(P6917-TG) Specification Sheet

Incandescent Complete Round Recessed
Unwired
Non-IC
T
ype
-TG
P6917
■■
Finish Dimensions (Inches)
Catalog No.
White Lamping A B C D
P6917 -TG 45w BR30 6-5/8 6-5/8 5-3/4 5-7/8
Ceiling opening 4-1/2
Specifications:
Wiring
• No junction box provided
• Fitter for 1/2" conduit or BX cable
provided
• 4-1/2 feet of wire furnished
Construction-Mounting
• Steel constr
uction throughout
• Mounting frame is installed first
• T
rim and housing are one unit and push
up into mounting frame
• Clips furnished for mounting housing in
finished ceiling
• Maximum ceiling thickness is 1-1/2"
• 26" adjustable bar hangers available,
order P8716-01
Electrical
• Medium based porcelain socket with
nickel plated brass screw shell
• Socket mounted in fixed position
• Unwir
ed
Labeling
• Non-IC rated
• UL listed for damp locations
Trim
• Open trim in white finish which is
permanently attached to the housing
Progress Lighting
Post Office Box 5704
Spartanburg, South Carolina
29304-5704
www.progresslighting.com
Rev
. 7/06
C
D
A
B
