SERIES FAN / LIGHT SERVICE PARTS

99045406C

Key No.

No. Clave

No. Légend

Description

Descripción

Description

Part No.

No. Pieza

No. Pièce

Models

Modelos

Modèles

Housing

Caja

Boîtier

97019514

(all)

(todos)

(tous)

Duct Connector – 4”

Conector del conducto - 4 pulg.

Raccord de conduit – 4 po

97019561

AEN80L,AEN80BL,

AERN90LC

97020122

AEN110L, AERN110L,

AERN110LC

Wire Panel Assembly

Ensamblaje del panel de alambre

Assemblage du panneau de fil

97019516

(all)

(todos)

(tous)

Blower Assembly

Conjunto del soplador

Ensemble souffleur

97019785 AEN80L, AEN80BL

97019786

AERN90LC, AEN110L,

AERN110L,

AERN110LC

Grille Spring (2 req’d)

Resorte de la parilla (2 nec.)

Ressort de grille (2 req.)

99140214

(all)

(todos)

(tous)

LED Module

Módulo LED

Module LED

99271529

(all)

(todos)

(tous)

Grille Assembly

(includes key no. 5 & 6)

Conjunto de grille

(incluye no. clave 5 y 6)

Ensemble de grille

(incluis no. légend 5 & 6)

97019921

(all)

(todos)

(tous)

Parts Bag

(not shown)

Bolsa de piezas (no mostrada)

Sac de pièces (non represente)

97019743

(all)

(todos)

(tous)

Summary of content (1 pages)

PAGE 1
SERIES FAN / LIGHT SERVICE PARTS Key No. No. Clave No. Légend Description Descripción Description 1 Housing Caja Boîtier 2 Duct Connector – 4” Conector del conducto - 4 pulg. Raccord de conduit – 4 po 3 4 5 6 7 8 Wire Panel Assembly Ensamblaje del panel de alambre Assemblage du panneau de fil Blower Assembly Conjunto del soplador Ensemble souffleur Grille Spring (2 req’d) Resorte de la parilla (2 nec.) Ressort de grille (2 req.) LED Module Módulo LED Module LED Grille Assembly (includes key no.
