I
Copyright Copyright 2017 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
This transmitter must not be co-located located or operating in conjunction with any other antenna or transmitter. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 26cm between the radiator & your body.
CONTENTS Chapter 1.Product Introduction ........................................................................................................... 7 1.1 Package Contents ............................................................................................................... 7 1.2 Product Description ............................................................................................................ 8 1.3 Product Features...................................................................
4.4.6 4.5 4.6 Dos Protection ........................................................................................................ 41 Wireless.............................................................................................................................. 42 4.5.1 Wireless Settings .................................................................................................... 42 4.5.2 WDS Link Settings ...............................................................................
FIGURES FIGURE 1-1 THREE-WAY VIEW .............................................................................................................................. 11 FIGURE 1-2 REAR PANEL ...................................................................................................................................... 12 FIGURE 2-1 POE AND LAN PORT CONNECTION ..................................................................................................... 16 FIGURE 2-2 FINISH INSTALLATION .............
FIGURE 4-30 SECURITY SETTINGS – AP/WDS AP MODE ..................................................................................... 48 FIGURE 4-31 SECURITY SETTINGS – CB/WDS STA/CR MODE ............................................................................ 48 FIGURE 4-32 SECURITY SETTINGS – WDS BRIDGE MODE .................................................................................... 49 FIGURE 4-33 SECURITY SETTINGS – WEP .........................................................................
User Manual of WBS-502AC Chapter 1. Product Introduction I 1.1 Package Contents Thank you for choosing PLANET WBS WBS-502AC series. Before installing the CPE,, please verify the contents inside the package box. 用前: 0.5 行 格式化: 間距 套用前: WBS-502AC Quick Installation Guide PoE Injector & Power Cord 用前: 0.5 行 格式化: 間距 套用前: 用前: 0.5 行 格式化: 間距 套用前: Mounting Ring x 1 Screw Set x 1 Rubber x 1 用前: 0.5 行 格式化: 間距 套用前: 用前: 0.5 行 格式化: 間距 套用前: Sealing Nut x 1 Bracket x 1 Dynamic Stick x 1 用前: 0.
User Manual of WBS-502AC 1.2 Product Description Ultra-high-speed Enterprise Outdoor Wireless Solution PLANET WBS-502AC 5GHz 900Mbps 802.11ac Outdoor Wireless CPE supports IEEE 802.11ac standard with 2T2R MIMO mechanism, which brings the latest wireless technology into outdoor infrastructure. The WBS-502AC supports standard IEEE 802.3at Power over Ethernet (PoE) and features IEEE 802.
User Manual of WBS-502AC Completely Secure Wireless Network The WBS-502AC supports 152-bit WEP, WPA/WPA2, WPA-PSK and WPA2-PSK wireless encryptions, the advanced WPA2-AES mechanism and 802.1X RADIUS authentication, which can effectively prevent eavesdropping by unauthorized users or bandwidth occupied by unauthenticated wireless access. Furthermore, any users are granted or denied access to the wireless LAN network based on the ACL (Access Control List) that the administrator pre-established.
User Manual of WBS-502AC Outdoor Environmental Characteristics IP55 rating IEEE 802.3at PoE design, IEEE 802.
User Manual of WBS-502AC 1.4 Hardware Description 用後: 0.5 行 格式化: 間距 套用後: Dimensions (Φ x H): 190 x 38mm Figure 1-1 Three-way View 1.4.1 The Bottom Panel – Port The Bottom panel provides the physical connectors connected to the power adapter and any other network device. Figure 1-2 shows the bottom panel of the WBS-502AC.
User Manual of WBS-502AC Bottom/Side Panel 用後: 0.
User Manual of WBS-502AC Hardware Interface Definition Object Description PoE LAN Port 10/100/1000Mbps RJ45 port, auto MDI/MDI-X IEEE 802.3at PoE PD supported, 54VDC In 格式化: 間距 套用前: 0.2 行, 套 用後: 0.2 行 10/100/1000Mbps RJ45 port, auto MDI/MDI-X, LAN2 Port IEEE 802.3af PoE PSE Reset Button Press and hold the Reset button on the device for over 10 seconds to return to the factory default setting. Table 2-2 Hardware Interface Definition -13- 格式化: 間距 套用前: 0.2 行, 套 用後: 0.
