MINI PTZ Network Mini Dome Cameras Quick Guide V1.
Safety and Compliance Information Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must read all of the Safety Instructions supplied with your equipment before installation and operation. Installation This device is a class A product and may cause radio interference. Take measures if necessary. Make sure the camera operates in an environment where the temperature and humidity meet requirements.
Contact professionals for maintenance information. Do not attempt to dismantle the device by yourself. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. Maintenance Caution: There will be risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. If there is dust on the glass window surface, remove the dust gently using an oil-free brush or a rubber dust blowing ball.
to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
LVD/EMC Directive This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner. Battery Directive-2013/56/EC Battery in the product complies with the European Battery Directive 2013/56/EC.For proper recycling,return the battery to your supplier or to a designated collection point.
the actual model for details. Item Quantity Camera 1 User document 1 Accessory pack 1 Appearance Dimensions The figures in the manual are for your reference only. The actual appearance may vary with the product model. ∅129.0mm (5.1") 143.6mm (5.7") ø108.5mm (4.3") S100.0mm (3.9") 1/4-UNC-2B 5 3-ø4.0mm (0.
Cable Connection The appearance and tail cable may vary with device model.
For specifications, see the latest product datasheet. Power Cable Requirements Please calculate the camera's power consumption (=voltage x current) based on the ratings on the nameplate. The maximum transmission distance and power requirements with power supply 12V DC, camera lowest working 10.8V DC Diameter (mm) Distance (m) Power (VA) 10 0.8 (AWG20) 1.00 (AWG18) 1.25 (AWG16) 1.
The maximum transmission distance and power requirements with power supply 12V DC, camera lowest working 9V DC Diameter (mm) Distance (m) Power (VA) 10 0.8 (AWG20) 1.00 (AWG18) 1.25 (AWG16) 1.
Insert the SD card along the arrow direction Open the slot cover 2. Uninstall the adapter plate. Hold the camera, rotate the adapter plate counterclockwise to detach it from the camera. Rotate counterclockwise OPEN LOCK Adapter plate 3. Attach the sticker. Attach the sticker to the desired mounting place.
4. Fix the adapter plate to the ceiling. Knock expansion bolts into holes, and fix the plate to the ceiling with screws. Make sure that FRONT on the plate is in monitoring direction. 5. Install the camera. Secure the camera to the adapter, align FRONT on the plate with the gap between OPEN and LOCK on the camera, rotate the camera counterclockwise until it’s fastened.
Lead the cable through the side slot opening on the camera to secure the cable, so that you may avoid opening a hole on the ceiling. Disconnect from power before intalling or uninstalling Micro SD card. Otherwise, the device or the Micro SD card might be damaged. For recommended SD card specifications, contact your dealer or technical support. Access Your Camera Before you begin, check that: Your camera is operating properly and connected to the network.
interface: 1. your browser, input the IP address of your camera in the address bar and then press Enter to open the login page. 2. Enter the username and password and then click Login. Install the ActiveX at your first login. When the installation of the ActiveX is completed, open your IE to log in. For your first login with Windows 7, if the system does not prompt you to install ActiveX, follow these steps to turn off UAC: click the Start button, and then click Control Panel.
