4-543.fm Page 1 Wednesday, June 30, 1999 3:52 PM Cat. No. 14-543 OWNER’S MANUAL Please read before using this equipment.
14-543.fm Page 2 Wednesday, June 30, 1999 3:52 PM FEATURES Your Radio Shack CD-3319 combines a compact disc player, an AM/FM radio, and a cassette deck system into an all-in-one portable package. You can use the CD-3319 indoors or out, at work or play. You can listen to the radio, pre-recorded cassette tapes or compact discs, and even make your own recordings. CD PLAYER FEATURES Automatic Search Music System (ASMS) — lets you quickly locate and play any track on a CD.
14-543.fm Page 3 Wednesday, June 30, 1999 3:52 PM Auxiliary Input Jacks — let you connect an additional audio source such as a TV, VCR, turntable, external CD changer or a cassette deck to your system. For your records, we recommend you record the serial number of the CD3319 in the space provided. The serial number is in the battery compartment. Serial Number __________________ The CD player in this stereo system is made and tested to meet exacting safety standards.
14-543.fm Page 4 Wednesday, June 30, 1999 3:52 PM CONTENTS Preparation ........................................................................................................... 5 Connecting the Speakers ................................................................................ 5 Attaching the Speakers ............................................................................. 5 Connecting the Speaker Wires .................................................................
14-543.fm Page 5 Wednesday, June 30, 1999 3:52 PM PREPARATION Important: • Complete all connections to the CD-3319 before you connect it to power. • Be sure to follow all of the installation instructions described in the enclosed “Important Safety Instructions.” Place the speakers so the distance between them is the same as the distance between the listening area and a point halfway between the speakers.
14-543.fm Page 6 Wednesday, June 30, 1999 3:52 PM Connecting the Speaker Wires Follow these steps to connect the speaker wires to the CD-3319. 1. Unwind as much speaker wire as you need from the back of each speaker, then slide the wire through one of the slots on the back of each speaker to hold it in place. 2. Insert the left speaker’s plug into SPEAKER L on the back of the CD-3319, then insert the right plug into SPEAKER R.
14-543.fm Page 7 Wednesday, June 30, 1999 3:52 PM CONNECTING POWER Using Batteries You can power the CD-3319 from any of the following: You can power the CD-3319 from nine D batteries (not supplied). For the best results, we recommend alkaline batteries (such as Radio Shack Cat. No. 23550).
14-543.fm Page 8 Wednesday, June 30, 1999 3:52 PM 3. Replace the battery compartment cover. meet these specifications could damage the CD-3319. Cautions: • If the CD-3319 does not operate properly or if the sound weakens or distorts, replace the batteries. • Always dispose of the old batteries promptly and properly. • Never leave dead, old, or weak batteries in the CD-3319. They can leak chemicals and corrode or damage electronic circuits. Using Your Vehicle’s Battery 1.
14-543.fm Page 9 Wednesday, June 30, 1999 3:52 PM USING HEADPHONES Listening Safely For private listening, you can connect a pair of stereo headphones (not supplied) with a 1/8-inch plug. Your local Radio Shack store carries a wide selection of stereo headphones. To protect your hearing, follow these guidelines when you use headphones. To connect the headphones, insert the headphones’ 1/8-inch plug into the PHONES jack. • Set the volume to the lowest setting before you begin listening.
14-543.fm Page 10 Wednesday, June 30, 1999 3:52 PM RADIO OPERATION Warning: To protect your hearing, set VOLUME to its lowest setting before you turn on the radio. Follow these steps to use the radio. 1. Set FUNCTION to RADIO to turn on the radio. The POWER indicator lights. Notes: • For the best AM reception, rotate the CD-3319 to position the built-in AM antenna. • For the best FM reception, fully extend the telescoping antenna and swivel it to the position that produces the best reception.
14-543.fm Page 11 Wednesday, June 30, 1999 3:52 PM CD PLAYER OPERATION LOADING A CD 1. Set FUNCTION to CD. The POWER indicator lights, and dISC appears in the display. PUSH OPEN on the CD 2. Press compartment cover. The CD compartment opens. PLAYING A CD 1. After loading a CD, press PLAY/ PAUSE . The CD player plays the CD starting with the first track. The display shows , the current track number, and the elapsed time.
14-543.fm Page 12 Wednesday, June 30, 1999 3:52 PM Warning: Your CD-3319 CD player has a wide dynamic range. If you turn the volume too high during the low volume sections of a program, you might damage your hearing during sudden loud sections. Note: If you do not stop the CD player, it plays to the end of the last track and automatically stops. When the CD player is stopped, disappears from the display and the total number of tracks appears. 3.
