Card Reader Baseboard 03 51634 0 IIC DATA / CONTROL RS232 13,56 MHz 20MHz connector from CPU Modul AT83C26 13,56 MHz USB 1.1 MFRC 531 MFRC 531 LED / BUZZER LED / BUZZER 50 Ohm Antenna ISO 14443 Type A / B SAM sockets 3.3V 8V..12V DC DC 5V int. 5V VV 5V exten V V The content of this document is protected by copyrights. File name: 03 65044 0 B.doc B Index --.--.
PAGE 6
Installation Instructions SCR-Smart Card Reader 4 Antenna Setup For SCR system, the following antenna setups can be used Antenna Connector BU500 Antenna Connector BU550 03 57570 03 64127 none none 03 57570 03 57570 03 64127 none none 03 57570 03 64127 03 57570 03 64127 03 57570 The content of this document is protected by copyrights. File name: 03 65044 0 B.doc B Index --.--.
PAGE 7
Installation Instructions SCR-Smart Card Reader 5 List of Cables and components Cable Functon 5V 5V 8V-24V 8V-24V Connector SCR Power LED/Buzzer Antenna Host RS232 USB Type No 2 x AWG20 Count Length UL SW 50 62106 0 0-3m 3 x AWG20 C UL SW 2 x AWG20 UL SW 50 60120 50 62106 0 A 0 3 x AWG20 C UL SW 6 x AWG24 C UL SW 50 60120 50 61441 0 A 0 A 2 0-3m 0-7,3m M17 / 113-RG316 5063381 0 2 0-7,3m 4 x AWG24C UL CSA SW 50 61440 0 A 1 0-3m 0-5 ST950 ST572 / ST582 BU500 / BU550 ST301 BU4
PAGE 8
Installation Instructions SCR-Smart Card Reader 6 FCC/IC information Important note: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The device is labelled as follows: This device complies with part 15 of the FCC and Industry Canada Rules.
