RF Module Overview Introduction The MWF220H RF module is designed for the user to implement cost effective solution to industrial wireless high power network products. The standard mPCI-e form factor makes it easy to install and fix in the embedded board. Key Features: - Qualcomn Atheros RF chip - Standard full size mPCIe interface - High Power up to 24dBm.
Mini PCIe pin definition Logical symbol of RF module Pin description PIN 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49 Definition WAKE_L RESERVED RESERVED CLKREQ_L GND REFCLKREFCLK+ GND NC NC GND PERn0 PERp0 GND GND PETn0 PETp0 GND NC 3.3V 3.3V GND RESERVED RESERVED 5V PIN 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 Definition 3.3V GND NC NC NC NC NC NC GND W_DISABLE_L PERST_L 3.
51 5V 52 3.
Installation The installation of RF module is very easy. Just follow the steps below and you can complete the installation: Insert the radio module into mini PCIe slot in the PCBA. Screw up to fasten the module tightly inside PCBA. Note: The mini PCIe pin definition is different from standard mini PCIe module in other Wi-Fi application. The embedded PCBA should follow the mini PCIe pin definition to design the pin assignment to connect this radio module.
Product specification Main Chip QCA9382 Dual-Band 2 x 2 MIMO 802.11 an WLAN Single chip Memory M24C32-FMC6TG, 32K, SOP-8, EEPROM Crystal XTAL,SMD,40MHz,4pin,21ppm,3.2X2.5MM PA SE5023L, 5 GHz, 26dBm Power Amplifier with Power Detector Power Supply DC 5V&3.3V (5V used to external PA) MIMO 5GHz, 2T2R I/O interface mPCI-E Temperature spec -20~+80 PCB Size 30x50.8mm Output Power 21dBm@MCS15 Power consumption Max 9.6W RF output power : IEEE 802.11a/n a. 1. 2. b. 1. 2. IEEE802.11a 27dBm@6M 24dBm@54M IEEE802.
Antenna specifications
Note: i. The module is limited to installation in mobile or fixed applications, according to Part 2.1091(b). ii. Separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations.
