D4 Mio with Bluetooth EVOKE_D4_Mio_Bluetooth_v2_UKAus.
EVOKE_D4_Mio_Bluetooth_v2_UKAus.
D4 Mio with Bluetooth Thank you for choosing Evoke D4 Mio with Bluetooth. This manual will get you up and running in no time and explains how to make the most of Evoke’s great features. If you need additional help with topics not covered in this manual, please visit the Pure support pages at support.pure.com. Volume Select 1 EVOKE_D4_Mio_Bluetooth_v2_UKAus.
Safety Instructions 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions – The safety and operating instructions should be retained for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions – All operating and use instructions should be followed. 5.
Contents 4 Introduction 4 Front panel controls 5 Rear connectors 5 Remote control 6 Switching between Sleep, Standby and On 7 Getting started 8 Changing digital radio stations 8 Changing FM radio stations 9 Pausing and controlling scrolling text 10 Storing and selecting presets 10 To quick-store a station to a preset button (1–4) 10 To store a station to the preset list (1–15) 10 To recall a preset when listening to digital radio or FM radio 11 Using Bluetooth 12 Setting the alarms a
Introduction Front panel controls SnoozeHandle Tap to snooze the alarm Volume dial Adjust and mute volume (see page 6) Volume Select Presets 1 − 5+ Store up to 15 digital and 15 FM radio preset stations (see page 10) Source Press to select Digital radio, FM radio, Auxiliary input or Bluetooth (see page 6) Menu Setup options (see page 14) Remote control sensor See page 5 Timer Kitchen timer (see page 13) Sleep timer (see page 13) Select dial Turn and press to browse and select radio stations (see pa
Model 440 Model D440D440 Rear connectors 9V DC 9V DC Stereo Speaker Stereo Speaker Stereo Speaker Speaker 9V DC9V DC Stereo Connect to supplied mains adapter only 3.
Switching between Sleep, Standby and On Evoke has three power modes, Standby, Sleep and On. In Standby, Evoke uses minimal power and displays the clock. In Sleep mode, Evoke is ready to stream music using Bluetooth. See page 11 for more information. To enter Sleep mode, press Standby. To enter Standby mode, press and hold Standby. Once in Sleep/Standby mode, press Standby to switch to On.
Getting started Quick set up Note: If you have a ChargePAK F1 rechargeable battery (sold separately) fit it now before plugging in Evoke. See page 18 for more information. 1 • Unclip the aerial and fully extend it (steps A and B). • Insert the jack of the supplied mains adapter into the socket on the rear of the radio (C). • Plug the mains adapter into the mains supply (D). B A 9V DC 9V DC D 9V DC Aux in Aux in C 2 Select your language when prompted.
Changing digital radio stations Using the front panel controls Turn the Select dial left or right to browse through the list of available digital stations. Push the Select dial to change the station. Select Select Station list BBC Radio 6Music BBC Radio 6Music Now playing: Race For T Using the remote control 1. 2. Press the < or > button on the remote to browse through the list of available digital stations. Press the Select button to change the station.
Pausing and controlling scrolling text Using the front panel controls 1. When ‘Scrolling text’ information is displayed in either digital or FM radio, push the Select dial to pause the scrolling text. BBC Radio 6Music Now playing: Race For T 2. Select BBC Radio 6Music Playing: Race For Th Turn the Select dial right and left to scroll forwards and backwards through the text. To exit push the Select dial. Select BBC Radio 6Music Prize by Flaming Lips Select > Exit Using the remote control 1. 2.
Storing and selecting presets Store up to 15 digital and 15 FM radio stations for quick access. BBC Radio 6Music Now playing: No Cars G Preset 1 stored Preset 06 Preset empty Preset 10 Preset empty Preset 10 stored Preset 10 DR theJazz theJazz Now: Remember by Ha To quick-store a station to a preset button (1–4) Tune to the digital or FM radio station you want to store.
Using Bluetooth If your phone or tablet is capable of storing audio files, you can use Bluetooth to stream any music stored on your phone or tablet to Evoke. Note: Adding a Bluetooth device varies on different mobile devices. See your Bluetooth mobile device manual for specific information. Preparing Evoke to stream audio using Bluetooth 1. Enable Bluetooth on your mobile device. 2. On your mobile device, select the option to add a new Bluetooth device.