14-543.fm Page 13 Wednesday, June 30, 1999 3:52 PM 3. Select the track you want by pressing SKIP/SEARCH or . The track number you selected appears on the display. 4. Press PROGRAM. The selected track is stored, and the next program number appears on the display. Checking a Programmed Sequence To check the programmed sequence, while the CD is stopped, repeatedly press PROGRAM. The display shows each stored track number. 5. Repeat Steps 3 and 4 to store up to 16 tracks.
-543.fm Page 14 Wednesday, June 30, 1999 3:52 PM SPECIAL CD PLAYER FEATURES Automatic Search Music System (ASMS) You can use ASMS to search through the CD to select a desired track or programmed sequence. rest of the last track and begins playing the first track. To select a track while the CD player is stopped or during pause, press SKIP/SEARCH or until the desired track number appears on the display. Then press PLAY/PAUSE to play the track.
14-543.fm Page 15 Wednesday, June 30, 1999 3:52 PM Repeat Play Note: Intro play does not work with a programmed sequence. You can repeat a single track, the entire CD, or a programmed sequence. • To repeat a single track, press MODE before or during play. REPEAT appears on the display and the CD player repeatedly plays the selected track. • To repeat the entire MODE twice before or REPEAT ALL appears on and the CD player plays the entire CD. CD, press during play.
14-543.fm Page 16 Wednesday, June 30, 1999 3:52 PM • You must select shuffle play before playback. If you select shuffle play while a CD is playing, SHUFFLE appears on the display but the function does not work. Before play, press MODE until SHUFFLE appears on the display. Then press PLAY/PAUSE . The CD player selects and plays each of the tracks randomly. After all of the tracks have played once, the CD player automatically stops.
14-543.fm Page 17 Wednesday, June 30, 1999 3:52 PM CASSETTE PLAYER OPERATION LOADING A CASSETTE TAPE Note: Take up any slack in the tape by turning the cassette’s hub with a pencil. If you do not remove excess slack, the tape might become tangled in the record/playback mechanism. Avoid touching the tape. 3. Close the cover. PLAYING A CASSETTE TAPE 1. Set FUNCTION to TAPE. 1. Press STOP/EJECT to open the cassette compartment cover. 2. Load a cassette tape. 2.
14-543.fm Page 18 Wednesday, June 30, 1999 3:52 PM • To rapidly wind the tape forward or backward, press FAST-F or REWIND . The cassette deck automatically stops at the end of the tape. RECORDING ON A CASSETTE TAPE You can record from the CD player, the radio, or an auxiliary audio source to a cassette tape. Notes: • Be sure the cassette player is stopped before fast-forwarding or rewinding a cassette tape. • Always remove and store cassette tapes when you are not using them. 4.
14-543.fm Page 19 Wednesday, June 30, 1999 3:52 PM 3. If you are not starting from track 1, select the desired track or program a sequence (if you do not want to record the entire CD), then press PLAY/PAUSE twice to pause the CD player. appears. on the tape 4. Press RECORD deck. RECORD and PLAY lock down, the CD player automatically begins playing the first track, and the tape deck begins recording from the CD . and SYNC appear on the display.
14-543.fm Page 20 Wednesday, June 30, 1999 3:52 PM TAPE CARE TIPS Erasing a Cassette Tape Preventing Accidental Erasure If you no longer want a recording, you can record over it or erase it. Cassette tapes have two eraseprotection tabs — one for each side. To protect a recording from being accidentally recorded over or erased, use a screwdriver to remove one or both of the cassette tape’s erase-protection tabs.
14-543.fm Page 21 Wednesday, June 30, 1999 3:52 PM CARE AND MAINTENANCE Your Radio Shack CD-3319 Portable Triple Play Compact Disc Player and AM/FM Stereo Cassette Recorder is an example of superior design and craftsmanship. The following suggestions will help you care for the CD-3319 so you can enjoy it for years. Keep the CD-3319 dry. If it gets wet, wipe it dry immediately. Water contains minerals that can corrode electronic circuits. Handle the CD-3319 carefully.
14-543.fm Page 22 Wednesday, June 30, 1999 3:52 PM FCC INFORMATION This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits provide reasonable protection against radio and TV interference in a residential area. However, your equipment might cause TV or radio interference even when it is operating properly.
14-543.fm Page 23 Wednesday, June 30, 1999 3:52 PM SPECIFICATIONS CASSETTE DECK Tape Speed ........................................................................... 17/8 ips (4.75 cm/sec.) Tape System ............................................................................ 4 Track/Side/Stereo Signal to Noise Ratio .......................................................................................43 dB Channel Separation .............................................................................
14-543.fm Page 24 Wednesday, June 30, 1999 3:52 PM Power Supply ........................................AC 120 V, 60 Hz/DC 13.5 V / 9 D Batteries Dimensions (HWD) ....................................................... 107/16 × 217/8 × 91/2 inches (265 × 555 × 240 mm) Weight (without batteries) ....................................................................... 14 lbs 3 oz 6.44 Kg Specifications are typical; individual units might vary.