User Manual of WBS-502AC Chapter 2. Connecting to the AP 2.1 Preparation before Installation 2.1.1 Safety Precautions 1. To keep you safe and install the hardware properly, please read and follow these safety precautions. 2. If you are installing the WBS-502AC for the first time, for your safety as well as others’, please seek 3. Keep safety as well as performance in mind when selecting your installation site, especially where there 4.
User Manual of WBS-502AC OUTDOOR INSTALLATION WARNING ! IMPORTANT SAFETY PRECAUTIONS: LIVES MAY BE AT RISK! Carefully observe these instructions and any special instructions that are included with the 格式化: 間距 套用後: 0.5 行 equipment you are installing. CONTACTING POWER LINES CAN BE LETHAL. Make sure no power lines are anywhere where possible contact can be made. Antennas, masts, towers, guy wires or cables may lean or fall and contact these lines.
User Manual of WBS-502AC 2.3 Installing the AP Please install the AP according to the following Steps. s. Don't forget to pull out the power plug and keep your hands dry. Step 1. PoE and LAN port connection: (1) Remove the bottom cover cover. (2) Connect one end of the Ethernet cable into the LAN (802.3at PoE) port of the device and the other end to the PoE port on the PoE Injector. (3) Connect the power cord with the PoE Injector and plug the other end into an electrical outlet.
User Manual of WBS-502AC 用前: 0.5 行 格式化: 間距 套用前: Figure 2-3 Pole Mounting 用前: 0.5 行 格式化: 間距 套用前: Step 4. Wall Mounting: (1) Put the rubber into the bracket bracket. (2) Plug the dynamic stick into the bracket. (3) Screw the sealing nut and assemble parts, and make sure they are well tightened. (4) Put the lock washer on the dynamic stick. (5) Assemble the mounting parts to the device. (6) Mark and drill two pilot holes aligning to the screw holes of the bracket.
User Manual of WBS-502AC Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your AP within minutes. A computer with wired Ethernet connection to the Wireless AP is required for the first-time configuration. 3.1 Manual Network Setup -- TCP/IP Configuration The default IP address of the WBS-502AC is 192.168.1.253. And the default Subnet Mask is 255.255.255.0. These values can be changed as you desire.
User Manual of WBS-502AC Figure 3-1 TCP/IP Setting Now click OK to save your settings. Now, you can run the ping command in the command prompt to verify the network connection between your PC and the AP. The following example is in Windows 7 OS. Please follow the Steps below: 1. Click on Start > Run. 2. Type “cmd” in the Search box.
User Manual of WBS-502AC Figure 3-2 Windows Start Menu 3. Open a command prompt and type ping 192.168.1.253, and then press Enter. If the result displayed is similar to Figure 4-3, it means the connection between your PC and the AP has been established well. Figure 3-3 Successful result of Ping command If the result displayed is similar to Figure 4-4, it means the connection between your PC and the AP has failed.
User Manual of WBS-502AC Figure 3-4 Failed result of Ping command If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your AP. Some firewall software programs may block a DHCP request on newly installed adapters. 3.2 Starting Setup in the Web UI Itt is easy to configure and manage the WBS-502AC with the web browser. Step 1. To access the configuration page, open a web browser and enter the default IP address http://192.168.1.
User Manual of WBS-502AC Default IP Address: 192.168.1.253 Default User Name: admin Default Password: admin If the above screen does not pop up, it may mean that your web browser has been set to a proxy. Go to Tools menu> Internet Options> Connections> LAN Settings in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it. After you enter into the Web User Interface, click Wireless on the left hand side of the screen to configure the wireless connection.
User Manual of WBS-502AC Chapter 4. Configuring the AP This chapter instructs you how to quickly configure the CPE in different operation modes. 4.1 Operation Mode Go to the “Network Wireless” page to configure the operation mode which is suitable to your application. Figure 4-1 Wireless – Basic The page includes the following settings: Object Description Enter a name for the device (1-32 characters). The name you type • Device Name appears in SNMP management.