Setting the alarms and timers On Alarm 1 Setup Alarm time 08:00 Alarm repeat Daily Alarm source FM Alarm FM Last listened Setting an alarm Evoke has two alarms which can switch the radio on and tune to a digital or FM radio station or sound an alarm tone. 2. Turn and press the Select dial to select ‘On’. The alarm is now active. 3. To set the time you want the alarm to sound turn the Select dial to adjust the hours and then push to confirm. Repeat to adjust the minutes. 4.
Changing the alarm snooze time Set snooze time 5 minutes 1. Press Menu. 2. Turn and press the Select dial to choose ‘Clock’. 3. Turn and press the Select dial to choose ‘Set snooze time’. 4. Turn and press the Select dial to change the snooze time between 1 and 59 minutes. Kitchen timer 01 hours 00 minutes Setting the kitchen timer Kitchen timer 01 hours 30 minutes To set the kitchen timer Evoke has a countdown timer which will sound an alarm after a set time period. 1.
Options and settings Digital radio settings Autotune You can use the autotune function to automatically scan for new digital radio stations and remove inactive ones. Note: Autotune is only available when you have selected ‘Digital radio’ as the radio source. To carry out an autotune: 1. Press Menu. 2. Turn and press the Select dial to choose ‘Autotune’. The number of stations found will be displayed during the autotune.
General settings Changing your preferred language You can select the language that your Evoke uses for menus and options. 1. Press Menu. 2. Turn and press the Select dial to choose ‘Settings’. 3. Turn and press the Select dial to choose ‘Language’. 4. Turn and press the Select dial to select a menu language from ‘English’, ‘French’, ‘German’ or ‘Italian’. Carrying out a factory reset Resetting your Evoke removes all presets, stored stations, alarms and resets all other options to default settings.
Clock settings Setting the time and date The time and date on Evoke are automatically set by the FM or digital radio signal. If the time/date does not update automatically, you can manually set it using this option. Note: Any time or date updates received by an FM or a digital broadcast will override manual settings, if clock synchronization is enabled (see below for more information). Setting the time and date manually 1. 2. 3. 4. 5. Press Menu. Turn and press the Select dial to choose ‘Clock’.
Display settings Adjusting the display You can adjust the brightness and time-out duration of the display for when the unit is switched on and in standby. To change display options: 1. Press Menu, scroll to ‘Display settings’ and push the Select dial. 2. Now choose either ‘Active’ to change settings that apply when the unit is switched on, or ‘Standby & Sleep’ to change settings that apply in standby and sleep.
Appendix Installing the ChargePAK F1 Note: Switch Evoke off and disconnect from the mains power supply before installing ChargePAK F1. Aerial Evoke D4 Mio Aux in 9V DC Aerial Aerial Evoke D4 Mio Aux in 9V DC 9V DC 9V DC Aux in Note: If you are charging ChargePAK for the first time or after an extended period of inactivity it is recommended that it is charged for around 24 hours to ensure full battery power.
Changing Evoke’s removable covers and handle trim Note: Switch Evoke off and disconnect from the mains power supply before changing the removable covers. 9V DC 9V DC Aux in 19 EVOKE_D4_Mio_Bluetooth_v2_UKAus.
Help and advice Secondary and inactive stations (<>) Secondary digital radio services Some stations have accompanying secondary services which provide extra information or alternative content and may only be broadcast at certain times. If a station has a secondary service available, the station shows ‘>>’ next to its name in the station list and the secondary service appears next to the station in the list. A secondary service has a ‘<<’ before its name in the station list.
Technical specifications Radio Digital and FM radio Frequencies DAB/DAB+/DMB-R/Parametric stereo decode up to 256 kbps, FM radio 87.5-108 MHz Bluetooth A2DP support Speaker Full-range 3" drive unit Inputs 9V DC power adapter socket (230V supplied). 3.5mm stereo Aux In for auxiliary devices. USB connection (Mini-B type) for product upgrades only Outputs 3.
Correct disposal of this product This marking indicates that this product should not be disposed with other household waste throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection system or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
Pure Warranty Statement for Australia This statement replaces any reference to warranty which may be contained elsewhere within this manual. What do you need to do now? • Keep your proof of purchase as evidence of your purchase date. This proof of purchase would need to be presented if warranty service was ever required. • Register your purchase on-line at http://www.pure.com/au/product-registration/ for free technical support.
