WIRING FAIL SAFE AND FAIL SECURE LOCKING HARDWARE



Fail safe and fail secure are ways of configuring locking hardware:

● Fail safe hardware unlocks when power is interrupted

● Fail secure hardware locks when power is interrupted

VOLTAGE SWITCHES

To power locking hardware without an external supply (Wet Relay), select 12V or 24V,

and connect locking hardware to NO and GND (for fail secure locks) or NC and GND

(for fail safe locks). To use external power, select DRY and use NO or NC and C, and

wire to external supply.



WARNING: Remove DC Input Power and PoE before changing the voltage of the

relays.



PROVISIONING THE SDC

Provisioning the SDC means registering it in the Control Center and getting it up and

running with the latest firmware. You can provision the SDC using the Open Admin

app for first time setup and in the case of RESETTING THE SDC.

REQUIREMENTS

● Meet all NETWORK REQUIREMENTS

● Connect the SDC to the Internet via Ethernet or via Wi-Fi

● Install the Open Admin app

○ iOS App Store

○ Google Play Store



To provision the SDC:



1. Before you can provision an SDC using the Open Admin app, you must first

create an SDC in the Control Center.

a. To add one SDC:

i. Go to https://control.openpath.com/login and log in

ii. Go to Hardware > ACU Management

iii. To add a new SDC, click the blue Create ACU button on the top

right corner

iv. Enter a name for the SDC. Names are usually relevant to the

location where the SDC is installed.



Version 1



Openpath 2020

Page 8



Summary of content (8 pages)

PAGE 1
WIRING FAIL SAFE AND FAIL SECURE LOCKING HARDWARE Fail safe and fail secure are ways of configuring locking hardware: ● Fail safe hardware unlocks when power is interrupted ● Fail secure hardware locks when power is interrupted VOLTAGE SWITCHES To power locking hardware without an external supply (Wet Relay), select 12V or 24V, and connect locking hardware to NO and GND (for fail secure locks) or NC and GND (for fail safe locks).
PAGE 2
v. From the Add ACU Expansion Board dropdown, select Openpath SDC and click Add. ● Note: You must add at least one expansion board vi. A description of the SDC will appear in green. Click Save. vii. At this point, you can create Readers, Entries, and Zones prior to provisioning b. To add multiple SDCs: i. Go to https://control.openpath.com/login and log in ii. Go to Administration > Quick Start iii. Enter a Site Name, click Next iv.
PAGE 3
Figure 3: ADMIN button TEST INTERNET CONNECTION In the Open Admin app, you can tap Test Internet Connection to check if the SDC can ping http://api.openpath.com/health NETWORK SETTINGS In the Open Admin app, you can configure network settings for the SDC. The default interface for the SDC is Ethernet/wired connection. You can change this by going to Network Settings > Wi-Fi IP Settings and enabling Default Interface.
PAGE 4
COUNTRY SETTINGS The country code on the SDC is automatically set up during initial connection and provisioning based on information from the installer’s Open Admin app. This setting cannot be changed by the installer. If you need to change the country code, please contact Openpath support.
PAGE 5
Figure 4: SDC Status LED The Openpath SDC has eight Port LEDs and two power LEDs.
PAGE 6
RESETTING THE SDC SOFT RESET To soft reset the SDC, disconnect power and Ethernet from the SDC, wait 10 seconds, then reconnect the power. HARD RESET WARNING: Only hard reset the SDC if absolutely necessary and if instructed by Openpath. This will clear all of the data off of the SDC and will require reprovisioning. To hard reset the ACU: 1. Disconnect power and Ethernet from the SDC 2. Hold down the ADMIN BUTTON for 15 seconds 3.
PAGE 7
Regulatory All national and local electrical codes apply. FCC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
PAGE 8
type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