User Manual of WBS-502AC 20MHz • Extension Channel • Channel • Transmit Power Select upper or lower channel. Your selection may affect the Auto channel function. Select the appropriate channel and frequency. Select Auto to enable auto-channel selection. The transmission power of the device (value: auto). To meet the regional regulation, this option is not allowed to be configured through the user interface. Select a data rate from the drop-down list. The data rate affects • Data Rate throughput.
User Manual of WBS-502AC 4.2 Overview This section provides the current system summary, system log and connection status including Wireless Client List, WDS Link List, DHCP Client Table and Connection Status to assist the administrator in viewing the network status. right corner of each function page, you can click “Home” to go back to the Main page to view the In the upper-right current system status and click “Reset Reset” to force the system reboot or reset the device to factory defaults.
User Manual of WBS-502AC Figure 4-4 Main Status -26-
User Manual of WBS-502AC The page includes the following settings settings: Object Description • Device Information • LAN Information S Shows the general system information such as device name, MAC address, country, current time, and firmware version. S Shows Local Area Network settings such as the LAN IP address, subnet mask, DHCP server, and Rx/Tx packets.
User Manual of WBS-502AC Figure 4-6 Wireless Client List The page includes the following settings: Object Description • SSID:# The SSID number that the client is associated with. • MAC Address The MAC address of the associated client. • Tx (Bytes) The current transmit packet of the associated client. • Rx (Bytes) The current received packet of the associated client. • RSSI (dBm) The current signal strength of the associated client.
User Manual of WBS-502AC • Refresh Click Refresh to update the current list. 4.2.5 DHCP Client Table Click “Overview -> DHCP Client Table” to view the current DHCP client. The DHCP Client Table is only available in CR (WISP) mode. Figure 4-8 DHCP Client List The page includes the following settings: Object Description • MAC Address The MAC Address of the DHCP client. • IP The IP assigned to the DHCP client. • Host Name The Host Name of the DHCP client.
User Manual of WBS-502AC Figure 4-9 Connection Status The page includes the following settings: Object Description • Network Type The current operation mode of the device. • SSID The SSID of the connected AP. • BSSID The MAC Address of the connected AP. • Connection Status The status of the connection. • Wireless Mode The current wireless mode of the AP. • Current Channel The current channel used of this connection. • Security The encryption method of the AP.
User Manual of WBS-502AC Figure 4-10 LAN IP Settings The page includes the following settings: Object Description Select Obtain an IP address automatically (DHCP) to receive the IP • IP Network Setting from DHCP server. Select Specify an IP address to configure the AP to use static IP. • IP Address The LAN IP of the AP. The default is 192.168.1.253. You can change it according to your needs. • IP Subnet Mask The LAN subnet mask of the AP. • Default Gateway Enter the Gateway IP address of the AP.
User Manual of WBS-502AC 4.3.2 Spanning Tree Settings The Spanning Tree Protocol (STP) allows network to provide a redundant link in the event of a link failure. Click “Network Basic” to enable/disable Spanning Tree Settings. Figure 4-11 Spanning Tree Settings The page includes the following settings: Object Description • Spanning Tree Status Click Enable to enable or click Disable to disable the option. Specify Hello Time in seconds.
User Manual of WBS-502AC Figure 4-12 DHCP Server Settings The page includes the following settings settings: Object Description • IP Address The LAN IP of the AP. • IP Subnet Mask The LAN subnet mask of the AP. • Use Router As DHCP Server Select it to enable DHCP server. In here the device is acting as a router. • Starting IP Address Specify the starting IP address for the DHCP range. • Ending IP Address Specify the ending IP address for the DHCP range.
User Manual of WBS-502AC Figure 4-13 WAN Settings – All The page includes the following common settings in each Internet Connection Type Type: Object Description • DHCP: Dynamic IP addressing dressing assigns a different IP address each time a device connects to an ISP service provider. • Static IP: Setting a static IP address allows an administrator to set a specific IP address for the router and guarantees that it cannot be • Internet Connection Type assigned a different address.
