User Manual

BESPA™ (Bidirectional Electronically Steerable Phased Array)

RF Controls Intelligent Tracking and Control System (ITCS™)

CS-490 North American (NA) BESPA™

Antenna Model

Configured with an RFC-445B RFID Reader CCA

Revision History

Rev Date Description

1.0- May2020 Changed for CS-490 NA

2.0- Aug2020 Updated for TCB Review

No part of this publication may be reproduced or used in any form, or by any electrical

or mechanical means, without permission in writing from RF Controls. This includes

electronic or mechanical means, such as photocopying, recording, or information

storage and retrieval systems. The material in this manual is subject to change without

notice.

Summary of content (9 pages)

PAGE 1
User Manual BESPA™ (Bidirectional Electronically Steerable Phased Array) RF Controls Intelligent Tracking and Control System (ITCS™) CS-490 North American (NA) BESPA™ Antenna Model Configured with an RFC-445B RFID Reader CCA Revision History Rev Date Description 1.02.0- May2020 Aug2020 Changed for CS-490 NA Updated for TCB Review © 2020 RF Controls, LLC. All rights reserved.
PAGE 2
Introduction This BESPA™ User Guide provides the basic information needed to install an individual BESPA antenna unit containing an RFC-445B RFID Reader CCA. This guide is not intended to provide instructions for installing, configuring and calibrating the RF Controls Intelligent Tracking and Control System (ITCS™). For additional information about RF Controls, LLC antennas, contact info@rf-controls.com.
PAGE 3
-BESPA Overview BESPA is a multi-protocol, multi-regional Radio Frequency Bidirectional Electronically Steerable Phased Array unit, which is used to Identify and locate RFID tags operating in the UHF 840 – 960 MHz frequency band. A number of BESPA units may be used together with an ITCS Location Processor to form an Intelligent Tracking and Control System (ITCS).
PAGE 4
-Indicator LEDs CS-490 Reader Indicator Lights The RF Controls CS-490 RFID antenna is equipped with three status indicators located on the top of the Radome.
PAGE 5
-INSTALLATION -Mechanical Installation Each model of the CS-490 family of BESPA units is mounted slightly differently. BESPA units weigh up to 15 lbs (7 kg), it is important to ensure that the structure, to which the BESPA is to be attached, is of sufficient strength. The BESPA may be ceiling mounted, wall mounted or attached to a suitable stand.
PAGE 6
Ethernet The Ethernet LAN connection uses the industry standard RJ-45 8P8C modular connector. A suitable Ethernet cable fitted with an RJ-45 plug is connected to the BESPA Array Antenna as shown in Figure 1. The BESPA is factory programmed with a fixed IP address which is shown on the label adjacent to the Ethernet connector. Non-Ionizing Radiation This unit incorporates a Radio Frequency Transmitter and should therefore be installed and operated so as to avoid exposure of any persons to unsafe emissions.
PAGE 7
-SOFTWARE Operation requires the purchase of a Software License. Software may then be downloaded from the RFC Customer Portal. https://support.rf-controls.com/login For additional information about RF Controls, LLC antennas, contact info@rf-controls.com. APPLICATION INTERFACE The BESPA uses an International Standard, Application Program Interface (API) as defined in ISO/IEC 24730-1. Further details of the API and commands are contained in the Programmer’s Reference Guide.
PAGE 8
-SAFETY INSTRUCTIONS Consignes de Sécurité This unit emits Radio Frequency non-ionizing radiation. The installer must ensure that the antenna is located or pointed such that it does not create an RF field in excess of that permitted by the Health and Safety Regulations applicable to the country of installation. Cet appareil émet Radio Fréquence rayonnements non ionisants.
PAGE 9
FCC and Industry Canada Modification Warning Statement Modification of this device is strictly prohibited. Any modifications to the factory hardware or software settings of this device will void all warranties and be deemed non-compliant with FCC and Industry Canada Regulations. La modification de ce dispositif est strictement interdite.
