Battery exhausted time for TOSHIBA WT10-A Battery type Sleep Mode Battery pack (22.5 Wh, about 10 days 2 cell) Shut Down Mode about 6 weeks Battery exhausted time for TOSHIBA WT8-B Battery type Sleep Mode Battery pack (15 Wh, 1 about 6 days cell) Shut Down Mode about 6 weeks Extending battery life To maximize the life of your battery pack: At least once a month, disconnect the tablet from a power source and operate it on battery power until the battery pack fully discharges.
Inside or directly under a building Inside a bag or box Among dense trees When there is an obstacle (person or object) in the front of the antenna Underground tunnel, underground, or underwater Buildings streets or residential areas Near to the high voltage cables Bad weather such as heavy rain or snow Memory media The tablet is equipped with a memory media slot that can accommodate some kinds of memory media with various memory capacities so that you can easily transfer data from devices, such as digital
Formatting a memory media card Memory media cards are sold already formatted in conformity to specific standards. If you reformat a memory card, be sure to reformat it with a device such as digital camera or digital audio player that uses the memory cards, not with the format command provided within Windows. Should you need to format all areas of the memory card, including the protected area, you will need to obtain an appropriate application that applies the copy protection system.
3. Press the memory media gently until it clicks into place. Figure 4-8 Inserting memory media (TOSHIBA WT10-A) 2 1 Figure 4-9 Inserting memory media (TOSHIBA WT8-B) 1 1. Memory media slot 2 2. Memory media Product appearance depends on the model you purchased. Make sure the memory media is oriented properly before you insert it. If you insert the media in wrong direction, you may not be able to remove it. When inserting the memory media, do not touch the metal contacts.
USB Device This tablet is equipped with a Micro-USB port that complies with USB 2.0 standard. You can connect the USB device into the Micro-USB port on your tablet directly or through the USB port on the provided "USB Data and Charge YCable" depending on the USB device. Make sure the connector is properly aligned with the socket. Do not try to force the connection, doing so can damage the connecting pins.
The AC adaptor should not be disconnected with the "USB Data and Charge Y-Cable" if it is connecting with USB device and tablet at the same time. If the USB device works with USB bus power, which comes from "USB Data and Charge Y-Cable", the disconnection of AC adaptor would cause power loss. Even if the USB device has its own power source, the device will stop around 60 miliseconds because USB controller would detect with “no bus power” due to sudden disconnection with AC adaptor.
2. 3. Plug the other smaller end of the HDMI cable into the Micro HDMI port on your tablet. Turn the HDMI display device's power on. Figure 4-11 Connecting an HDMI cable 2 1 1. Micro HDMI port 2. HDMI cable (Type D connector) Please do not plug/unplug an HDMI device under the following conditions: The system is starting up. The system is shutting down. When you connect a television or external monitor to the Micro HDMI port, the display output device is set to HDMI.
While data is being read or written. While communication is being carried out. Selecting HD Format To select the display mode, follow the steps as detailed below: 1. 2. Tap Desktop Assist -> Control Panel -> Appearance and Personalization -> Display -> Change display settings -> Advanced settings -> List All Modes under TOSHIBA group in the Apps view. Select one of the modes at List All Modes.
Changing the display settings After one or more external displays are connected, the operating system can automatically detect, identify and setup the display settings. You can also manually manage how the external displays will work and change the display settings by tapping Projector in the Devices charm. If you disconnect the external display before you turn the tablet's power off, be sure to switch to the internal display.
Figure 4-13 Magnets location (Keyboard) Product appearance depends on the model you purchased. The Keyboard contains magnets that may interfere with pacemakers, defibrillators or other medical devices. If you wear a pacemaker, keep at least 6 inches (approximately 15cm) of separation between your medical device and the Keyboard. If you suspect that the Keyboard is interfering with your medical device, discontinue use and consult your physician for information related to your specific device.
