MCA9129-90-A Installation & Service Manual

All specifications are subject to change without notice. Contact the factory for complete performance data.

044-05060 Rev. AC 1-1 July 2001November 2002

Section 1 General Description

1-1 Introduction

This manual contains information and procedures for installation, operation, and maintenance of

Powerwave’s MCA9129-90

MCA9129-90-A multicarrier cellular amplifier. The manual is organ-

ized into six sections as follows:

Section 1. General Description

Section 2. Installation

Section 3. Operating Instructions

Section 4. Principles of Operation

Section 5. Maintenance

Section 6 Troubleshooting

1-2 General Description

The MCA9129-90MCA9129-90-A (see figure 1-1) is a linear, feed-forward power amplifier that

operates in the 25 MHz frequency band from 869 MHz to 894 MHz. The amplifier can simultane-

ously transmit multiple frequencies, with better than -65 dBc third order intermodulation distortion

(IMD) at 100 watts output, or –60 dBc IMD at 120 watts output. It is designed for use in an ampli-

fier system that is modular in design, and is ideally suited for use in AMPS/TDMA/CDMA base

stations. When used in a subrack employing four MCA9129-90

MCA9129-90-A amplifiers, the

system offers up to 360 watts output at

–65dBc IMD performance level (430 watts output at –60dBc IMD). The plug-in Model MCA9129-

90MCA9129-90-A amplifier modules can each provide 120 watts of power and function com-

pletely independently of each other. The amplifier modules are designed for parallel operation to

produce high peak power output and backup redundancy for remote applications. All solid-state,

the system is designed to provide trouble-free operation with minimum maintenance. The sys-

tem's modular construction and unique and highly effective LED-based operational status and

fault indicators help minimize downtime. The turn-on and turn-off sequences of voltages are fully

automatic, as is overload protection and recycling. Inadvertent operator damage from front panel

manipulation is virtually impossible.

Each amplifier module has a status connector that allows the host system to monitor the amplifier

module performance. The front panel of each amplifier module has unit level status/fault indica-

tors and an RF on/off/reset switch. Primary power for the amplifier is +27 Vdc. Cooling for each

plug-in amplifier module is provided by three fans, two mounted on the front and one on the rear

of the module. The fans draw outside air through the front of the module and exhaust hot air out

through the rear of the module.

1-3 Functional and Physical Specifications

Functional and physical specifications for the amplifier are listed in tables 1-2 and 1-3.

1-4 Equipment Changes

Powerwave Technologies, Inc. reserves the right to make minor changes to the equipment, in-

cluding but not necessarily limited to component substitution and circuitry changes. Changes that

impact this manual may subsequently be incorporated in a later revision of this manual. To that

end, we ask that you, our customer, share with us any information acquired in field situations that

would enhance this manual.
