PRE220/240 User Manual www.audac.
ADDITIONAL INFORMATION This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu.
Index Introduction 5 Precautions 6 Safety requirements 6 Caution servicing 6 EC Declaration of Conformity 6 Waste of Electrical and Electronic Equipment (WEEE) 7 Caution 7 Chapter 1: Pin connections and connectors 9 Connection standards 9 Chapter 2: Front & rear panel 10 Front panel overview 10 Front panel description 10 Rear panel overview 11 Rear panel description 11 Enabling phantom power & talkover 12 Chapte
Introduction 10-Channel stereo preamplifiers The PRE2xx series preamplifiers are solutions for applications where a large number (up to 8) of microphones (or other mono balanced audio inputs) need to be mixed to two output zones. The multifunctional stereo design with a total of 10 inputs allows connection for any type of audio source such as microphones, Bluetooth devices or line level audio sources.
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE. DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. ENSURE THERE IS ADEQUATE VENTILATION TO COOL THE UNIT.
CAUTION - SERVICING This product contains no user serviceable parts. Refer all servicing to qualified service personnel.
POWER SUPPLY AND POWER CORD REQUIREMENTS Power supply class I grounding requirements: For protection from fault currents, the equipment shall be connected to a grounding terminal. Plug the system power cord into an AC outlet that provides a ground connection. Substitute cords may not provide adequate fault protection.
Chapter 1 Pin connections and connectors CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed corresponding to international wiring standards for professional audio equipment. Cinch (RCA): For unbalanced line input connections Tip: Signal White: Left Sleeve: Red: Ground Right XLR: For balanced signal input connections Pin 1: Ground Pin 2: Signal + Pin 3: Signal - 3-Pin Terminal Block: For balanced signal input & link output connections.
Chapter 2 Front & rear panel Front panel overview Front panel description Input mixing controls: Using the input mixing controls, the individual level for each input can be adjusted. Each input control is provided with a clip indicator LED which illuminates when the maximum level (clipping) is almost reached. To ensure the best signal-to-noise ratio, illumination of this indicator should only occur at peak levels.
When pairing with your device for the first time, the ‘PAIR’ button should be pressed and the LED will start blinking for about 2 minutes. During this period, the device can be discovered and is indicated as Bluetooth ID ‘AUDAC PRE series xxxx’ (where the xxxx stands for an unique ID for each single device). When both devices have been paired before, the transmitter will be recognized by the receiver and will allow continuous pairing without pressing the ‘PAIR’ button. 3.5 mm Jack input (CH2): A 3.
Rear panel description AC Power inlet with fuse: The mains power supply (100-240V AC - 50/60 Hz) has to be applied to this AC power inlet. The connection is made by an IEC C14 power connector and is fitted with a fuse. When replacing the fuse, make sure that the value of the replacement fuse matches the value of the original fuse. (T500mAL/250V) Balanced stereo line output: The balanced stereo line outputs are implemented using two 3-pin terminal block output connectors.
Enabling phantom power & talkover Phantom power: The phantom power switches on the rear side of the pre-amplifier enable phantom power (48V) to the inputs for powering condenser microphones. The first switch ‘MIC 1’ enables phantom power to the first input, the second switch ‘MIC 2’ enables phantom power to the second input while switch ‘Mic 3-8’ enables phantom power to all other microphone inputs.
Chapter 3 Additional information Technical specifications Inputs Mic 1 to 8 Type Balanced microphone Connector Female XLR Sensitivity -6 dB ~ -50 dB Other 3-Band tone control Phantom power (48V DC) Talkover Channel 1 & 2 Type Connector Sensitivity Unbalanced stereo line Female RCA (2x) +4 dB ~ -20 dB Bluetooth Type Integrated Bluetooth receiver Mixed with Channel 1 Connector Male SMA connector Other Included antenna
Dimensions (W x H x D) 482 x 88 x 330 mm Unit height 2 HE Weight PRE220 4.45 Kg PRE240 4.