Setting up the Keyboard Fit your tablet into the Keyboard properly. The Keyboard supports two modes when using it with your tablet. Stand mode You can put your tablet onto the Keyboard cover and operate like a laptop when in this mode. Figure 4-14 Stand mode Product appearance depends on the model you purchased. Portable mode This mode provides you the convenience to carry the Keyboard and prevent damange or scratch to it.
2. Plug the the smaller connector of the Micro-USB cable into the MicroUSB port on your Keyboard. Figure 4-16 Charging the Keyboard 2-pin 3-pin Product appearance depends on the model you purchased. 3. Plug the AC adaptor into a live wall outlet. A full charge takes about 3 hours. If you are not going to use the Keyboard for a long period of time, turn it off to conserve power. Connecting your tablet to the Keyboard Before you start using the Keyboard, it is neccessary to do Bluetooth pairing.
To manually disconnect the Keyboard, tap Bluetooth Keyboard and tap Remove device. The touch pad may not work properly by immediate use after turning on the Bluetooth keyboard. If it happens, please turn off/on the keyboard again and wait for over three seconds. Reconnecting the Keyboard Under any of the following conditions, the connection between your tablet and the Keyboard will be lost. Bluetooth is turned off on your tablet. Keyboard is manually disconnected from tablet.
Two-Finger Scroll Place two fingers down and slide them vertically or horizontally from anywhere on the Touch Pad. This allows you to operate the scroll bars of a window. Swipe Quickly move your finger in from the edge of the Touch Pad, without pausing when you first touch it. Swipe from the left edge: shows your recently opened apps. Swipe from the right edge: opens or closes the charms (Search, Share, Start, Devices, Settings). Swipe from the top edge: opens or closes the app command bar.
Special function mode Standard F1F12 mode Function F6 FN + F6 Moves media backward. F7 FN + F7 Plays or pauses media playback. F8 FN + F8 Moves media forward. F9 FN + F9 Decreases the tablet's volume. F10 FN + F10 Increases the tablet's volume. F11 FN + F11 Turns the sound on or off. F12 FN + F12 Launches the Function Key utility at the first time (by default). You can enable/disable F12 key’s function within the utility.
To access it, tap Desktop Assist -> Tools & Utilities -> Function Key under TOSHIBA group in the Apps view. Windows special keys The keyboard provides two keys that have special functions in Windows, the Windows® logo key activates the Start screen while the application key has the same function as the secondary (right) mouse button. This key activates the Windows Start screen. This key has the same function as the secondary (right) mouse button.
1. 2. 3. Press and hold on the speaker icon on the Windows Taskbar, and select Recording devices from the sub menu. Select Microphone, and tap Properties. On the Levels tab move the Microphone slider to increase or decrease the microphone volume level. If you feel the microphone volume level is inadequate, move the Microphone Boost slider to a higher level. Video mode Video mode settings are configured via the Screen Resolution dialog.
Chapter 5 Utilities and Advanced Usage This chapter describes the utilities and special features of this tablet, and the advanced usage of some utilities. Utilities and Applications This section describes the pre-installed utilities that come with the tablet and details how to start them. For further information on their operation, you may refer to each utility's online manual, help files or README.TXT file (if applicable).
TruNote This software is note taking application that can take and management handwritten notes. To access it, tap TruNote in the Apps view. For more information, please refer to the TruNote section. TruRecorder This software is a recording application that can check recorded data quickly and easily, analyze voices to automatically identify specific speakers, and allow you to mark important statements in the recording. To access it, tap TruRecorder in the Apps view.
Dolby® Digital Plus™ Advanced Audio™ Dolby® Digital Plus™ Advanced Audio™ is a suite of audio technologies that enables a PC to deliver a crisp, clear cinematic surround sound experience over its built-in speakers. It also adds clarity to sound from headphones. To access this utility, tap the Dolby Digital Plus icon in the Apps view. You may not have all the software listed above depending on the model you purchased.
A Tutorial will appear on the screen which provides the basic information about how to use this feature. Tap next if you want to continue viewing the Tutorial. For more detailed information on the use of this feature, tap More information. You can also find it by swiping from the right edge of the screen, and then tap Settings -> Help. TruNote You can use this application to take and manage the handwritten notes. To open TruNote, tap TruNote in Apps view.
