¨ Model No. 831.299270 Serial No. USER'S MANUAL Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal SEARS, ROEBUCK AND CO. HOFFMAN ESTATES, IL 60179 CAUTION Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Patent Pending Visit our website at www.proform.
¨ TABLE OF CONTENTS IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions. pation of 450 joules. The surge suppressor must be electrically rated for 120 volts AC and 15 amps.
24. Inspect and tighten all parts of the treadmill regularly. 21. When using i-Fit.com CDÕs and videos, an electronic ÒchirpingÓ sound will alert you when the speed and/or incline of the treadmill is about to change. Always listen for the ÒchirpÓ and be prepared for speed and/or incline changes. In some instances, the speed and/or incline may change before the personal trainer describes the change. 25. Never insert or drop any object into any opening. 26.
BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM¨ 730CS treadmill. The 730CS treadmill combines advanced technology with innovative design to help you get the most from your exercise program in the convenience and privacy of your home. And when youÕre not exercising, the unique 730CS can be folded up, requiring less than half the floor space of other treadmills. Monday through Saturday, 7 a.m. until 7 p.m. Central Time (excluding holidays).
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver . Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
3. Locate the plastic tie in the post on the left Upright (82). Hold a Handrail Extension (85) in the position shown. Insert the plastic tie into the Handrail Extension as you insert the Handrail Extension into the post. Attach the Handrail Extension with three Screws (76). The plastic tie is tied to the Pulse Wire (124). Be careful to avoid damaging the Pulse Wire. The Pulse Wire is used with the optional chest pulse sensor (see page 18).
OPERATION AND ADJUSTMENT THE PERFORMANT LUBETM WALKING BELT This product is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the plug illustrated in drawing 1 below. A temporary adapter that looks like the adapter illustrated in drawing 2 may be used to connect the surge suppressor to a 2-pole receptacle as shown in drawing 2 if a properly grounded outlet is not available. Your treadmill features a walking belt coated with PERFORMANT LUBETM, a high-performance lubricant.
CONSOLE DIAGRAM Manual/Program Indicators LED Track Displays Note: If there is a thin sheet of clear plastic on the face of the console, remove it. Displays i-Fit.com Indicator Clip Key home stereo, portable stereo, or computer and play special iFit.com CD programs (CDÕs are not included). IFit.com CD programs automatically control the speed and incline of the treadmill as a personal trainer guides you through every step of your workout. High-energy music provides added motivation.
exercise, change the speed of the walking belt as desired by pressing the SPEED buttons. STEP-BY-STEP CONSOLE OPERATION Make sure that the on/off switch near the power On cord is in the on Position position. Next, make sure that the key is removed from the console and the power cord is properly plugged in (see HOW TO PLUG IN THE POWER CORD on page 8). To stop the walking belt, press the STOP button. The TIME/INCLINE/SEG TIME display will begin to flash.
CALS/FAT CALS/ PULSE displayÑThis display shows the approximate numbers of calories and fat calories you have burned (see FAT BURNING on page 22). Every seven seconds, the display will change from one number to the other, as shown by the arrows in the display. This display will also show your heart rate when the pulse sensor is used (see step 6 on this page). 6 Measure your pulse, if desired. Stand on the Sensors foot rails and place your hands on the metal contacts on the pulse bar.
One speed setting and one incline setting are programmed for each segment. When only three seconds remain in the first segment, a series of tones will sound and the treadmill will automatically adjust to the speed and incline settings for the second segment. HOW TO USE PERSONAL TRAINER PROGRAMS 1 Insert the key into the console. When the key is inserted, the four displays and various indicators on the console will light.
HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5mm LINE OUT jack, see instruction B. If your stereo has only a PHONES jack, see instruction C. To use iFit.com CDÕs, the treadmill must be connected to your portable CD player, portable stereo, home stereo, or computer with CD player. See pages 13 and 14 for connecting instructions. To use iFit.
HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. Note: If your computer has a 3.5mm LINE OUT jack, see instruction A. If your computer has only a PHONES jack, see instruction B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter.
HOW TO CONNECT YOUR VCR HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV with a built-in VCR, see instruction B. If your VCR is connected to your home stereo, see HOW TO CONNECT YOUR HOME STEREO on page 14. To use iFit.com CDÕs or videocassettes, the treadmill must be connected to your portable CD player, portable stereo, home stereo, computer with CD player, or VCR.
4 ¥ adjust the volume of your CD player or VCR. If the volume is too high or too low, the console may not detect the program signals Press the PLAY button on your CD player or VCR. A moment after the button is pressed, your personal trainer will begin guiding you through your workout. Simply follow your personal trainerÕs instructions.
5 HOW TO USE PROGRAMS DIRECTLY FROM OUR INTERNET SITE Read and follow the on-line instructions for using a program. Our new internet site at www.iFit.com allows you to access a large selection of programs that interactively control your treadmill to help you achieve your specific exercise goals. In addition, you can play iFit.com audio and video programs directly from the internet. By adding an optional upgrade module to the console, you can use virtually endless features on our internet site.
8 IMPORTANT: The CALORIES/FAT CALORIES/ PULSE display should be blank. If a ÒdÓ appears in the display, the console is in the ÒdemoÓ mode. This mode is intended to be used only when a treadmill is displayed in a store. When the console is in the demo mode, the power cord can be plugged in, the key can be removed from the console, and the displays and indicators on the console will automatically light in a preset sequence, although the buttons on the console will not operate. If a ÒdÓ appears in the CALS.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE 1 Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be permanently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right.
TROUBLE-SHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our toll-free HELPLINE at 1-800-736-6879, Monday through Saturday, 7 a.m. until 7 p.m. Central Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a UL-listed surge protector, rated at 15 amps, with a 14-gauge cord of five feet or less in length. b. If the walking belt is overtightened, treadmill performance may decrease and the walking belt may become damaged. Remove the key and UNPLUG THE POWER CORD. Using the allen wrench, turn both rear roller adjustment bolts counterclockwise, 1/4 of a turn.
CONDITIONING GUIDELINES uses easily accessible carbohydrate calories for energy. Only after the first few minutes does your body begin to use stored fat calories for energy. If your goal is to burn fat, adjust the speed and incline of the treadmill until your heart rate is near the lowest number in your training zone. WARNING: Before beginning this or any exercise program, consult your physician.
PART LISTÑModel No. 831.299270 R0100A To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty.
65 36 100 65 36 101 59 12 47 64 68 89 70 67 55 46 75 62 61 57 45 63 68 60 59 120 44 71 47 1 41 39 68 40 3 47 44 32 2 43 54 46 33 4* 42 66 37 41 45 22 53 62 47 68 75 39 21 76 EXPLODED DRAWINGÑModel No. 831.
104 97 103 101 47 110 118** 121** 72 85 124 82 76 108 20 102 107 101 122 104 105 97 97 101 113 95 115 79 86 96 84 114 103 119 101 83 111 112 76 124 117 15 34 69 99 110 47 109 90 101 122 117 20 107 84 108 77 86 79 97 95 101 15 89 87 EXPLODED DRAWINGÑModel No. 831.
The model number and serial number of your PROFORM¨ 730CS treadmill are listed on a decal attached to the frame. See the front cover of this manual to find the location of the decal. Model No. 831.299270 QUESTIONS? All replacement parts are available for immediate purchase or special order when you visit your nearest SEARS Service Center. To request service or to order parts by telephone, call the toll-free numbers listed at the left.
