Samsung Mobile Hotspot User Manual t Draf www.samsung.com 2014.03.
www.sar-tick.com 2 This product meets applicable national SAR limits of 2.0 W/kg. The specific maximum SAR value can be found in the SAR information section of this guide. When carrying the product or using it while worn on your body, maintain a distance of 1.0 cm from the body to ensure compliance with RF exposure requirements.
This device provides high quality mobile communication and entertainment using Samsung’s high standards and technological expertise. • Content may differ from the final product, or from software provided by service providers or carriers, and is subject to change without prior notice. • The items supplied with the device and any available accessories may vary depending on the region or service provider. • The supplied items are designed only for this device and may not be compatible with other devices.
• Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or applications to work improperly.
Copyright Copyright © 2014 Samsung Electronics This guide is protected under international copyright laws. No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics.
Trademarks • SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics. • Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi CERTIFIED™, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. • All other trademarks and copyrights are the property of their respective owners.
Getting Started Device layout WPS button Notification light Power button Multipurpose jack 7
Getting Started Package contents Check the product box for the following items: • Device • Battery Installing the SIM or USIM card and battery Insert the SIM or USIM card provided by the mobile telephone service provider, and the included battery. Only microSIM cards work with the device.
Getting Started 1 Remove the back cover. Be careful not to damage your fingernails when you remove the back cover. Do not bend or twist the back cover excessively. Doing so may damage the cover. 2 Insert the SIM or USIM card with the goldcoloured contacts facing downwards.
Getting Started 3 Insert the battery. 2 1 4 Replace the back cover.
Getting Started Removing the SIM or USIM card and battery 1 Remove the back cover. 2 Pull out the battery. 3 Pull out the SIM or USIM card.
Getting Started Charging the battery Before using the device for the first time or when the battery has been unused for extended periods, you must charge the battery. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device. Connect the USB cable to the USB power adaptor and then plug the end of the USB cable into the multipurpose jack.
Getting Started Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty. After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket. Do not remove the battery before removing the charger. This may damage the device.
Getting Started • To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging. • The socket-outlet shall be installed near the equipment and shall be easily accessible.
Getting Started Turning the device on and off Press and hold the Power button for a few seconds to turn on the device. While the device is turned on, all notification lights turn green. To turn off the device, press and hold the Power button again.
Getting Started Notification light The notification light alerts you to the device’s status with the following colours.
Getting Started Name Wi-Fi network Battery power Status • Steady green: Devices connected • Blinking green: Data transferring • Steady blue: Ready to connect to devices • Blinking blue: WPS standby mode • Blinking red: Notification alert or error occurred • Steady green: 50 % – 100 % • Blinking green: Fully charged • Steady blue: 15 % – 49 % • Steady red: Charging • Blinking red: Less than 15 % 17
Getting Started Connecting with other devices Connect your device with computers or other devices that support the Wi-Fi function. Recently-connected devices will automatically connect to your device whenever it is turned on. When a password is required, enter the default password. The default password is the last 8 digits of the IMEI number. The IMEI number is on a label affixed to the device. IMEI label You must insert a SIM or USIM card to use the device.
Getting Started Connecting to a network via Wi-Fi 1 Turn on your device. 2 On other devices, access Wi-Fi settings and search for the network. 3 Select the device name from the search results. 4 Enter a password if necessary.
Getting Started Activating Wi-Fi Protected Setup (WPS) mode You can connect devices to a network and encrypt data by pushing the WPS button. 1 Press and hold the WPS button. The notification light flashes blue when the WPS mode is activated. 2 Activate the WPS mode on other devices. The devices enter WPS setup mode. 3 Press the WPS button again within 2 minutes.
Getting Started Connecting to a network using a USB cable 1 Turn on your device. 2 Connect the device to the computer using the USB cable. 3 Select the device name from the network list. 4 Enter a password if necessary. Upgrading the device The device can be upgraded to the latest software. On the computer, launch Samsung Kies and connect the device to the computer. Refer to the Samsung Kies help for details on how to upgrade.
Getting Started Configuring the device When the device is connected to other devices, access the administration page to configure the device. On the connected device, open the web browser and go to http://samsung.hotspot (http://192.168.1.1). When the password request appears, enter the password. The default password is ‘admin.’ At the top of the administration page, tabs will be shown. Select tabs to access the following options: Home View information about the device and the network.
Getting Started Messages • Inbox: View messages saved on the device or the SIM card. Or, send and receive messages. • SMS over mode: Select a network to send messages. Network • Network info: View the current network information. • DHCP server: Set the device to operate as a Dynamic Host Configuration Protocol (DHCP) server. • Wi-Fi settings: Configure Wi-Fi settings such as network name and password.
