GSM/GPRS/GPS Tracker GL100S User Manual TRACGL100SUM001 Revision: 1.01 http://www.queclink.com sales@queclink.
GL100S User Manual Document Title GL100S User manual Version 1.01 Date 2011-7-8 Status Release Document Control ID TRACGL100SUM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers.
GL100S User Manual Contents Contents............................................................................................................................................. 2 0. Revision history............................................................................................................................. 2 1. Introduction................................................................................................................................... 2 2. Product Overview................
GL100S User Manual 0. Revision history Revision Date Author Description of change 1.
GL100S User Manual 1. Introduction GL100S is a powerful GPS locator which is designed for shoes and assets tracking. With superior receiving sensitivity, fast TTFF and GSM frequencies 850/900/1800/1900MHz. Its location can be real time or schedule tracked by backend server or specified terminals.
GL100S User Manual 2. Product Overview 2.1.
GL100S User Manual 2.2. Buttons/Mini USB Interface Description Button /Mini USB Interface Description Power Key z Turn on GL100S z Turn off GL100S. (If power key is enabled) Mini USB interface z Connect a 5V DC adapter can power GL100S and charge the internal battery z Connect a 3.7V Li-ion or Li-Polymer battery can power GL100S z Backend server developer or administrator can use the Data_Cable to configure GL100S 2.3. LEDs Description There are three LED in GL100S, the description as following.
GL100S User Manual AC-DC Power Adapter (Standard accessory) It is used to charge the internal battery of GL100S. GL100S Data Cable It is the USB data cable which can be used for firmware upgrading and configuration.(Please note , it only for backend server developer or administrator ,It is not in delivery list of GL100S) 3.2. Battery Charging z Please connect AC-DC power adapter with GL100S. z Insert the AC-DC power adapter into the power socket. z During charging, the PWR LED is flashing fast.
GL100S User Manual Method 1: Press the Power key at least 3 seconds and release it to turn on GL100S. At the same time, PWR LED will light on. z Turn off: Method 1: Press the power key about 2 seconds; PWR LED will fast flash and then turn off, it indicates that GL100S is turned off. The time of power off is depended on the quality of network. The maximum time of power off is 90 seconds. It is only valid to turn off when using internal battery.
GL100S User Manual 4. Troubleshooting and Safety info 4.1. Troubleshooting Trouble Possible Reason Solution After GL100S is turned on, the Net LED flashes quickly always. The SIM card is not inserted. Please insert the SIM card into GL100S. The signal is too weak; GL100S can’t register to the network. Please move GL100S into place with good GSM coverage. PIN locked Using SIM card without SIM-PIN, or unlock SIM-PIN. The SIM card in GL100S doesn’t support GPRS. Try a GPRS supported SIM card.
GL100S User Manual 4.2. Safety info z Please do not disassemble the device by yourself. z Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion. z Please do not use GL100S on the airplane or near medical equipment.