User Manual of WBS-502AC • Discard Ping on WAN Check it to enable pings on the WAN interface or disable d to block pings on the WAN interface. 4.4.2.1. DHCP Select DHCP and the device will automatically obtain IP addresses, subnet masks and gateway addresses from the ISP. Figure 4-14 WAN Settings – DHCP The page includes the following specific settings in DHCP type type: Object Description • Account Name (if required) Enter the account name provided by your ISP.
User Manual of WBS-502AC 用前: 0.5 行 格式化: 間距 套用前: Figure 4-15 WAN Settings – Static IP The page includes the following specific settings in Static IP type type: Object Description • Account Name (if required) Enter the account name provided by your ISP. • Domain Name (if required) Enter the domain name provided by your ISP. The maximum transmission unit (MTU) specifies the largest packet size • MTU permitted for an internet transmission. The factory default MTU size for static IP is 1500.
User Manual of WBS-502AC Figure 4-16 WAN Settings – PPPOE 用前: 0.5 行 格式化: 間距 套用前: The page includes the following specific settings in PPPoE type type: Object Description The maximum transmission unit (MTU) specifies the largest packet size • MTU permitted for an internet transmission. The factory default MTU size for PPPoE is 1492. The MTU size can be set between 576 and 1492. • Login Enter the username provided by ISP. • Password Enter the password provided by ISP.
User Manual of WBS-502AC 4.4.2.4. PPTP Select PPTP if ISP is using a PPTP connection connection. Figure 4-17 WAN Settings – PPTP The page includes the following specific settings in PPTP type type: Object Description The maximum transmission unit (MTU) specifies the largest packet size • MTU permitted for an internet transmission. The factory default MTU size for PPTP is 1400. The MTU size can be set between 1200 and 1400. • IP Address Enter the device’s WAN IP address provided by ISP.
User Manual of WBS-502AC 4.4.3 VPN Passthrough VPN Passthrough allows a secure virtual private network (VPN) connection between two sites. Enabling the options on this page opens a VPN port and enables connections to pass through the AP without interruption. Go to the “Network Wireless” page to configure the device as “WISP” and then go to “Router VPN Pass Through” to enable VPN passthrough you required in WISP mode. 用前: 0.
User Manual of WBS-502AC • # Displays the sequence number of the forwarded port. • Name Displays the name of the forwarded port. • Protocol Displays the protocol to use for mapping from the following: TCP, UDP or Both. • Start Port Displays the LAN port number that WAN client packets will be forward to. • End Port Displays the port number that the WAN client packets are received. • Server IP Address Displays the IP address of the server for the forwarded port.
User Manual of WBS-502AC Enter the IP address of the server computer on the LAN network where • IP Address users will be redirected. • Save Click Save to save the new forwarding rule. 4.4.5 DMZ Settings The DMZ function allows the device to redirect all packets going to the WAN port IP address to a particular IP address on the LAN.
User Manual of WBS-502AC 用前: 0.5 行 格式化: 間距 套用前: Figure 4-22 DoS Protection The page includes the following settings settings: Object Description • SYN Flood Attack Protection Enter a value between 1 ~ 10000. When the current TCP-SYN-Flood TCP Packets numbers is beyond the set value, the Router will start up the blocking function immediately. • Use TCP SYN Cookies Protection • UDP Flood Attack Protection Select it to use TCP SYN Cookies Protection. Enter a value betwe between 1 ~ 10000..
User Manual of WBS-502AC Figure 4-23 Wireless Settings – AP Mode Figure 4-24 Wireless Settings – WDS AP Mode 用前: 0.5 行 格式化: 間距 套用前: In the AP/WDS AP mode, click the Edit button on the “Wireless Settings – 5GHz” section to enter the “SSID Profile” page to configure the SSID profile includes the wireless security and wireless traffic shaping for the wireless network.
User Manual of WBS-502AC Figure 4-25 Wireless Profile – AP/WDS AP Mode 用前: 0.5 行 格式化: 間距 套用前: The wireless settings of AP or WDS AP mode include the following settings: Object Description Wireless Settings – 5GHz Displays the sequence number of the entries. • No. In the AP mode, up to 8 SSIDs can be configured as different VAPs. In the WDS AP mode, up to 4 SSIDs can be configured as different VAPs. • Enable Click it to enable the SSID interface. • SSID Specify the SSID for the current profile.