Getting Started Security Lock your SIM card and restrict access to authorised devices only. Settings • Mobile network: Select the default network to use. • Options: Change the settings for the administration page. Support • Samsung Electronics: Access the Samsung Electronics homepage. • LED guide: View details of the notification light status for the device. • Open Source Licenses: Read licences, disclaimers, acknowledgements, and notices for specific free or open source software on the device.
Getting Started Resetting the device On the connected device, access the administration page. Open the web browser and go to http://samsung.hotspot (http://192.168.1.1). When the password request appears, enter the password. The default password is ‘admin.’ At the top of the administration page, tap Settings → Options → Device factory reset.
Safety information This safety information contains content for the device. Some content may be not applicable to your device. To prevent injury to yourself and others or damage to your device, read the safety information about your device before using the device. Do not use your device outdoor during a thunderstorm Do not drop or cause an impact to the device Handle and dispose of the device with care • Never dispose of the battery or device in a fire.
Safety information Do not use or store your device in areas with high concentrations of dust or airborne materials Dust or foreign materials can cause your device to malfunction and may result in fire or electric shock. Do not bite or suck the device or the battery Keep your device dry Do not store your device in very hot or very cold areas.
Safety information Specific Absorption Rate (SAR) certification information THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) recommended by international guidelines.
Safety information During use, the actual SAR value for this device is usually well below the value stated above. This is because, for purposes of system efficiency and to minimise interference on the network, the operating power of your mobile device is automatically decreased when full power is not needed for the call. The lower the power output of the device, the lower its SAR value. A body-worn SAR test has been performed on this device at a separation distance of 1.0 cm.
Safety information Correct disposal of this product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste.
Safety information Correct disposal of batteries in this product (Applicable in countries with separate collection systems) This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
Declaration of Conformity Product details For the following Product : Wireless Hotspot Model(s) : SM-V101M Declaration & Applicable standards We hereby declare, that the product above is in compliance with the essential requirements of the R&TTE Directive (1999/5/EC) by application of: SAFETY EN 60950 - 1 : 2006 + A11 : 2009 + A1 : 2010 + A12 : 2011 SAR EN 50566 : 2013 EN 62209-2 : 2010 EN 62311 : 2008 EMC EN 301 489-1 V1.9.2 EN 301 489-24 V1.5.1 EN 301 489-17 V2.2.1 EN 301 489-7 V1.3.
Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. About the Samsung Kies Samsung Kies is a computer application that manages media contents and personal information with Samsung devices. Download the latest Samsung Kies from the Samsung website (www.samsung.com/kies) and install it on your computer. Printed in China GH68-40989A Rev.1.0 English (EU).
Health and safety information Exposure to Radio Frequency (RF) Signals Certification Information (SAR) Your wireless device is a radio transmitter and receiver. It is designed and manufactured not to exceed the exposure limits for radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. government.
devices. The FDA publication includes the following information: What kinds of devices are the subject of this update? The term wireless device refers here to hand-held wireless devices with built-in antennas, often called “cell,” “mobile,” or “PCS” devices. These types of wireless devices can expose the user to measurable radio frequency energy (RF) because of the short distance between the device and the user's head.
“Occupational Safety and Health Administration “National Telecommunications and Information Administration The National Institutes of Health participates in some interagency working group activities, as well. FDA shares regulatory responsibilities for wireless devices with the Federal Communications Commission (FCC). All devices that are sold in the United States must comply with FCC safety guidelines that limit RF exposure.
such as the angle at which the device is held, or which model of device is used. What is FDA doing to find out more about the possible health effects of wireless device RF? FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to radio frequency energy (RF).
causes brain tumors or other ill effects. Their recommendation to limit wireless device use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists. Do hands-free kits for wireless devices reduce risks from exposure to RF emissions? Since there are no known risks from exposure to RF emissions from wireless devices, there is no reason to believe that hands-free kits reduce risks.
obtained from the following organizations: FCC RF Safety Program: http://www.fcc.gov/oet/rfsafety/ Environmental Protection Agency (EPA): http://www.epa.gov/radiation/ Occupational Safety and Health Administration's (OSHA): http://www.osha.gov/SLTC/radiofrequencyradiation/index.html National institute for Occupational Safety and Health (NIOSH): http://www.cdc.gov/niosh/ World health Organization (WHO): http://www.who.
“The wireless industry reminds you to use your device safely when driving.” For more information, please call 1-888-901-SAFE, or visit our web-site www.wow-com.com Provided by the Cellular Telecommunications & Internet Association Operating Environment Remember to follow any special regulations in force in any area and always switch your device off whenever it is forbidden to use it, or when it may cause interference or danger.
alternatives. Other Medical Devices If you use any other personal medical devices, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information. Switch your device off in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
accurately as possible. Remember that your device may be the only means of communication at the scene of an accident; do not cut off the call until given permission to do so. Restricting Children's access to your Device Your device is not a toy. Children should not be allowed to play with it because they could hurt themselves and others, damage the device or make calls that increase your device bill.
FCC Notice and Cautions FCC Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
