Specification Sheet

Model D400 (4MP)
Image Sensor 1/3" CMOS Sensor
Effective Pixels 2560x1440 (4.0 Megapixels)
Lens f=4.0mm Fixed, F=2.0
Angle of View Horizontal: 80°, Vertical: 42°
Day/Night Mode Auto Switchover
Min. Illumination 0 Lux (With IR Illuminator)
IR Distance IR Distance 30 Meters (LED: 18pcs/14mil/850nm)
Backlight Compensation Support
Noise Reduction 3D DNR
Compression H.264
Resolution Main Stream: 2560x1440, 2048x1536, 2304x1296; Sub Stream: 640x360
Bitrate Main Stream: 1024Kbps~8192Kbps, Sub Stream: 64Kbps~512Kbps
Frame Rate Main Stream@25fps, Sub Stream@6fps
Audio Interface Built-in Microphone
Interface One 10M/100Mbps RJ45
Network Protocol HTTPS, SSL, TCP/IP, UDP, UPNP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Browser Supported IE, Edge, Chrome, Firefox, Safari
OS Supported PC: Windows, Mac OS; Smartphone: iOS, Android
Max. User Access 20 Users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
Power Supply DC12V & PoE (IEEE 802.3af)
Power Consumption <8W
Working Environment
-10℃~+55℃ (14°F~131°F), 10%~90%
Ingress Protection IP66
Dimensions Φ120*77mm
Weight 480g
D400-IP-Camera-Specifications
General
Network
Video
