Quick Guide RIGOL Publication Number QGA07114-1110 August 2010 DS1000E, DS1000D Series Digital Oscilloscope DS1102E, DS1052E, DS1102D, DS1052D © 2008 RIGOL Technologies, Inc.
RIGOL Copyright © 2008 RIGOL Technologies, Inc. All Rights Reserved. RIGOL products are protected by patent laws in and outside of the P.R. China. Information in this publication replaces all previous corresponding material. RIGOL reserves the right to modify or change part of or all the specifications and pricing policies at company’s sole decision. NOTE: RIGOL is registered trademark of RIGOL Technologies, Inc.
RIGOL Safety Notice Review the following safety precautions carefully to avoid any personal injuries or damages to the instrument and any products connected to it. To avoid potential hazards, please use the instrument as specified by this manual only. The instrument should be serviced by Authorized personnel only. To Avoid Fire or Personal Injury. Use Proper Power Cord. Use the power cord designed for the instrument and authorized in your country only. Connect and Disconnect Logic Analyzer.
RIGOL personnel before further operations. Provide Proper Ventilation. Refer to the installation instructions for proper ventilation of the instrument. Do Not Operate in Wet/Damp Conditions. Do Not Operate in an Explosive Atmosphere. Keep Product Surfaces Clean and Dry. The disturbance test of all the models meet the limit values of A in the standard of EN 61326: 1997+A1+A2+A3, but can’t meet the limit values of B.
RIGOL Safety Terms and Symbols Terms in This Guide. These terms may appear in this manual: ! ! WARNING: Warning statements indicate the conditions or practices that could result in injury or loss of life. CAUTION: Caution statements indicate the conditions or practices that could result in damage to this product or other property. Terms on the Product. These terms may appear on the product: DANGER indicates an injury or hazard that may be immediately happen.
RIGOL Contents Contents .................................................................................. V Necessary Inspection ................................................................ 1 How to Connect Power Cord ...................................................... 2 How to Connect Probe or BNC ................................................... 3 How to Connect Logic Analyzer ................................................. 5 How to Connect USB and RS232 Devices...............................
RIGOL Necessary Inspection 1． Inspect the shipping container for damage. Keep the damaged shipping container or cushioning material until the contents of the shipment have been checked for completeness and the instrument has been checked mechanically and electrically. 2． Inspect the instrument. In case there is any mechanical damage or defect, notify the RIGOL Sales Representative.
RIGOL How to Connect Power Cord After inspecting the instrument and the accessories, connect the power cord as shown in the following figure. Press the power key on the top of the oscilloscope. if the oscilloscope can not be powered on, check the power cord connection. If the oscilloscope still can not start up after the inspections, please contact RIGOL for help.
RIGOL How to Connect Probe or BNC 1． Connect the probe As shown in the above figures, set the attenuation switch on the probe to 10X and connect the probe to Channel 1 on the oscilloscope, push and rotate clockwise to lock the probe in place.
RIGOL (1) Set the attenuation switch on the probe to 10X and connect the probe to Channel 1 on the oscilloscope. Attach the probe tip and ground lead to the PROBE COMP connector. Press CH1, and set the attenuation menu to 10X. Then press AUTO.
RIGOL How to Connect Logic Analyzer DS1000D Series Oscilloscopes provide the Logic Analyzer to meet users’ requirement. 1. Before connect the logic analyzer, please turn off the power source to avoid any possible damage during the connection. Connect Logic Analyzer 2. Connect the Logic cable to the digital input port on the front panel of the oscilloscope as shown in the above figure. There is a sign on the Logic Probe that you can only connect the cable in the proper direction.
RIGOL How to Connect USB and RS232 Devices DS1000E, DS1000D Series Oscilloscope support the USB flash drive and connections to PC or printer throught USB. The instrments also support RS232 communication.
RIGOL Troubleshooting 1. (1) (2) (3) (4) 2. (1) (2) (3) (4) (5) 3. After the oscilloscopes is powered on, the screen remains dark (no display): Check the power cord connection. Ensure the power switch is turned on. After the above inspection, restart the oscilloscope. If the problem still remains, please contact RIGOL for help. After the signal acquisition the waveform does not appear: Check the probes connected with the signals. Check the probes connected to the channels firmly.
RIGOL (3) Switch the Coupling into “HF Rejection” or “LF Rejection” in order to filter the noise which disturbs trigger. (4) Adjust the trigger Sensitivity and the hold off time. 5. After pressing the RUN/STOP button, the oscilloscope does not display any waveform on screen. Check whether the Trigger Mode is set to “Normal” or “Single” and see whether the trigger level is out of the signal range. If yes, set the trigger level in proper range by turning the knob or pressing the 50% button.
RIGOL Contact RIGOL If you have any problem or requirement occurs when using our products, please contact RIGOL Technologies, Inc. or the local distributors. In China: Please call Tel: (86-10) 8070 6688 Fax: (86-10) 8070 5070 Service & Support Hotline: 800 810 0002 9:00 am–5: 00 pm from Monday to Friday Or by e-mail: service@rigol.com Or mail to: RIGOL Technologies, Inc.