User Manual of WBS-502AC Wireless Profile Settings (Security, MAC ACL, Wireless Traffic Shaping) Select the suitable security mode from the drop drop-down down list to encrypt the wireless network. The options include Disabled, WEP, WPA-PSK, WPA • Security Mode WPA2 WPA2-PSK, WPA-PSK PSK Mixed, WPA, WPA2, and WPA Mixed Mixed. The latest WPA2 WPA2-PSK mode is strongly recommended.
User Manual of WBS-502AC 用前: 0.5 行 格式化: 間距 套用前: Figure 4-27 27 Wireless Settings – CB/WDS STA/CR Mode 用前: 0.5 行 格式化: 間距 套用前: The page includes the following settings settings: Object Description Ent Enter the MAC address if known. If you select an Access Point in the Site • Prefer BSSID Survey, this field is completed automatically. Specify the SSID if known. This field is completed automatically if you • SSID select an Access Point in the Site Survey.
User Manual of WBS-502AC Figure 4 4-29 WDS Link Settings – WDS Bridge Mode The page includes the following settings settings: Object Description • Security Select the type of WDS security: None, WEP, or AES. • WEP Key Enter the WEP key if security is selected as WEP. • AES Passphrase Enter the AES passphrase if security is selected as AES. Displays the sequence number of the entries. In the WDS AP mode, up to 4 nodes can be configured to use WDS link.
User Manual of WBS-502AC In the AP/WDS AP mode, click the Edit button in the “Wireless Settings – 5GHz” section to enter the “SSID Profile” page and configure the wireless security for the wireless network. Figure 4-30 Security Settings – AP/WDS AP Mode In the CB/WDS STA/CR mode, click Edit button in the “Wireless Settings – 5GHz” section to modify the wireless security of the associated AP AP.
User Manual of WBS-502AC Figure 4-32 Security Settings – WDS Bridge Mode The option includes the following settings settings: Object Description Select the suitable security mode from the drop drop--down list to encrypt the • Security Mode wireless network. The options include Disabled, WEP, WPA-PSK, WPA WPA2 WPA2-PSK, WPA-PSK PSK Mixed, WPA, WPA2, and WPA Mixed. The latest WPA2 WPA2-PSK mode is strongly recommended. 1. The WEP and WPA/WPA2 with TKIP d does not support in the 802.
User Manual of WBS-502AC Figure 4-33 Security Settings – WEP The security mode includes the following settings settings: Object • Security Mode Description Select WEP from the drop-down list to configure the wireless network using WEP encryption method. • Auth Type Select Open System or Shared. • Input Type Select an input type of Hex or ASCII. Level of WEP encryption is applied to all WEP keys. Select a 64 64-/128-/152-bit password length.
User Manual of WBS-502AC The security mode includes the following settings settings: Object • Security Mode Description Select WPA WPA-PSK from the drop-down down list to configure the wireless network using WPA WPA-PSK encryption method. Select TKIP or AES, or both as the encryption type. • Encryption Both: uses TKIP and AES. TKIP: automatic encryption with WPA-PSK; PSK; requires passphrase. AES: automatic encryption with WPA2-PSK; PSK; requires passphrase. • Passphrase Specify the security password.
User Manual of WBS-502AC WPA-PSK Mixed Figure 4-36 Security Settings – WPA-PSK Mixed The security mode includes the following settings settings: Object Description Select WPA-PSK Mixed from the drop-down down list to configure the wireless • Security Mode network using WPA-PSK Mixed encryption method. Select TKIP or AES, or both as the encryption type. Both: uses TKIP and AES. • Encryption TKIP: automatic encryption with WPA-PSK; PSK; requires passphrase.
User Manual of WBS-502AC Select TKIP or AES, or both as the encryption type. Both: uses TKIP and AES. • Encryption TKIP: automatic encryption with WPA-PSK; PSK; requires passphrase. AES: automatic encryption with WPA2-PSK; PSK; requires passphrase. • Radius Server Specify the IP address of the RADIUS server. Specify the port number that your RADIUS server uses for authentication. • Radius Port Default port is 1812. • Radius Secret Specify RADIUS secret furnished by the RADIUS server.
