7120990001 QP-990-U1 DPMR Digital Two-Way Radio USER MANUAL Quantun Electronics, LLC
THANK YOU We are grateful you have chosen Quantun production. This Professional Digital two-way radio incorporates the advanced technology and craft, It is endowed all-round digital functions and remarkable quality to refresh your experience, You will be pleased with the quality and features of our product. Please read this manual carefully to ensure you know how to property operate the radio before use.
CONTENTS User Safety Information Compliance with RF Energy Exposure Standards Precautions and notices Product Inspection Radio Overview Parts of the Radio The functions of the LEDs and Beeps Table Programmable Auxiliary Functions Radio embedded features Getting Started Battery Antenna Accessory Installation Basic Operations Call VOX Operation Troubleshooting Care and Cleaning Service 2
User Safety Information READ THIS IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION BEFORE USING YOUR QUANTUN PORTABLE TWO-WAY RADIO. Compliance with RF Energy Exposure Standards Your Quantun two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy.
EU Regulatory Conformance As certified by the qualified laboratory, the product is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. Please note that the above information is applicable to EU countries only. Precation and Notices Government law prohibits the operation of unlicensed radio transmitters. Illegal operation is punishable by fine or imprisonment Of both.
Product Inspection Please carefully take the transceiver out of the box. We recommend that you confirm the items listed in the following table are enclosed before discarding the box. If any items are missing or have been damaged during shipment, file a claim with the carrier immediately. Available Accessories Item Qty. (Pcs.
Radio Overview Parts of the Radio 9 10 11 12 13 14 15 1 2 3 4 5 6 7 8 (3) SK2 (4) SK3 (Programmable (Programmable Side key 2) Side key 3) (6)Menu operation key (7)Numeric keypad (8) Microphone (9) Antenna (10) Status Indicator (11) Radio On-Off/ Volume Control Knob (12) Accessory Jack (13) Battery (14) Battery Latch (15) Belt Clip (16) (1) SK1 (Programmable Side key 1) (2) PTT Key (5) LCD Display 6
LCD Icon Icon Name Icon RSSI Radio status No signal More bars indicate better signal strength Message New message/unread message InBox is full Scanning is in progress Scan Scanning pauses on a non-priority channel Scanning pauses on Priority Channel 1 Scanning pauses on Priority Channel 2 Battery Strength More bars indicate more battery power Monitor The Monitor feature is active Speaker The speaker is unmated.
Transmitting Status Indicator glows red when transmitting. When TOT timer expires, the radio sounds beep tone continuously. TOT pre-alert:: A beep is heard. Receiving Status Indicator glows green when carrier is present. Call ended (within the presettime period) LED glows orange Scanning VOX Status Indicator flashes green once every 1 second, while scanning is in process. Scan Start Alert Tone (programmable by your dealer): A beep is heard.
Radio embedded features Analog Digital Receive Automatically Identify Channel number Voice Selectable Squelch Level Busy Channel Lockout Tx time-out-timer CTCSS/CDCSS signalling Squelch Tail Elimination Battery Save function Low battery Alert 9
Getting Started Battery Safety Precautions The battery is not fully charged at the factory. It is recommended to charge the new battery for 5 hours before using it. Also, batteries that may have set longer than 2 months since the last charge should be charged before using it. The battery capacity will be optimum after being charged/discharged two or three times. When the battery’s charge is depleted, charge the battery or replace the battery with a new one. Caution: 1.
1. Considering the battery's self-discharge characteristics, fully charge the battery prior to long time storage, to avoid battery damage due to over-discharge. 2. Recharge the battery after 6 months’ storage, to avoid reducing battery capacity due to over-discharge. 3. Notice the ambient humidity and temperature for the battery storage. Please store it in cool dry area under room temperature, to reduce self-discharge capacity.
Antenna Stubby antennas are ideal for communication within limited range. Fine and long antennas optimizes communication coverage, ideal when the radio is worn on the belt because they are flexible and soft. Rainy days or forest locations may narrow your communication range, please repare in advance to avoid potential inconvenience. Accessory Installation Battery Attaching the battery 1. Insert the battery into the bottom of the radio. See arrow ①. 2.
2 1 Antenna Attaching the Antenna 1. Align the threaded end of the antenna with the radio’s antenna connector. 2. Turn the antenna clockwise to fasten it, as shown in Figure 5. Figure 5 To remove the antenna, rotate it counterclockwise. Attaching the Accessory Open (not remove) the accessory cover, plug the audio accessory firmly into the accessory jack.
Figure 8 Note: Using the radio with audio accessory may affect the waterproof performance of the radio.
Basic Operations Turn On/Off the Radio Turning the Radio On/Off Rotate the Radio On-Off/Volume Control knob clockwise/counterclockwise until a click is heard to turn the radio on/off. Adjusting the Volume Adjusting the Volume After turning the radio on, rotate the Radio On-Off/Volume Control knob clockwise to increase the call volume, or counterclockwise to decrease it. Selecting a Channel Ensure the LCD Display is in the home screen, press the ▲ ▼ key to select a channel.
respond to a received Private Call, your radio will display the missed call icon. Group Call Transmitting a Group Call You may transmit a Group Call through any of the following methods. When transmitting a Group Call, the Group call icon will appear. ● Transmitting a call to the preset contact In the home screen, hold down the PTT key to transmit a Group Call to the Group Call contact preset for the current channel. ● Transmitting a call through Contact List 1） Go to “Contact -> Contact List”.
17
Troubleshooting Trouble Solution Cannot power on the radio. The battery has run out. Please recharge the battery or replace it with a new one. The battery may not be properly installed. Remove the battery and attach it again. The operating time is noticeably shorter than normal performance, even though the battery is properly charged. The battery has worn out, and it is time to buy a new battery. The battery is not fully charged. Make sure the charge indicators glow green.
Care and Cleaning Do not place the radio in a dusty or dirty environment. Clean the radio with a lint-free cloth to remove dirt or grease, to avoid poor contact due to excessive dust. Clean the radio using a lint-free cloth moistened with clean water and a mild dishwashing liquid. Avoid subjecting the radio to corrosives, solvents or spirits.
Service If you need service, contact your Quantun dealer.
