0 | For gamers by gamers™

We all require a pair of headphones that can keep up with our work and play, a

personal companion that you can take about whether you are chilling on the couch or

out on the move. Introducing the Razer Adaro Wireless Bluetooth® headphones –

wireless freedom for your music.

The Razer Adaro Wireless is built to follow you wherever you go. Featuring the

advanced Bluetooth® 4.0 standard with aptX technology, the Razer Adaro Wireless

easily connects to your Bluetooth® audio devices, providing pristine CD-quality audio

for up to 20 hours.

Packing high performance, custom-tuned 40mm neodymium magnet drivers, the Razer

Adaro Wireless delivers crisp, natural sounding acoustics for an amazing audio

experience. These powerful drivers are housed in the Razer Adaro Wireless’ custom

developed, fully adjustable architecture, allowing for an extremely comfortable and

lightweight design.

With its brilliant Razer Adaro sound, wireless portability and comfortable form factor,

the Razer Adaro Wireless are the perfect headphones for cord-free music enjoyment

on the go.

Summary of content (15 pages)

PAGE 1
We all require a pair of headphones that can keep up with our work and play, a personal companion that you can take about whether you are chilling on the couch or out on the move. Introducing the Razer Adaro Wireless Bluetooth® headphones – wireless freedom for your music. The Razer Adaro Wireless is built to follow you wherever you go. Featuring the advanced Bluetooth® 4.
PAGE 2
TABLE OF CONTENTS 1. PACKAGE CONTENTS / HARDWARE REQUIREMENTS ......................................... 2 2. REGISTRATION / TECHNICAL SUPPORT ............................................................... 3 3. TECHNICAL SPECIFICATIONS ............................................................................... 4 4. DEVICE LAYOUT .................................................................................................. 5 5. USING YOUR RAZER ADARO WIRELESS - BLUETOOTH® HEADPHONES ...............
PAGE 3
1.
PAGE 4
2. REGISTRATION / TECHNICAL SUPPORT REGISTRATION Sign up now for a Razer Synapse account to get real-time information on your product’s warranty status. To learn more about Razer Synapse and all its features, visit www.razerzone.com/synapse2. If you are already a Razer Synapse user, register your product by clicking on your email address at the Razer Synapse application and select Warranty Status from the dropdown list. To register your product online, visit www.razerzone.com/registration.
PAGE 5
3. TECHNICAL SPECIFICATIONS             Bluetooth® v4.0 with aptX Technology Drivers: 40 mm Neodymium Magnets Frequency Response: 20Hz – 20kHz Impedance: 32 Ω Sensitivity: 91dB ± 3dB Max Input: 50mW Operating Distance: 10m Playtime: Up to 20hrs Standby Time: Up to 300hrs Charging Time: 2.5hrs Charging Cable: 0.
PAGE 6
4. DEVICE LAYOUT A. B. C. D. E.
PAGE 7
5. USING YOUR RAZER ADARO WIRELESS - BLUETOOTH® HEADPHONES CHARGING YOUR HEADPHONES For best results, please charge the battery fully the first time you use the Razer Adaro Bluetooth® Headphones. A depleted battery will fully charge in about 2.5 hours. POWER ON Power On Press and hold the power for 3 seconds until the LED flashes blue. You should hear 4 short beeps.
PAGE 8
PAIRING YOUR HEADPHONES TO A BLUETOOTH® DEVICE 1. Upon powering on, the LED should be flashing blue and red alternatively. This indicates that the headphone is now in pairing mode. 2. Activate Bluetooth® on your device and search for new Bluetooth® devices. 3. Select “Razer Adaro Wireless” from the list of Bluetooth® devices found. 4. Wait for the pairing to complete. Your headphone LED will flash blue 5 times and you should hear 1 short beep.
PAGE 9
PLAYBACK CONTROLS The following audio playback controls can be accessed directly on the earcups. Play/Pause Press once Volume Up/Down Changing Tracks Slide and hold Slide and release POWER OFF Power Off Press and hold the power button for 3 seconds until the LED flashes red twice. You should hear 4 short beeps.
PAGE 10
INDICATORS Battery LED Indication Sound Indication None Status Charging None Fully charged 5 short beeps Battery low Solid Red LED Off 2 red flashes every 3 seconds 9 | razer
PAGE 11
In Use LED Indication Flashing blue and red alternatively Sound Indication 4 short beeps in increasing tones Status Headphones are powered on and in pairing mode 2 short beeps Bluetooth® connection disconnected. Headphones return to pairing mode 2 short beeps followed by 2 low beeps Connected device is out of range of the headphones. Connection will be reestablished automatically if the device returns within range in 1 minute. Else, the headphones return to pairing mode.
PAGE 12
EXTENDING YOUR HEADPHONE’S LIFESPAN We recommend stretching the headphones gently apart before placing them over your head to minimize headband stress. However, please avoid overstretching the headphones beyond its technical limits.
PAGE 13
6. SAFETY AND MAINTENANCE SAFETY GUIDELINES In order to achieve maximum safety while using your Razer Adaro Wireless Bluetooth® Headphones, we suggest that you adopt the following guidelines: 1. Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to www.razersupport.com for support. Do not attempt to service or fix the device yourself at any time. 2.
PAGE 14
7. LEGALESE COPYRIGHT AND INTELLECTUAL PROPERTY INFORMATION ©2013-2014 Razer Inc. All Rights Reserved. Razer, the Razer Triple-Headed Snake logo, the Razer distressed word logo and other trademarks contained herein are trademarks or registered trademarks of Razer Inc. and/or its affiliated or associated companies, registered in the United States and/or other countries. Razer Inc.
PAGE 15
COSTS OF PROCUREMENT For the avoidance of doubt, in no event will Razer be liable for any costs of procurement unless it has been advised of the possibility of such damages, and in no case shall Razer be liable for any costs of procurement liability exceeding the retail purchase price of the Product. GENERAL These terms shall be governed by and construed under the laws of the jurisdiction in which the Product was purchased.
