The Razer BlackWidow Tournament Edition features the all-new Razer™ Mechanical Switches that have been designed from the ground up with the aim of elevating the speed and responsiveness of the Razer BlackWidow gaming keyboard beyond the capabilities of current-gen mechanical switches. Tested and validated by the world’s top eSports athletes, we have identified the optimal actuation distance and reduced the tolerance for faster commands and greater precision when compared to standard mechanical switches.
CONTENTS 1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS .................................... 2 2. REGISTRATION / TECHNICAL SUPPORT ................................................... 2 3. TECHNICAL SPECIFICATIONS ................................................................... 3 4. DEVICE LAYOUT ...................................................................................... 4 5. INSTALLING YOUR RAZER BLACKWIDOW TE CHROMA ........................... 5 6. USING YOUR RAZER BLACKWIDOW TE CHROMA ...........
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS PACKAGE CONTENTS Razer BlackWidow Tournament Edition Chroma Gaming Keyboard USB Cable Carrying case Important Product Information Guide SYSTEM REQUIREMENTS PC / Mac with USB port Windows® 8 / Windows® 7 / Windows Vista® / Windows® XP (32-bit) / Mac OS X (10.8 – 10.10) Internet connection 200MB of free hard disk space 2.
3. TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Razer™ Mechanical Switches with 50g actuation force 60 million keystroke life span Chroma backlighting with 16.8 million customizable color options Compact layout 10 key roll-over anti-ghosting Fully programmable keys with on-the-fly macro recording Detachable braided fiber USB cable with cable strap Carrying case for protection 1000Hz Ultrapolling Razer Synapse enabled APPROXIMATE SIZE & WEIGHT: Width 366 mm / 14.
4. DEVICE LAYOUT A. B. C. D. E. F.
5. INSTALLING YOUR RAZER BLACKWIDOW TE CHROMA Step 1: Connect your Razer device to the USB port of your computer. Step 2: Install Razer Synapse when prompted* or download the installer from www.razerzone.com/synapse. Step 3: Create your Razer ID or login to Synapse with your existing Razer ID. *Applicable for Windows 8 or later. Note: By default, the Razer BlackWidow Tournament Edition Chroma is set to spectrum cycling. To customize the lighting, please install Razer Synapse.
6. USING YOUR RAZER BLACKWIDOW TE CHROMA Pressing the “FN” key in combination with the function keys will activate their secondary features. Listed below are the function keys and their features’ descriptions. Function Keys Features Description The audio volume controls allow you to mute ( ), decrease ( ) and increase ( ) the audio output. The media keys allow you to play/pause ( ) a track or skip tracks backward ( ) and forward ( ). The sleep key allows you to suspend all operating system activities.
ON-THE-FLY (OTF) MACRO RECORDING Follow these steps to create an OTF Macro Recording: 1. Press the key combination to start recording. 2. The Macro Recording Indicator will light up to show that the device is ready to record. 3. Type in the keys you want to record. 4. Press the key combination to stop the recording or the ESC key to cancel recording. The Macro Recording Indicator will start blinking to show that the device has stopped recording and is ready to save the macro. 5.
7. CONFIGURING YOUR RAZER BLACKWIDOW TE CHROMA Disclaimer: The features listed here require you to log in to Razer Synapse. These features are also subject to change based on the current software version and your Operating System. KEYBOARD TAB The Keyboard Tab is your default tab when you first install Razer Synapse. This tab allows you to customize your device’s profiles and key assignments.
Profile A profile is a convenient way of organizing all your custom settings and you can have an infinite number of profiles at your disposal. Any changes made within each tab are automatically saved to the current profile and stored into the cloud servers. You can create a new profile by clicking the button or delete the current profile by clicking the button. The button allows you to Copy, Import, and Export profiles.
Customize Tab The Customize Tab is where you can modify the basic functionalities of your device such as key assignments to suit your gaming needs. The changes made in this tab are automatically saved to your current profile.
Key Assignment Menu Initially, each key is set to DEFAULT. However, you may change the function of this key by clicking the desired key to access the Key Assignment Menu. Listed below are the customization options and their description. Default This option enables you to return the key to its original function. To choose the DEFAULT, simple select it from the Key Assignment Menu. Keyboard Function This option enables you to change any key into another keyboard function.
Mouse Function This option allows you to change any key into a mouse button function. To choose a mouse function, select MOUSE FUNCTION from the Key Assignment Menu and an ASSIGN BUTTON submenu will appear. Listed below are the functions which you can choose from the Assign Button submenu: Left Click Right Click Scroll Click Double Click Mouse Button 4 Mouse Button 5 Scroll Up Scroll Down Scroll Left Scroll Right - Performs a left mouse click using the assigned button.
Switch Profile The Switch Profile enables you to change profiles on the fly and immediately load all your pre-configured settings. When you select Switch Profile from the Key Assignment Menu, a sub-menu will appear that will allow you to choose which profile to use. An on-screen display will automatically appear whenever you switch profiles. Launch Program Launch Program allows you to launch a program or a website using the assigned key.
Windows Shortcuts This option enables you to assign the key into an Operating System shortcut command. For more information please visit: http://support.microsoft.com/kb/126449 Disable This option renders the assigned key unusable. Use Disable if you do not want to use the key or if it interferes with your gaming.