User Manual of WBS-502AC AES: automatic encryption with WPA2-PSK; requires passphrase. • Radius Server • Radius Port Specify the IP address of the RADIUS server. Specify the port number that your RADIUS server uses for authentication. Default port is 1812. • Radius Secret Specify RADIUS secret furnished by the RADIUS server. • Group Key Update Interval Specify how often, in seconds, the group key changes. • Radius Accounting Select to enable or disable RADIUS accounting.
User Manual of WBS-502AC WPA Mixed (WPA Mixed Enterprise) Figure 4-39 Security Settings – WPA Mixed (WPA Mixed Enterprise) The security mode includes the following settings settings: Object • Security Mode Description Select WPA Mixed from the drop-down down list to configure the wireless network using WPA Mixed encryption method. Select TKIP or AES AES, or both as the encryption type. • Encryption Both: uses TKIP and AES. TKIP: automatic encryption with WPA-PSK; PSK; requires passphrase.
User Manual of WBS-502AC 4.5.4 Wireless MAC Filter Wireless MAC Filters are used to allow or deny network access to wireless clients according to their MAC addresses. You can manually add a MAC address to restrict the permission to access the device or refer to section 5.2.3 to kick the associated client from the wireless client list. Click “Wireless Wireless MAC Filter Filter” to configure the wireless access control settings.
User Manual of WBS-502AC 4.5.5 Guest Network Settings Go to the “Network Wireless” page to configure the device as “Access Point” or “WDS WDS Access Point” mode and then you can configure the Guest uest Network Settings in the bottom of the page. The Guest Network allows segregate temporary guest wifi usage with individual SSID, security and DHCP settings. Click Edit to configure the security for the guest network.
User Manual of WBS-502AC and then you can configure the Guest Network Settings in the bottom of the page. and then you can configure the RSSI Threshold in the bottom of the page. The RSSI Threshold is used when a weakening wireless link between AP and client is detected below the specific RSSI, the AP will encourage client to access the nearby AP with stronger signal, thus ensure stable wireless connectivity.
User Manual of WBS-502AC • Status • Management VLAN ID Click Enable to enable the Management VLAN. Specifies the management VLAN ID for the wireless network.
User Manual of WBS-502AC 4.6 Management On this page, you can configure the system settings for management purpose,, including Management VLAN settings, Time settings, Password settings, SNMP settings, CLI settings, Wi-Fi Fi schedule, Firmware upgrade, Configuration backup and restore,, Factory default, and Auto reboot. 4.6.1 Account (Password Settings) Click “System Manager Account”” to configure username and password of the login account.
User Manual of WBS-502AC Click “Management Advanced” to configure SNMP settings. Figure 4-45 SNMP Settings The page includes the following settings settings: Object Description • SNMP Enable or disable the SNMP service. • Contact Enter the contact details of the device. • Location Enter the location of the device.
User Manual of WBS-502AC • Priv Key (8-32 Characters) Specify the privacy key for privacy. • Engine ID Specify the engine ID for SNMPv3. • Save/Apply Click Save/Apply to apply all changes. • Cancel Click Cancel to cancel the settings. 4.6.3 CLI/SSH/HTTPS Settings Click “Management Advanced” to configure CLI/SSH/HTTPS settings.
User Manual of WBS-502AC Figure 4-47 Email Alert Settings The page includes the following settings settings: Object Description • Status Click Enable to use email alert. • From Enter the email address to show the sender of the email. • To Enter the address to receive email alerts. • Subject Enter the text to appear in the email subject line. • Username Enter the username for the email account that will be used to send emails.
User Manual of WBS-502AC Figure 4-48 Backup/Restore Settings The page includes the following settings settings: Object Description Factory Setting • Backup Setting Click Export to save the current configured settings. • Restore New Setting • Revert to Factory Default Settings To restore settings that have been previously backed up, click Choose File to select the file, and click Import. Click Reset to restore the device to its factory default settings.
