台揚科技股份有限公司 ISO 9001 Certified MICROELECTRONICS TECHNOLOGY INC. NOTE: APPROVALS ON THIS PAGE SIGNIFY APPROVAL OF ENTIRE PROCEDURE. MTI RFID Reader DEMO Integration Program 1.05_02 User Guide Model : RU-814 A0 LTR. 陳建鳴 AS ISSUED E.C.O. NO. DATE CHANGE INFORMATION REVISED HISTORY DWG NO. 43-RFID INTEGRATION UG105 PAGE NO.
LTR. E.C.O. NO. DATE CHANGE INFORMATION REVISED DWG NO. XX-XXXX AUTHOR HISTORY TITLE: XXXXXXXXXXXXXXXXXXXXX 台揚集團智慧財產 MTI Group Proprietary Information 任何未經授權逕予複製、重製、公開或使用本文之行為，將被視為侵害 台揚集團之智慧財產權，將可因此負擔法律責任。 Any unauthorized use, duplication, reproduction, or disclosure of this document may be considered as infringement of MTI Group’s intellectual property rights, the infringer may be accused and liable applicable legal penalties.
台揚集團智慧財產 MTI Group Proprietary Information 任何未經授權逕予複製、重製、公開或使用本文之行為，將被視為侵害 台揚集團之智慧財產權，將可因此負擔法律責任。 Any unauthorized use, duplication, reproduction, or disclosure of this document may be considered as infringement of MTI Group’s intellectual property rights, the infringer may be accused and liable applicable legal penalties.
RFID Reader DEMO Integration User Guide V1.05_02 台揚科技股份有限公司 ISO 9001 Certified 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 4 DATE: 12/13/2006 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 5 DATE: 12/13/2006 Table of Content Chapter 1 Introduction.......................................................................................................................7 1.1 Purpose .............................................................................................................................7 1.2 Trademarks..........................
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 6 DATE: 12/13/2006 Table of Figures Fig. 1 Interface installation with related ports. .....................................................................9 Fig. 2 Start the setup wizard. ............................................................................................11 Fig. 3 Select the destination location to install. .............................
台揚科技股份有限公司 ISO 9001 Certified MICROELECTRONICS TECHNOLOGY INC. RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 PAGE: 7 DATE: 12/13/2006 Chapter 1 Introduction 1.1 Purpose This document provides information and procedures on demo software program installation, setup, and use of MTI RFID Reader. 1.2 Trademarks The product described in this book is a licensed product of Microelectronics Technology Inc.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 8 DATE: 12/13/2006 Chapter 2 Accessories 2.
台揚科技股份有限公司 ISO 9001 Certified MICROELECTRONICS TECHNOLOGY INC. RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 PAGE: 9 DATE: 12/13/2006 2.2 Interface Installation Please install the accessories as following illustration, see Fig. 1. Fig. 1 Interface installation with related ports.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 MICROELECTRONICS TECHNOLOGY INC. 43-RFID INTEGRATION UG105 PAGE: 10 DATE: 12/13/2006 Chapter 3 Installation 3.1 Install Java Runtime Environment The MTI RFID DEMO requires Java Runtime Environment (JRE) 5.0 or newer version. Please make sure that your JRE had been installed on your Windows. You can download it from Sun Microsystems, see http://java.sun.com/javase/downloads/index.jsp 3.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 11 DATE: 12/13/2006 Fig. 2 Start the setup wizard. Step 2: Select destination location where the program will be installed, shown in Fig. 3 Fig. 3 Select the destination location to install. Step 3: Select start menu folder where the program’s shortcuts will be placed, shown in Fig.
RFID Reader DEMO Integration User Guide V1.05_02 台揚科技股份有限公司 ISO 9001 Certified Fig. 4 Step 4: 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 12 DATE: 12/13/2006 Select start menu folder to install. Install the program and finish wizard, shown in Fig. 5 and Fig. 6 Fig. 5 Ready to install.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 13 DATE: 12/13/2006 Fig. 6 Finish the installation. Step 5: The shortcuts will be created on startup program group and desktop. 3.3 Uninstall MTI RFID DEMO Step 1: Click shortcut of “Uninstall MTI RFID Integration”. Step 2: Click “Yes” of confirmation to remove program, shown in Fig. 7 Fig. 7 Confirmation of uninstallation.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 14 DATE: 12/13/2006 Step 3: Click “OK” to finish uninstallation, shown in Fig. 8 Fig. 8 Uninstall MTI RFID Integration successfully.
RFID Reader DEMO Integration User Guide V1.05_02 台揚科技股份有限公司 ISO 9001 Certified 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 15 DATE: 12/13/2006 Chapter 4 MTI RFID Integration 4.1 Launch Software "RFID Integration v1.05_02" can be launched by double clicking the shortcut on desktop, or from startup menu. The Fig. 9 shows the running screen. If the program couldn’t run, please check the JRE (in section 3.1) was installed correctly. Fig. 9 Running screen.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 16 DATE: 12/13/2006 4.2 Connect The program contacts RFID Reader by TCP connection. It could be running as TCP Server mode or TCP Client mode by selecting the radio box of "TCP Server" or "TCP Client". Please press “Connect” button to enable the connection dialog as Fig. 10 shows. In server-mode (see Fig.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 17 DATE: 12/13/2006 Fig. 11 Connection dialog - TCP Client. When the socket is connected, the icon of “TCP Connection” will be green as Fig. 12 shows; otherwise it will be red to indicate the failure of socket connection. The failure is caused by timeout in most of the cases. Please check the IP address of reader and computer’s setting. Fig.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 18 DATE: 12/13/2006 available, the RF power of reader won’t turn on. The default value is that only antenna number 1 was plugged in and its sequence is 1st. If you want to adjust the RF power, change the value of “Power”. The degree is from 24 to 28.5 dBm. Please see Fig. 13 about above setting, and Fig. 14 shows the status of antenna’s switch. Fig.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 19 DATE: 12/13/2006 Fig. 16 Scan button and additional options. The data mask supplies the filter of EPC data. The “Mask” field is the bytes of filter; the “Mask Length” is the number of bits to filter. nothing (see Fig. 17).
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 20 DATE: 12/13/2006 After starting to scan the EPC data, the button “Scan” will become to “Stop”. To stop the scanning, press “Stop” button, then the reader stops to read EPC. You can press “Scan” to make reader to scan again, and the showing table will be reset. 4.4 Read All "Read All" is the same as Read EPC in section 4.3 except masking data.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 21 DATE: 12/13/2006 Fig. 20 Read data of banks. 4.5 Write Before writing data to tag or locking the tag, you must turn on the RF power. Different with reading, the antenna setting is just the Tx selection. Choose one Tx antenna which you want to use to write the tag (see Fig. 21). You can also adjust power like reading. Fig.
台揚科技股份有限公司 ISO 9001 Certified RFID Reader DEMO Integration User Guide V1.05_02 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. PAGE: 22 DATE: 12/13/2006 Fig. 22 Memory bank selection. The data what you want to write is in “Data”, and “Data Length” means that how many bytes will be written (see Fig. 23). For example, if you want to write a 96 bits data to EPC bank. must have 12 bytes data, and “Data Length” must be “0x06”. The “Data” Note that one words is two bytes.
RFID Reader DEMO Integration User Guide V1.05_02 台揚科技股份有限公司 ISO 9001 Certified 43-RFID INTEGRATION UG105 MICROELECTRONICS TECHNOLOGY INC. Fig. 24 PAGE: 23 DATE: 12/13/2006 GPIO panel.