3. Tap Change settings that are currently unavailable . 4. Deselect the Turn on fast startup check box from Shutdown settings. 5. Tap the Save changes button. To save the changes and exit the utility, select Save and Exit -> Exit Saving Changes -> Yes. The tablet will restart immediately. Navigating the utility TOSHIBA Setup Utility can be navigated through the touch screen. Some buttons on the tablet are also designated to execute the corresponding unction.
Do not use utilities, including those intended to enhance internal storage access speed. They may cause unstable operation and damage data. Do not shut down/log off or Sleep/Hibernate while writing or rewriting the media. Set the tablet on a level surface and avoid places subjected to vibrations such as airplanes, trains, or cars. Do not use on an unstable surface such as a stand.
3. 4. 5. After completely shut down the tablet, wait for about 10 seconds. Then hold down the Power button and Volume up button simultaneously until the Boot menu is loaded. Use the Volume up and the Volume down button to select the appropriate option from the menu according to your actual recovery media and press the Windows button to confirm the selection. A menu will be displayed from which you should follow the on-screen instructions.
In addition, if you use a third-party partitioning program to reconfigure the partitions on your internal storage, you may find that it becomes impossible to setup your tablet. Make sure that the AC adaptor is connected during the restoring process. When you reinstall the Windows operating system, the internal storage may be reformatted and all data may be lost. For detailed information, please refer to the Windows Help and Support. 1. 2. 3. 4. 5. 6.
Chapter 6 Troubleshooting TOSHIBA has designed this computer for durability, however, should problems occur you are able to use the procedures detailed in this chapter to help determine the cause. All users should become familiar with this chapter as knowing what might go wrong can help prevent problems from occurring in the first place.
Check all cables to ensure they are correctly and firmly attached to the computer - loose cables can cause signal errors. Inspect all connecting cables for loose wires and all connectors for loose pins. Always try to make detailed notes of your observations and keep them in a permanent error log - this will help you to describe your problems to TOSHIBA Support. In addition, if a problem recurs, the log you have made will help to identify the problem faster.
Hardware If you cannot find a software problem, you should then check the setup and configuration of your hardware. First run through the items in the preliminary checklist as described previously then, if you still cannot correct the problem, try to identify the source - the next section provides checklists for individual components and peripherals.
Advanced option Key & button operations BIOS utility Hold down Power button and Volume down button simultaneously. Boot menu Hold down Power button and Volume up button simultaneously. If your computer starts to load the Operating System instead of desired advanced options, follow the steps below: Please make sure that fast startup is disabled in the Power Options by following the steps below: 1. 2. 3. 4. 5. 1. 2. 3.
Problem Procedure Computer shuts down automatically. Leave the computer off until the it reaches room temperature. If the computer has reached room temperature and it still does not start, or if it starts but shuts down quickly, contact TOSHIBA Support. AC power Problem Procedure AC adaptor doesn’t power the computer Check the connections to make sure that the Micro-USB cable/adaptor is firmly connected to the computer and a working power outlet. Check the condition of the cable and terminals.
Real Time Clock Problem Procedure The BIOS setting and system date/ time are lost. The lasting time of the Real Time Clock (RTC) has run out - you will need to set the date and time in the BIOS setup utility by using the following steps: 1. 2. 3. 4. 5. Launch the BIOS setup utility. Please refer to the TOSHIBA Setup Utility section for further information. Set the date in the System Date field. Set the time in the System Time field.
Internal Storage Problem Procedure Slow performance The files on the internal storage may be fragmented - in this instance you should run the disk Defragmentation utility to check the condition of your files and the internal storage. Please refer to the operating system's documentation or online Help File for further information on operating and using the Defragmentation utility. As a last resort you should reformat the internal storage and then reload the operating system and all other files and data.
