CR6019D-BR Executive Deluxe USB Turntable Instruction Manual Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 6 p.m., EST, Monday – Friday 1-888-CROSLEY www.crosleyradio.
English Safety Instructions Read and understand this entire manual before using this product. Keep these instructions for future reference. 1. Do not use this product near water. 2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. 3. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way.
English Items in this package Before throwing away any packaging materials, please check thoroughly and make sure you find the following items that come along with this package: • Turntable • 45 RPM adapter • 3.5mm aux in cable • Power adaptor Please contact Crosley customer service if there is any accessory missing from the package. Retain the original packaging materials for exchange or return purposes.
English Product Description 1. 2. 3. 4. 5. 6. 7. 8. 9. Turntable Platter Turntable Spindle Tonearm Lever Tonearm Function Switch Auto-stop Switch Pitch Control Speed Switch On/Off-Volume Knob 10. Tonearm Rest 11. Hold Down Clip 12. Headphone Jack 13. USB Jack 14. Aux In Jack 15. RCA Jacks 16. Power Jack 17.
English Initial Setup Essential Setup 1. Place the unit on a flat and level surface. The selected location should be stable and free from vibration. 2. Remove the tie-wrap that is holding the tonearm. 3. Place the slip mat on top of the turntable platter. 4. Connect AC adaptor to the Power Jack of the unit. Note: Do not plug the AC power adaptor to power outlet before all the assembly is completed. Before turning the power on, make sure again all the connection settings are correct.
English Turntable Operation 1. 2. 3. 4. Rotate the On/Off Volume Knob to turn on the power. Set the Speed Switch accordingly. Place the record on the turntable. Use the 45 RPM Adapter if necessary. Remove the stylus protector from the stylus assembly. Note: To avoid stylus damage, make certain the included stylus guard is in place whenever the turntable is being moved or cleaned. 5. Release the tonearm Hold Down Clip. Note: when the turntable is not in use, remember to lock back hold down clip. 6.
English Needle Replacement Removing Needle 1. Gently pull down the front edge of the needle. 2. Pull needle forward. 3. Pull out and remove. Installing Needle 1. Position the needle with its tip facing down. 2. Line up the back of the needle with the cartridge. 3. Insert the needle with its front end at a downward angle and gently lift the front of the needle upward until it snaps into place.
English Bluetooth Operation 1. Press the Function Switch to Bluetooth mode , you will hear an activation sound from the unit. 2. Turn on the Bluetooth feature of your audio device, search for “Crosley CR6019” and pair. 3. Once your device is successfully paired with the unit, you will hear a short confirmation sound from the unit. 4. Play and stream music from your device to the unit. Note: Bluetooth version - 4.2 Turntable Maintenance 1. Do not touch the stylus tip with your fingers.
English Troubleshooting There is no power • Power adaptor is not connected correctly. • No power at the power outlet. • To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 20 minutes, their powers will automatically cut-off. To turn power back on and resume playing, turn off the power and turn it on again. Power is on, but the platter does not turn • Turntable’s drive belt has slipped off.
English FCC Statements FCC Caution: 1. This device complies with Part 15 of the FCC rules/ Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. 3.
