EN USER INSTRUCTIONS AND SAFETY Firmware Version: 1.
Congratulations on your purchase of an N-Com product. N-Com BX5 was made using the most advanced technologies and the best materials. Long-running tests and thorough system development have allowed the highest audio quality to be achieved. For additional information about BX5, and to download high-definition instructions as well as the latest Firmware version, visit the website www.n-com.
Contents 1. WARNINGS AND SAFETY ................................................................................................................... 4 1.1.Road safety ................................................................................................................................................................ 4 1.2.Switching on the system in safe environments ......................................................................................... 4 1.3.Interferences........................
1. WARNINGS AND SAFETY Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N-Com BX5. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and the like.
BX5 Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected to it before you use the system on the road. Caution: Adjusting the volume to very high levels may cause damage to your hearing. Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected to it so as to avoid audio reproduction at high volumes. Constant exposure to high audio volumes may damage your hearing.
1.7. Disposal Refer to this user manual and to manuals related to other parts of the N-Com system in order to disassemble the system from the helmet. Once the system has been disassembled, dispose of it according to the following instructions: The presence of a crossed-out wheelie bin indicates that in the European Union the product is subject to separate collection at the end of its useful life. Do not dispose of these products together with undifferentiated urban waste.
BX5 2.
3. INSTALLATION Important: Prior to installing the N-Com system, it is recommended to write down the identification code affixed to the product (see chapter XX). 3.1. Preliminary operations – Jet helmets or Flip-up helmets You can download the installation video from www.n-com.it X-Series Download section. Fig. 1 Fig. 2 Fig. 3 Open the helmet chin guard (only on Flip-up helmets). Pull out both comfort cheek pads, left and right, from the helmet. (Fig.
BX5 Fig. 7 Fig. 6b Remove both comfort cheek pads, left and right, from the helmet (see specific instructions in the helmet user manual). (Fig. 4) Open the visor. Remove the rear section of the comfort padding, pulling on the neck roll until it is released from the shell (see specific instructions in the helmet user manual).Reposition the padding on the outside of the helmet for the time being. (Fig. 5) Remove the chin guard by pulling on the special red tab (Fig.
3.3. Installing the microphone – jet helmets or flip-up helmets Fig. 11 Fig. 12a Set up the microphone by inserting the clip that holds it in place, being careful to position it correctly. (Fig. 11) Note: The flat part of the clip has to face upward when the microphone is positioned as shown in Fig. 11. Fig. 12b Fig. 13 Position the microphone on the left side of the helmet, screwing the screw into the small frame. (Fig.
BX5 3.5. Installing the battery and the right-hand side speaker Fig. 16 Fig. 17 Fig. 18 Connect the battery to the wiring system. (Fig. 16) Position the battery in the right polystyrene cheek pad housing and secure it using the Velcro ribbon. (Fig. 17 / 18) Position the right-hand side speaker in the specific cheek pad housing and secure it using the specific adhesive (Fig. 19). Reposition the right polystyrene cheek pad in its housing. Fig.
Only for X702 helmet Position the battery connector and wiring underneath the shell gasket (Fig. 21). Cut along the pre-cut lines of the plastic tab on the back of the comfort padding (Fig. 22). Secure the wiring underneath the plastic tab. Close the cut parts using the cable fixing adhesives (Fig. 23). Fig. 21 Fig. 23 Fig. 22 3.6. Positioning the e-box Connect the microphone to the e-box. (Fig. 24) Position the e-box in the left polystyrene cheek pad housing. (Fig.
BX5 N.B.: BEFORE replacing the left polystyrene cheek pad, follow the instructions provided in the following chapter. 3.7. Installing the adhesive keyboard Remove the N-Com plug from the left side of the helmet; to make this easier, it is recommended to push the plug from the inside of the helmet. (Fig. 27) Thoroughly clean the outside surface of the shell to make sure that the adhesive keyboard sticks properly.
Fig. 32 Fig. 33 Remove the protective film from the back of the adhesive keyboard using the special tab. (Fig. 32) Pass the antenna and keypad cable completely through, inside the helmet. Apply the keyboard to the shell and press down on its entire surface to make sure that it sticks properly. (Fig. 33) Note: Make sure you do not glue the antenna and keypad cable underneath the keypad support.
BX5 Only for flip-up / jet helmets: Secure the neck roll (left side), being careful to slide the neck roll plastic ring behind the microphone, then clicking it in the press stud. (Fig. 35) Secure the neck roll (right side) by hooking up the plastic ring to the press-stud. Fig. 35 Warning: Always verify the proper length of your chinstrap and adjust it if necessary, referring to the specific helmet instructions.