Problem Procedure USB device does not Remove the USB device from the computer and work then reconnect it to the Micro-USB port in order to ensure it is firmly attached. Ensure that any required USB device drivers are properly installed - to achieve this you should refer to both the device documentation and the operating system documentation. Sound system In addition to the information in this section, please also refer to the documentation supplied with your audio device.
Problem Procedure Monitor does not turn on After confirming that the monitor's power switch is on, you should check the connections to make sure that the power cord/adaptor is firmly connected to the monitor and to a working power outlet. No display Try adjusting the contrast and brightness controls on the external monitor. change the display priority and ensure that it is not set for the internal display only. Check to see if the external monitor is connected.
Bluetooth Problem Procedure Cannot access Bluetooth device Check to ensure the computer's Wireless Communication function is on. Check to ensure the Bluetooth Manager application is running on the computer and that power to the external Bluetooth device is turned on. Check to ensure that no optional Bluetooth Adaptor is installed in the computer - the built-in Bluetooth hardware cannot operate simultaneously with another Bluetooth controller.
Chapter 7 Appendix Specifications This section summarizes the tablet’s technical specifications. Physical Dimensions Physical Dimensions shown below do not include parts that extend beyond the main body. The physical dimensions may vary depending on the model you purchased. TOSHIBA WT10-A Approximately 258.8 (w) x 175 (d) x 9.1 (h) millimeters (not including parts that extend beyond the main body). TOSHIBA WT8-B Approximately 132 (w) x 210.62 (d) x 9.
Power Requirements AC adaptor 100-240V AC 50 or 60 Hz (cycles per second) Computer 19V DC External RGB monitor port pin assignment 5 1 15 11 10 6 Pin Signal Name Description I/O 1 CRV Red Video Signal O 2 CGV Green Video Signal O 3 CBV Blue Video Signal O 4 Reserved Reserved 5 GND Ground 6 GND Ground 7 GND Ground 8 GND Ground 9 +5V Power Supply 10 GND Ground 11 Reserved Reserved 12 SDA Data Signal I/O 13 HSYNC Horizontal Sync Signal O 14 VSYNC Vert
AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Wire size: Minimum 0.75 mm2 Current rating: Minimum 2.5 amperes Certification agencies China: CQC U.S. and Canada: UL listed and CSA certified No.
USA United Kingdom UL approved BS approved Australia Europe AS approved Approved by the appropriate agency Canada China CSA approved CCC approved Information for Wireless Devices Wireless Technology Interoperability The Wireless LAN is compatible with other LAN systems Direct Sequence Spread Spectrum (DSSS) /Orthogonal Frequency Division Multiplexing (OFDM) radio technology, and is compliant to: The IEEE 802.
and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection. If you should experience any such problem, immediately turn off either one of your Bluetooth or Wireless LAN. Please visit http://www.pc.support.global.toshiba.com if you have any questions about using Wireless LAN or Bluetooth Module. In Europe visit http://www.toshiba-europe.com/computers/tnt/bluetooth.
Do not use the Wireless LAN (Wi-Fi) or Bluetooth functionalities near a microwave oven or in areas subject to radio interference or magnetic fields. Interference from a microwave oven or other source can disrupt Wi-Fi or Bluetooth operation. Turn all wireless functionalities off when near a person who may have a cardiac pacemaker implant or other medical electric device. Radio waves may affect pacemaker or medical device operation, possibly resulting in serious injury.
impose a number of limitations to the use of wireless communication equipment. Radio Frequency Band 2.4GHz (2400-2483.5 MHz) (Revision b/g and n) The range of the wireless signal is related to the transmit rate of the wireless communication. Communications at lower transmit range may travel larger distances. The range of your wireless devices can be affected when the antennas are placed near metal surfaces and solid high-density materials.
comes with the product. This product complies with the following radio frequency and safety standards. Europe Restrictions for Use of 2400.0-2483.5MHz Frequencies in Europe France: Outdoor use limited to 10mW e.i.r.p. within the band 2454-2483.5MHz Military Radiolocation use.Refarming of the 2.4GHz band has been ongoing in recent years to allow current relaxed regulation Full implementation planned 2012.
designed to provide reasonable protection against harmful interference in a residential installation. Refer to the FCC information section for the detailed information. The radiated output power of the Wireless device is far below the FCC radio frequency exposure limits. Nevertheless, the Wireless device shall be used in such a manner that the potential for human contact during normal operation is minimized.
