RTL8197D-11AC AP/Router User’s Manual Rev. 1.0 04 Dec 2012 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.
RTL8197D-11AC AP/Router User's Manual COPYRIGHT ©2012 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp. DISCLAIMER Realtek provides this document ‘as is’, without warranty of any kind.
RTL8197D-11AC AP/Router User's Manual Table of Contents 1. GENERAL DESCRIPTION................................................................................................................................................0 2. FEATURES...........................................................................................................................................................................2 3. SYSTEM APPLICATIONS ...........................................................................
RTL8197D-11AC AP/Router User's Manual 1. General Description The RTL8197D is an integrated System-on-a-Chip (SoC) Application Specific Integrated Circuit (ASIC) L2 5-Port Ethernet switch. An RLX5281 CPU is embedded and the clock rate can be up to 660MHz. To improve computational performance, a 64Kbyte I-Cache, 32Kbyte D-Cache, 16Kbyte I-MEM, and 8Kbyte D-MEM are provided. A standard 5-signal P1149.1 compliant EJTAG test interface is supported for CPU testing and software development.
RTL8197D-11AC AP/Router User's Manual The RTL8197D is provided in a Thermally Enhanced Thin Profile Plastic Quad Flat Package, 176-Lead (TQFP176 E-PAD) package. It requires a 3.3V and 1.0V external power supply. 5-Port 10/100M Ethernet Router Network Processor 1 Track ID: JATR-3375-16 Rev. 1.
RTL8197D-11AC AP/Router User's Manual 2. Features SOC Embedded RISC CPU, RLX5281 with 64Kbyte I-Cache, 32Kbyte D-Cache, 16Kbyte I-MEM, 8Kbyte D-MEM Supports MIPS-1 ISA, MIPS16 ISA Clock Rate: 500MHz~660MHz Provides a standard 5-signal P1149.1 EJTAG test port Supports RLX5281 CPU suspend mode Peripheral Interfaces Five Ethernet MAC switch with five IEEE 802.
RTL8197D-11AC AP/Router User's Manual DDR1 DRAM Supports one DDR1 DRAM bank that can be configured as 16M/32M/64M/128Mbytes 16-bit DDR1 DRAM data bus supported. System totally supports up to 128Mbyte DDR1 DRAM memory space DDR2 DRAM Supports one DDR2 DRAM bank that can be configured as 32M/64M/128Mbyte 16-bit DDR2 DRAM data bus supported.
RTL8197D-11AC AP/Router User's Manual 3. System Applications IEEE 802.11b/g/n AP/Router Dualband Concurrent Router Network-Attached Storage (NAS) 4 Rev.1.
RTL8197D-11AC AP/Router User's Manual 4. Product specifications 4.1. Environmental 4.1.1. Operating Operating Temperature: Relative Humidity: 4.1.2. 0 to 70 C 5-90% (non-condensing) Storage Temperature: Relevant Humidity: -55 to 125 C 5-95% (non-condensing) 4.2. Functional Specifications Standards Bus Interface Form Factor Data Rate Media Access Control Modulation Techniques Network Architecture Table 1. Functional Specifications IEEE 802.
RTL8197D-11AC AP/Router User's Manual WiFi 2.4GHz: 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan WiFi 5GHz: 20MHz band width : Ch 36, 40, 44, 48, Ch 52, 56, 60, 64, Ch 100, 104, 108, 112, 116, 120, 124, 128,132,136, 140, Ch 149,153, 157,161, 165. Operating Channel 40MHz band width : Ch 38, 46, Ch 54, 62, Ch 102, 110, 118, 126, 134, Ch 151, 159. 80MHz band width : Ch 42 Ch 58 Ch 105, 122 Ch 155. Security 2.400GHz ~ 2.4835 GHz 5.1500GHz ~ 5.3500GHz 5.4700GHz ~ 5.7250GHz 5.
RTL8197D-11AC AP/Router User's Manual 4.3. Warning 4.3.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
RTL8197D-11AC AP/Router User's Manual 4.3.2 Industry Canada Statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: 1) this device may not cause interference and 2) this device must accept any interference, including interference that may cause undesired operation of the device French translation: Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence.
RTL8197D-11AC AP/Router User's Manual IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
RTL8197D-11AC AP/Router User's Manual (iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
RTL8197D-11AC AP/Router User's Manual fournir d'outil ou d'informations à l'utilisateur final en ce qui concerne le changement de réglementation de domaine. Tant que les 3 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité supplémentaires requis pour ce module installé.
RTL8197D-11AC AP/Router User's Manual French translation: Manuel d'information à l'utilisateur final L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module. Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme indiqué dans ce manuel. 4.3.
RTL8197D-11AC AP/Router User's Manual The Wireless AP/Router Hardware Power Jack, Reset button, USB, LAN, WAN, Antenna, WPS button 13 Rev.1.
RTL8197D-11AC AP/Router User's Manual Installing the Wireless PCIe miniCard module Software 1. 2. 3. 4. 5. EUT LAN IP：192.168.1.254 EUT WAN IP：172.1.1.1 Wireless SSID (2.4G)：RTK 11n AP 2.4G (5G)：RTK 11n AP 5G Wireless IP：192.168.1.254 Webpage： Realtek Semiconductor Corp. Headquarters No. 2, Innovation Road II, Hsinchu Science Park, 14 Rev.1.
RTL8197D-11AC AP/Router User's Manual Hsinchu, 300, Taiwan, R.O.C. Tel: 886-3-5780211 Fax: 886-3-5776047 www.realtek.com.tw 15 Rev.1.