5. BASIC FUNCTIONS System ON System OFF Increase Volume Decrease Volume 5.1. Press “on” and keep it pressed for about 2 seconds, until the LEDs turn on and you hear a beep in the headset. Press “on” and keep it pressed for about 4 seconds, until the LEDs turn off and you hear a beep in the headset. Briefly press “” to increase the volume. A double tone signals the highest volume level. Briefly press “” to decrease the volume. A double tone signals the lowest volume level.
BX5 6. MOBILE PHONE Answering a phone call Briefly press any key when you hear the incoming call signal. Voice call Press “on” and “n” at the same time. Redial last number Press “on” and “n” and keep them pressed for about 2 seconds. Dial Friend Number Press “n” and keep it pressed for about 2 seconds. Hanging up/rejecting a phone call Transferring a call from helmet to mobile phone Press “on” and keep it pressed for about 2 seconds.
7. MUSIC VIA BLUETOOTH – A2DP BLUETOOTH PROTOCOLL Play music (Play) Briefly press “on”. Pause function (Pause) When the player is connected and playing music, press “on” for 2 seconds. Next track (Skip) When the player is playing music, press “” for 2 about seconds. Previous track (Rew) When the player is playing music, press “” for 2 about seconds. Turning off the A2DP Press “on” and keep it pressed for about 4 seconds.
BX5 9.1. Navigators on Smartphone (Smart Navi System) By connecting the M5 system to a Smartphone, all navigator instructions are sent to the helmet through the A2DP profile. During each navigator communication, the intercom via Bluetooth is automatically cut off and subsequently restored when the navigator has stopped giving road instructions (SMART NAVI SYSTEM function). The Smart Navi System function can be turned off in Setting Mode (see Chapter 15). 10.
13. BIKE TO BIKE INTERCOM The N-Com system is used for bike-to-bike communication up to a distance of about 800 m (open terrain, no obstacles). The M5 system entails the use of a default “STANDARD” commands configuration, or the use of a “FRIENDS” configuration that can be turned on from the N-Com Wizard or dedicated App.
BX5 Con FRIENDS CONFIGURATION active: Call CHANNEL 4 Briefly press “on”. Call CHANNEL 5 Press the “on” key twice. Call CHANNEL 6 Press the “on” key three times. Disconnection of active intercom Briefly press “on”. N.B.: In case the memory setting is empty, or the other helmet cannot be reached, an error tone will sound in your helmet.
N.B.: The N-systems keeps an active connection with a mobile phone or a GPS even during Bluetooth communication with other intercom systems. The intercom system connected to N-Com may not allow simultaneous connection to a mobile phone. 15. SETTING MODE All Bluetooth pair ups and other adjustments are carried out in this mode. To put the system in Setting mode, press the “on” key and keep it pressed for 4 seconds, until the red LED starts to flash quickly.
BX5 16. BATTERY AND RECHARGE 16.1. Low battery signal During its operation, the system alerts the user with a voice message when the battery is low. From the first message, the system has a 1-hour autonomy. Warning is given every 10 minute. 16.2. Charging the system To charge the system, hook it up to the battery charger or to a USB outlet powered with the USB-mini USB cable supplied as standard equipment.
17.
BX5 Radio Menu Button n on Turning on the Radio x2 Turning off the Radio x2 N + on Automatic search for new station Change station (pre-set stations) + 2 sec 2 sec Pre-set station 4 sec Pairing up mode (system turned off) Setting* Turning on/off the RDS X Turning on/off the Smart Navi System Pairing up secondary mobile phone (or device) 2 sec 2 sec Pairing up CHANNEL 1 X Pairing up CHANNEL 2 x2 Pairing up CHANNEL 3 x3 Pairing up CHANNEL 4 X Pairing up CHANNEL 5 x2 Pa
18. LIMITED WARRANTY With this LIMITED WARRANTY CERTIFICATE, Nolangroup warrants this Product to be free from defects in material and workmanship at the time of its original purchase by the buyer. We invite you to: - Read the cautions pertaining to safety and proper use. - Read the warranty terms and conditions. - Keep the originals sales receipt. This must be shown in case of repairs covered by warranty. In these cases, the product has to be taken back to the dealer where it was purchased. 18.1.
BX5 Nolangroup shall not be responsible in case the product presents limited capabilities due to the operating mode of cell phones or of other accessories or equipment not supplied by Nolangroup. Tampering with the internal electronic card or with other parts of the N-Com system shall invalidate the warranty.
NOT LIMITED TO LOST PROFITS OR COMMERCIAL DAMAGES, TO THE FULL EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY THE LAW. NOLANGROUP RESERVES ITSELF THE RIGHT TO MODIFY, AT ANY TIME AND WITHOUT ADVANCE NOTICE, THE PRODUCT CHARACTERISTICS, FUNCTIONS, COMPATIBILITY AND SOFTWARE.
19.