1. Important notice The frequency bandwidth of this equipment may operate within the same range as industrial devices, scientific devices, medical devices, microwave ovens, licensed radio stations and non-licensed specified low-power radio stations for mobile object identification systems (RFID) used in factory production lines (Other Radio Stations). 1. 2. 3. Before using this equipment, ensure that it does not interfere with any of the equipment listed above.
4. : This equipment uses a frequency bandwidth from 2,400 MHz to 2,483.5 MHz. It is impossible to avoid the band of mobile object identification systems. Device Authorization This device obtains the Technical Regulation Conformity Certification and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Telecommunications Business Law of Japan. Broadcom BCM43340 802.
Legal Footnotes Non-applicable Icons Certain computer chassis are designed to accommodate all possible configurations for an entire product series. Therefore, please be aware that your selected model may not have all the features and specifications corresponding to all of the icons or switches shown on the computer chassis. CPU Central Processing Unit (CPU) Performance Legal Footnotes.
graphics system, applications utilized, system memory size and other factors. If your computer is configured with more than 3 GB memory, the memory might be displayed as approximately 3 GB only (depending on the computer’s hardware specifications). This is correct because the operating system usually displays the available memory instead of the physical memory (RAM) built into the computer. Various system components (like the video adapter’s GPU and PCI devices like Wireless LAN, etc.
Maximum brightness is only available when operating in AC power mode. Screen will dim when the computer is operated on battery power and you may not be able to increase the brightness of the screen. Graphics Processing Unit (GPU) Graphics processing unit (GPU) performance may vary depending on product model, design configuration, applications, power management settings and features utilized.
User's Manual CMOS: Complementary Metal-oxide Semiconductor CPU: Central Processing Unit DC: Direct Current DDR: Double Data Rate DIMM: Dual Inline Memory Module DVD: Digital Versatile Disc DVD-R: Digital Versatile Disc-recordable DVD-RAM: Digital Versatile Disc-random Access Memory DVD-R DL: Digital Versatile Disc Recordable Dual Layer DVD-ROM: Digital Versatile Disc-read Only Memory DVD-RW: Digital Versatile Disc-rewritable DVD+R DL: Digital Versatile Disc Recordable Double Layer
OCR: Optical Character Recognition (Reader) PC: Personal Computer PCI: Peripheral Component Interconnect PCMCIA: Personal Computer Memory Card International Association RAM: Random Access Memory RGB: Red, Green, and Blue RFI: Radio Frequency Interference ROM: Read Only Memory RTC: Real Time Clock S/P DIF: Sony/philips Digital Interface Format SD: Secure Digital SDHC: Secure Digital High Capacity SDXC: Secure Digital Extended Capacity SDRAM: Synchronous Dynamic Random Access Memory
Index A G AC adaptor additional 4-26 connecting 2-3 B Graphics Processing Unit 3-9 H HDMI out port 3-4 Battery extending life 4-11 monitoring capacity 4-10 save mode 5-3 Bluetooth 7-7 C K Keyboard Function keys F1...
Problems Analyzing the problem 6-2 Battery 6-5 External monitor 6-8 Hardware and system checklist 6-4 HDD 6-7 Internal display panel 6-6 Memory Media Card 6-7 Overheating power down 6-4 Power 6-4 Real Time Clock 6-6 Sound system 6-8 TOSHIBA support 6-10 USB device 6-7 U USB device problems 6-7 V Video mode 4-27 Video RAM 3-9 W Web Camera 3-3, 3-6 R Wireless communication 7-5 Recovery hard disk drive 5-7 Recovery Media 5-6 Restarting the computer 2-8 S SD/SDHC/SDXC Card formatting 4-13 note 4-12 Sleep
