Precaution Thank you for purchasing this digital instrument. For perfect operation and security, please read the manual carefully and keep it for future reference.
DIGITAL PIANO Thank you for choosing the Mp8820 Digital Piano Your MP8820 is a high quality digital piano featuring an 88 note hammer action, touch sensitive keyed and the most advanced PCM tone generation technology that combined will provide you with a rich performing and playing experience. You can also record your own performances or record your own accompaniment to play along to.
DIGITAL PIEING _ Contents PANE] COOT 2 Play the Peale = 4 1. Turn on the Power: 4 2. Set the Volume 4 3. Using Headphone 4. Using External Sound System 4 5. Using AUDIO -5 6. Using MIDI IN/MIDI QUT Jack 5 7. Piano Pedals 5 8. Using DC Power Jack 6 9. Voices 6 10. Demo Play 6 11. Dual Mode Split Mode Reverb Effect Chorus Effect 10 15. Touch Sensitivity 11 16. Transpose nrsscsnassannns C11 17. Metronome and Tempo -18.
POWER ON/OFF MASTER VOLUME TOUCH Button CHORUS Button REVERB Button SONG Bitten METRONOME Button TEMPO Nations MULCH DISPLAY VOICES Select DIGITAL PIEING ¢) SPLIT Button {f) DUAL Button TRANSPOSE Button §' USB-MIDI Jack {& MIDI OUT Jack {f» MIDI IN Jack {fy PEDAL Jack {f) LINE OUT Jack © DC Power Jack a Phones Jack
DIGITAL PIANO Play The Paine 1. Turn on the power Before playing turn the power on by pressing the POWER switch, the panel LED will light. POWER MILT! DISPLAY on Pro [Pra 2. Set the Volume Initially set the MASTER VOLUME about half way between the "MIN" and "MAX" settings. You can adjust the volume to accommodate you play. 7 ph 2 Ton mm, MASTER, 3. Using Headphone Two sets of standard stereo headphones can be plugged in here for private practice or late-night playing.
DIGITAL PIANO 5. Using USB-MIDI / USB AUDIO Jack This product allows the transfer of MIDI information over USB to a computer. Complicated as it sounds, it's pretty simple. Because your piano is USB Class Compliant, there is no need to install a driver to enable it to work with OSX, Windows XP, Vista or Windows 7. Just plug it in and the 08 will do the rest. The piano will work with all standard MIDI based computer software. USB AUDIO interface is a digital audio interface.
DIGITAL PIANO 8. Using DC Power Jack Connection for the included DC power adapter. Please use only the provided adapter. 9. Voices The piano has 16 built-in voices which include several pianos as well as other instruments. These digitally-sampled musical instrument sounds may be selected one at a time, layered to produce two voices at once, or assigned to the left or right hands. To select a voice (Main voice), press the appropriate Voice Select button on the right side of the front panel.
DIGITAL PIANO 11. Dual Mode Press [DUAL] button to enter Dual voice mode, two voices will sound simultaneously when you play keyboards. . ™ a.Select Dual Voice Hold down [DUAL] button and the Dual indicator will light, then press the voice button to select the Dual voice. OW aa Err om Oa om ween moms 1 uU ib b.Exit The Dual Mode Press [DUAL] button again to exit the Dual mode.
DIGITAL PIANO 12. Split Mode Press [SPLIT] button to enter split mode, your keyboard will be divided into two sections, which means different voices can be played with the left and right hands at the same time, a. Enter Split Mode Press the [SPLIT] button and the Split indicator will light. The LED will show: SPL. The Split (left hand) voice will be E.PIANO and the Split Point will be F2. ; SPL b.
DIGITAL PIANO yb d.Exit the Split Mode Press [SPLIT] button again to exit the Split mode. Ty [ere] The Reverb effect may be applied to each voice individually and will be retained even when the power is turned off. To apply reverb, select the desired voice and press [REVERE] button repeatedly. The Reverb indicator will light and the effect will be heard when the piano is played. Ceo Press [REVERB] button repeatedly, when the Reverb indicator is unlighted, the Reverb effect is off.
DIGITAL PIANO To adjust the amount (depth) of the reverb effect, hold the [REVERB] button down and press the [TEMPO «/p] buttons to adjust the desired ceo TB 28 14. Chorus Effect The Chorus effect may be applied to each voice individually and will be retained even when the power is turned off. This effect simulates the same tone coming from multiple sources, like several singers or instruments singing or playing the same note. To apply the Chorus Effect, select the desired voice and press [CHORUS] button.
DIGITAL PIANO 15. Touch Sensitivity Press [TOUCH] button, you can select four type of touch sensitivity styles to accommodate your play and the corresponding indicator will light. HARD style: require more strength to produce maximal sound. NORMAL style: require standard strength to produce maximal sound. SOFT style: require less strength to produce maximal sound. FIXED style: when touch is off, the same volume is produced no matter how strongly or softly you play the keyboard.
DIGITAL PIANO D2 |D"2 | E2 | F2{F'2 | A2 | D3 | F3F"3 G3 |G'3| A3 20-10 #142 & 17.Metronome and Tempo Press [METRONOME] button, you can turn on or off metronome function. ‘When this function is on, you can select beat type by holding the METRONOME] button until the beat type will appear on the LED, then using the [TEMPO ] buttons to set it. Time signatures include :teatime, teatime, teatime, teatime, teatime, teatime, teatime, teatime, meantime.
DIGITAL PIEING a.To Record a Track Press the [SONG] button and the [METRONOME] button simultaneously to enter Record Wait Mode. The buttons indicator will light, and the Metronome will begin playing at the currently selected tempo. The LED display will show: REC. for one second, after which it will show: TR1. The piano is now in Record Wait Mode. To start recording, begin playing the keyboard. Recording starts automatically as soon as you start playing. To end recording, press the [SONG] button.
