SPECIFICATION SHEEET

CPU

TVS-471-i3-4G: Dual-core Intel Core i3-4150 3.5 GHz Processor

DRAM

System memory: 4 GB DDR3 RAM

Memory module pre-installed: 2 GB x2

Total memory slots: 2

Memory expandable up to: 16 GB (8GB x2)

NOTE:

1. When upgrading RAM, the original RAM module in the upgradable slot must be removed.

2. For the information of RAM module installation and compatible NAS models, please refer to the

QNAP RAM Module Installation Guide.

Flash Memory

512MB DOM

Hard Drive

4 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive or 2.5-inch SATA, SSD hard drive

NOTE:

1. The standard system is shipped without hard drives.

2. For the HDD compatibility list, please visit Compatibility list

Hard Drive Tray

4 x hot-swappable and lockable tray

LAN Port

4 x Gigabit RJ-45 Ethernet port

(Expandable up to 8 x 1 Gb LAN or 4 x 10 Gb + 4 x 1 Gb LAN by installing optional dual-port 10 Gb

and 1 Gb network card)

Note:

1. For the optional network card compatibility list, please visit Compatibility list of Expansion Card

2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS

Hardware Manual.

LED Indicators

Status, USB, LAN

USB

3x USB 3.0 port (front: 1, rear: 2)

2x USB 2.0 port (rear)

Support USB printer, pen drive, USB hub, and USB UPS etc.

Summary of content (12 pages)

PAGE 1
SPECIFICATION SHEEET CPU DRAM Flash Memory Hard Drive Hard Drive Tray LAN Port LED Indicators USB TVS-471-i3-4G: Dual-core Intel Core i3-4150 3.5 GHz Processor System memory: 4 GB DDR3 RAM Memory module pre-installed: 2 GB x2 Total memory slots: 2 Memory expandable up to: 16 GB (8GB x2) NOTE: 1. When upgrading RAM, the original RAM module in the upgradable slot must be removed. 2.
PAGE 2
Power Consumption (W) 1 System: Power button and reset button System warning Tower 177 (H) x 180 (W) x 235 (D) mm 6.97 (H) x7.09 (W) x 9.25 (D) inch 4.56 kg (10.05 lbs) (Net) 5.7 kg (12.57lbs) (Gross) TVS-471-i3-4G: HDD Standby: 28.19 In Operation: 50.52 Sound Level* Temperature Relative Humidity Power Supply PCIe Slot Fan (with 4 x WD WD20EFRX hard drive installed) Sound pressure (LpAm): 17.3 dB(A) 0~40˚C 5~95% non-condensing, wet bulb: 27˚C.
PAGE 3
5. Online RAID Level Migration 6. Storage expansion via QNAP REXP-1000 Pro (Max: 4 units) or QNAP UX-500P / UX-800P (Max: 2 units) expansion unit 7. Bad block scan and hard drive S.M.A.R.T. 8. Bad block recovery 9. RAID recovery 10. Bitmap support Supported Clients* 1. Apple Mac OS 10.7 or later 2. Linux and UNIX 3. Microsoft Windows 7, 8, and 10 4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016 Power Management 1. Wake on LAN 2. Internal hard drive standby mode 3. Scheduled power on/off 4.
PAGE 4
. Apple Safari 4. Local user access control for CIFS, AFP, FTP, and WebDAV 5. Application access control for Photo Station, Music Station, Video Station, and Multimedia Station 6. Subfolder permissions support for CIFS/SMB, AFP, FTP, and File Station Multilingual Support myQNAPcloud Service 1. Chinese (Traditional & Simpliﬁed), Czech, Danish, Dutch, English, Finnish, French, German, 1.
PAGE 5
File System 1. Internal hard drive: EXT4 2. External hard drive: EXT4, EXT3, NTFS, FAT32, HFS+ Qsync 1. Syncs files among multiple devices with SSL support 2. Selective synchronization for syncing specific folders only 3. Share team folder as a file center for team collaboration 4. Shares files by links via e-mail 5. Policy settings for conflicted files and file type filter support 6. Version control: up to 64 versions. 7. Incremental synchronization for HDD space saving 8.
PAGE 6
7. Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC 8. UPnP & Bonjour Discovery 9. USB Wi-Fi Adapter Support 6. Resource monitor 7. Network recycle bin for file deletion via CIFS/SMB, AFP and File Station o Automatic cleanup o File type filter 8. Comprehensive logs (events & connection) 9. Syslog client/server 10. Mobile app: Qmanager for remote system monitoring & management Security 1.
PAGE 7
4. Shared Folder Aggregation (CIFS/SMB) 2. VMware vSphere (ESXi 5.x) 3. VMware VAAI for iSCSI and VAAI for NAS 4. vSphere Plug-in 5. Citrix XenServer (6.2) 6. Windows Server 2012 R2 Hyper-V 7. Supports Microsoft ODX 8. QNAP SMI-S provider for Microsoft SCVMM FTP Server 1. FTP over SSL/TLS (Explicit) 2. FXP supported 3. Passive ftp port range control Transcode Management 1. Transcode video files to 240p, 360p, 480p, 720p and 1080p resolution 2. Automatic video transcoding for watched folders 3.
PAGE 8
6. File Compression and decompression (ZIP and 7z) Backup Station 1. Remote replication server (over rsync) 2. Real-time remote replication (RTRR) to another QNAP NAS or FTP server 3. Works as both RTRR server & client with bandwidth control 4. Real-time & scheduled backup 5. Encryption, compression, file filter, and transfer rate limitation 6. Encrypted replication between QNAP NAS servers 7. Desktop backup with QNAP NetBak Replicator for Windows 8. Apple Time Machine backup support 9.
PAGE 9
10. Third party backup software support: Veeam backup & replication, Acronis True Image, Arcserve backup, EMC retrospect, Symantec Backup Exec, etc. 4. Image editor: a easy way to highlight the focus in your image 5. Support note publishing with a single link 6. Support key word search 7. Provide Chrome Extension: Notes Station Clipper o Clip web page content to your note 8. Mobile app: Qnotes Cloud Storage Backup 1. Amazon S3 2. Amazon Glacier 3. WebDAV-based cloud storage 4. Microsoft Azure 5.
PAGE 10
3. LDAP server, LDAP client 4. Domain users login via CIFS/SMB, AFP, FTP, and File Station Virtualization Station 1. Support Virtual Machine (VM) creation to run an operating system such as Windows, Linux, Unix and Android 2. Support importing VM from the other virtual platform, e.g. VirtualBox, VMware Workstation 3. Support exporting VM with *.ovf, *.qvm formats 4. VM clone 5. VM snapshot 6. HTML5-based shared remote console 7. User-based permission setting 8. Support USB device pass-through 9.
PAGE 11
8. Download Station Signage Station 1. Support dynamic content includes video, image, music, and text message 2. Multi-user collaboration 3. Support email and social network sharing 4. Support design software - iArtist Lite for Windows® 5. Support various browser playback ( Chrome, Firefox, IE, Safari) 6. Support most viewed, latest released and different categories content list iSCSI (IP SAN) 1. iSCSI Target 2. Multi-LUNs per Target 3. Up to 256 Targets/LUNs Combined 4. Supports LUN Mapping & Masking 5.
PAGE 12
9. iSCSI Connection and Management by QNAP Finder (Windows) 10. Virtual Disk Drive (via iSCSI Initiator) 11. Max No. of Virtual Disk Drives: 8 (1). Not all services are supported. *The data encryption functions may not available in accordance to the legislative restrictions of some countries. Design and specifications are subject to change without notice.