Lighting Tab The Lighting Tab is where you can customize the color of the lighting of individual keys or select pre-loaded lighting effects to be applied to the entire keyboard. You can also adjust the brightness of the lighting and set the system to turn off all lighting on the device when your monitor display is turned off. Changes made in this tab will be automatically saved to the current profile.
Pre-loaded lighting effects A number of pre-loaded lighting effects can be selected and applied to your keyboard lighting as a whole, such as spectrum lighting, breathing etc. The default effect is spectrum lighting. Select your desired effect and their corresponding properties (such as color) from the bottom area of this tab.
Gaming Mode Tab The Gaming Mode Tab allows you to customize which keys to disable when Gaming Mode is activated. Depending on your settings, you may choose to disable the Windows key, Alt + Tab and Alt + F4. An indicator will light up when the function is currently turned ON.
MACROS TAB The Macros Tab allows you to create a series of precise keystrokes and button presses. This tab also allows you to have numerous macros and extremely long macro commands at your disposal. The Macro section works similarly to Profile wherein you can rename a macro by typing on the field below MACRO NAME. There are also other options available in the macro section such as creating a new macro by clicking the current macro by clicking the Import, and Export macros. button.
The Macro section allows you to input the delay in-between commands. In RECORD DELAY the delay in-between commands are registered as how it is entered. The DEFAULT DELAY uses a predefined time (expressed in seconds) as the delay. And NO DELAY omits all the pauses in-between keystrokes and button presses. Note: You may use up to three decimal places when inserting values on the seconds (sec) field.
Once you have recorded a macro, you may edit the commands you have entered by selecting each command on the macro screen. Each keystroke or button press is arranged sequentially with the first command shown at the top of the screen. The button allows you to edit a particular command and the enables you to delete a command. The option to move the command up or down.
Once you have pressed the button, a new display window will appear beside the list of macro commands. The dropdown menu on this window allows you to choose a keystroke or a delay to be added in before or after the highlighted macro command.
You may add in a new set of macro commands by clicking the button on the keystroke menu; or input time delays on the duration field using the delay menu.
STATS & HEATMAPS Note: The images shown here are for reference only and may differ from the actual device. Stats & Heatmaps help you analyze your gameplay by tracking your in-game mouse clicks, mouse movement and keyboard usage and visualizing it in form of heatmap overlays. This function is disabled by default. To enable this function, click the notification icon next to your user name in the Razer Synapse window and select “Enable Stats & Heatmaps”.
Return to Razer Synapse and a new “Stats” tab will be available. Simply click the tab to open the function window.
Games List Stats & Heatmaps work by tracking the usage of all supported devices for each game. When the feature is enabled, it automatically scans your system for installed games and adds them to the Games List located on the left side of the screen. Click to show or hide the Games List. From this list, you can add more games that have not been automatically detected, using the button, edit games with the button or re-scan your system with the button to search for newly installed games.
Stats Tab By default, the Stats Tab shows you the overall statistics of all your Razer devices for all games and all time. You can select a specific game via the game list on the left side, change the time period using the SHOWING dropdown menu, or the Razer device using the DEVICES dropdown menu.
Heatmaps Tab - Keyboard Heatmaps Tab shows the most frequently used keys on your Razer device for each game on your Games List.
Social Media You can share your heatmap image on social media networks such as Facebook or Twitter directly from Razer Synapse. From the Heatmaps tab, click the Share button on the bottom right of the screen. You will be prompted to login to the selected social media using an existing account if you have not already done so. You can also login to your social media accounts first from the “SETTINGS” screen. From the Stats & Heatmaps window, click . Select the “ACCOUNTS” tab.
8. SAFETY AND MAINTENANCE SAFETY GUIDELINES In order to achieve maximum safety while using your Razer BlackWidow TE Chroma, we suggest that you adopt the following guidelines: 1. Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to www.razersupport.com for support. Do not attempt to service or fix the device yourself at any time. 2.
4. During gameplay, relax your wrist and keep it straight. If you do the same tasks with your hands repeatedly, try not to bend, extend or twist your hands for long periods. 5. Do not rest your wrists on hard surfaces for long periods. Use a wrist rest to support your wrist while gaming. 6. Customize the keys on your keyboard to suit your style of gaming in order to minimize repetitive or awkward motions while gaming. 7. Do not sit in the same position all day.
9. LEGALESE COPYRIGHT AND INTELLECTUAL PROPERTY INFORMATION ©2015 Razer Inc. Patent Pending. All rights reserved. Razer, For Gamers By Gamers, and the triple-headed snake logo are trademarks or registered trademarks of Razer Inc. and/or affiliated companies in the United States or other countries. All other trademarks are the property of their respective owners. Actual product may differ from pictures. Information is correct at time of printing.
COSTS OF PROCUREMENT For the avoidance of doubt, in no event will Razer be liable for any costs of procurement unless it has been advised of the possibility of such damages, and in no case shall Razer be liable for any costs of procurement liability exceeding the retail purchase price of the Product. GENERAL These terms shall be governed by and construed under the laws of the jurisdiction in which the Product was purchased.