User Manual of WBS-502AC Figure 4-49 Auto Reboot Settings The page includes the following settings settings: Object Description • Auto Reboot Settings Select Enable to set up this function. • Timer Select the day and enter the time you would like to reboot automatically. • Save Click Save to save all changes. 4.6.6.2. WiFi Scheduler Click “Management WiFi Scheduler Scheduler” and the following page will be displayed. This page allows you to configure wireless on/off schedule rule rule.
User Manual of WBS-502AC The page includes the following settings: Object Description • Status Select Enable to set up this function. • Wireless Radio Select frequency from the drop-down list for the preferred band type. • SSID Selection Select the SSID that you want to configure the wifi schedule. • Schedule Templates Select a schedule template from the drop-down list. • Schedule Table Choose “available” or “unavailable” on the specific day.
User Manual of WBS-502AC Step 1. Click the Choose File button to locate the firmware file path. Then, click the Upload button. Step 2. The firmware checksum information appears to help you confirm whether the file is correct. Once confirmed, click the Upgrade button to begin the upgrade process. 格式化: 間距 套用前: 0.5 行 Step 3. Wait for the process until it is finished. Step 4.
User Manual of WBS-502AC Figure 4-52 Time Settings The page includes the following settings settings: Object Description Enter the date and time values in the date and time fields or click the • Manually Set Date and Time Synchronize with PC to get the e date and time values from the administrator’s PC.
User Manual of WBS-502AC 4.6.9 Log Click “System Manager Log” to view the system log. Figure 4-53 System Log The page includes the following settings settings: Object Description • Status Select Enable to enable the system log. • Log type Select log type to filter the records. • Save Click Save to save the records. • Refresh Click Refresh to update the current data. • Clear Click Clear to erase the records. • Remote Log Select Enable to enable the remote log function.
User Manual of WBS-502AC Figure 4-54 Tools - Ping The section includes the following settings settings: Object Description • Target IP / Domain Name Enter the IP address you would like to ping. • Ping Packet Size Enter the packet size of each ping. • Number of Pings Enter the number of times you want to ping. • Start Click Start to begin pinging.
User Manual of WBS-502AC Figure 4-56 Tools – Speed Test The section includes the following settings settings: Object Description • Target IP / Domain Name Enter the IP address you would like to test. • Time period Enter time period for the speed test. • Check Interval Enter the interval for the speed test. • Start Click Start to begin the speed test operation. • IPv4 Port Displays the IPv4 port number of the device. • IPv6 Port Displays the IPv6 port number of the device. 4.6.
User Manual of WBS-502AC Appendix A: Troubleshooting If you find the AP is working improperly or stop responding to you, please read this troubleshooting first before contacting the Planet Tech Support for help. Some problems can be solved by yourself within a very short time. Scenario Solution The AP is not responding to me when I Please check the connection of the power cord and the want to access it by web browser. Ethernet cable of this AP.
User Manual of WBS-502AC Are you too far from your AP? Try to get closer. Please remember that you have to input ESSID on your wireless client manually, if ESSID broadcast is disabled. File downloading is very slow or breaks Are you using QoS function? Try to disable it and try again. frequently. Internet is slow sometimes; try to be patient. Try to reset the AP and see if it’s better after that. Try to know what computers do on your local network.
User Manual of WBS-502AC Appendix B: Use Planet Smart Discovery to find AP To easily discover the WBS-502AC in your Ethernet environment, the Planet Smart Discovery Utility is an ideal solution. The utility is available at: http://www.planet.com.tw/en/product/images/48590/Planet_Utility.zip The following instructions will guide you to how to use the Planet Smart Discovery Utility. Step 1. Deposit the Planet Smart Discovery Utility in administrator PC. Step 2. Execute this utility. Step 3.
User Manual of WBS-502AC EC Declaration of Conformity English Hereby, PLANET Technology Corporation, declares that this 900Mbps 802.11ac Wireless Outdoor CPE is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Lietuviškai Šiuo PLANET Technology Corporation,, skelbia, kad 900Mbps 802.11ac Wireless Outdoor CPE tenkina visus svarbiausius 1999/5/EC direktyvos reikalavimus ir kitas svarbias nuostatas.
